🔧 Prius - Serpentine Belt Replacement

Your Prius uses a single accessory drive belt (often called the serpentine belt) to drive the engine’s belt-driven accessories. Replacing it prevents squealing, slipping, and loss of accessory operation due to belt cracking or stretching.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Hybrid system: keep hands/tools away from orange high-voltage cables.
• ⚠️ Work on a cool engine; hot parts can burn you.
• ⚠️ Support the Prius with jack stands; never rely on a jack alone.
• ⚠️ Keep fingers clear of the belt path while releasing the tensioner.
• Disconnecting the 12V battery is not strictly required, but it’s recommended to prevent accidental starts while your hands are near rotating parts.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 3/8" drive breaker bar
• 14mm socket
• 10mm socket
• Trim clip removal tool
• Flat-blade screwdriver
• Torque wrench (10-150 ft-lbs)
• Work light
• Nitrile gloves
• Safety glasses
• Belt tension gauge (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Accessory drive belt (serpentine belt) - Qty: 1
• Plastic under-cover clips (assortment) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Open the hood and remove the key fob from the vehicle area (keep it 10+ feet away).
• If you choose to disconnect power: use a 10mm socket to disconnect the 12V battery negative terminal in the rear hatch area. (Negative terminal is the “-” post.)
• Take a photo of belt routing first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the front and remove the right-front wheel

• Use a 21mm socket and breaker bar to loosen the right-front lug nuts 1/2 turn while the tire is on the ground.
• Lift the front-right with a floor jack (rated 2-ton minimum), then place jack stands (rated 2-ton minimum) under a safe support point and lower the car onto the stand.
• Remove the lug nuts using a 21mm socket and ratchet, then remove the wheel.
• Reinstall later and Torque to 103 Nm (76 ft-lbs).

Step 2: Remove the RH (passenger-side) fender liner access and lower splash shield

• Use a trim clip removal tool and flat-blade screwdriver to remove the plastic clips/screws from the lower splash shield area and the front portion of the right fender liner.
• Use a 10mm socket and ratchet to remove any 10mm bolts holding the under-cover/liner (some fasteners vary).
• Pull the liner back just enough to see the belt and tensioner area.

Step 3: Locate the belt tensioner and relieve belt tension

• Locate the automatic belt tensioner (a spring-loaded arm with a pulley).
• Use a 14mm socket with a 3/8" drive ratchet (or breaker bar for more leverage) on the tensioner hex.
• Rotate the tensioner to relieve belt tension, then slide the belt off the easiest-to-reach pulley.
• Move slowly; spring tension is strong.

Step 4: Remove the old belt and compare to the new belt

• With tension released, remove the belt from all pulleys by hand.
• Compare belt length and rib count to the new belt before installing.
• Inspect pulleys for wobble or roughness by spinning them by hand (engine OFF).

Step 5: Route and install the new belt

• Route the new belt around the pulleys following the belt routing diagram (usually on the underside of the hood or in the service info). Use your phone photo as reference.
• Make sure the ribs sit fully in the pulley grooves; the belt must not ride on an edge.
• Use a 14mm socket with a ratchet to rotate the tensioner again, slip the belt onto the last pulley, then slowly release the tensioner.

Step 6: Verify belt alignment

• Use a work light to check every pulley: belt ribs centered, no twist, no missing grooves.
• If you have one, use a belt tension gauge (specialty) to confirm tension is in spec for an automatic tensioner system (you’re mainly confirming the tensioner isn’t weak).
• If it’s one rib off, fix it now.

Step 7: Reinstall splash shield/liner and wheel

• Reposition the liner and under-cover.
• Reinstall 10mm bolts using a 10mm socket and ratchet (snug them; do not over-tighten plastic).
• Reinstall plastic clips using a trim clip removal tool (and replace any broken clips).
• Reinstall the wheel and hand-start lug nuts, then snug with a 21mm socket.
• Lower the Prius off the jack stand using the floor jack.
• Use a torque wrench and 21mm socket to Torque to 103 Nm (76 ft-lbs).

Step 8: Restore 12V battery connection (if disconnected)

• Use a 10mm socket to reconnect the 12V negative terminal.
• Make sure the terminal is fully seated and snug.

---

✅ After Repair

• Start the Prius and listen for squeal, chirp, or slapping sounds near the belt area.
• With the car in READY and parked, visually confirm the belt runs smoothly (do not put hands near moving parts).
• Recheck that all clips/fasteners are installed and the splash shield is not rubbing the belt.
• After a short drive, recheck belt alignment and look for any fresh rubber dust.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $25-$65 (parts only)

You Save: $115-$325 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
