🔧 Escape - Serpentine Belt Replacement

The serpentine belt drives accessories like the alternator and A/C. Replacing it fixes belt squeal, cracking, glazing, or a belt that’s been contaminated with oil/coolant.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; hot pulleys and coolant lines can burn you.
• ⚠️ Support your Escape with jack stands; never rely on a floor jack alone.
• ⚠️ Keep fingers and tools clear of the belt path when releasing the tensioner (it’s spring-loaded).
• ⚠️ If the belt was soaked in oil/coolant, fix the leak first or the new belt will fail early.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 19mm socket
• 1/2" drive breaker bar
• 15mm socket
• 1/4" drive ratchet
• 7mm socket
• 8mm socket
• Trim clip remover
• Flashlight
• Torque wrench (20-200 Nm range)
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Accessory drive belt tensioner - Qty: 1 (optional if noisy/weak)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Open the hood and look for the belt routing diagram sticker; if it’s missing, take a clear photo of the current routing before removing the belt.
• A “tensioner” is a spring-loaded pulley that keeps the belt tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front-right corner

• Use a 19mm socket to slightly loosen the front-right wheel lug nuts (do not remove yet).
• Use a floor jack (rated 3-ton minimum) to lift at the proper front jack point.
• Place jack stands (rated 3-ton minimum) under the support point and lower the vehicle onto the stands.
• Remove the lug nuts using the 19mm socket and take the wheel off.

Step 2: Remove the right-front splash shield/liner for access

• Use a trim clip remover to remove plastic push-clips (pry the center up first, then the clip).
• Use a 7mm socket and 8mm socket with a 1/4" drive ratchet to remove the small screws/bolts holding the liner/splash shield section.
• Use a flashlight to locate the belt, tensioner pulley, and crank pulley through the wheel well opening.

Step 3: Note the belt routing

• Use a flashlight to find the under-hood routing diagram and compare it to what you see at the engine.
• If the sticker is missing, use your phone to take a clear photo of the belt path before removal.
• Grooved side goes on grooved pulleys.

Step 4: Release belt tension

• Install a 15mm socket on a 1/2" drive breaker bar.
• Place the socket on the belt tensioner bolt head and rotate the tensioner to relieve tension (hold it firmly; it’s spring-loaded).
• While holding the tensioner released, slip the belt off the easiest-to-reach smooth pulley from the wheel well.

Step 5: Remove the old belt

• Slowly let the tensioner return to its resting position using the 1/2" drive breaker bar and 15mm socket.
• Pull the belt off the remaining pulleys by hand and remove it from the engine bay.
• Inspect pulleys by spinning them by hand (engine off): if any pulley is rough, wobbly, or noisy, plan on replacing that pulley/tensioner.

Step 6: Install the new belt

• Route the new belt around the pulleys following the under-hood routing diagram (or your photo), leaving the easiest pulley for last.
• Use a flashlight to confirm the belt ribs are fully seated in every grooved pulley (no ribs hanging off the edge).
• Use the 15mm socket and 1/2" drive breaker bar to rotate the tensioner again, slip the belt onto the last pulley, then slowly release the tensioner.

Step 7: Reinstall liner/splash shield and wheel

• Reposition the liner/splash shield and reinstall fasteners using the 7mm socket, 8mm socket, and 1/4" drive ratchet.
• Reinstall the wheel and hand-thread the lug nuts.
• Lower the vehicle using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a torque wrench (20-200 Nm range): Torque to 150 Nm (111 ft-lbs).

---

✅ After Repair

• Start your Escape and let it idle while you watch the belt for 30-60 seconds (stand to the side, keep loose clothing away).
• Listen for chirping/squealing; if present, shut off and re-check belt seating on every pulley with a flashlight.
• Take a short test drive, then re-check for any abnormal noises.

---

💰 DIY vs Shop Cost

Shop Cost: ₹6,000-₹12,000 (parts + labor)

DIY Cost: ₹1,500-₹3,500 (parts only)

You Save: ₹4,500-₹8,500 by doing it yourself!

Shop labor rates vary by area, but this repair typically bills about 1.0-2.0 hours.

---
