🔧 4Runner - Serpentine Belt Replacement

The serpentine belt drives key accessories like the alternator, A/C compressor, and power steering. If it’s cracked, noisy, or slipping, replacing it prevents charging issues and overheating.

Difficulty Level: Beginner | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine—hot pulleys and radiator parts can burn you.
• ⚠️ Keep fingers, hair, and clothing away from the cooling fan and pulleys.
• ⚠️ Support the SUV with jack stands if you go underneath—never rely on a jack alone.
• ⚠️ Do not pry on the belt with a screwdriver—you can damage ribs and pulleys.
• ⚠️ Battery disconnect is not required, but keep the key off and engine off.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 3/8" drive ratchet
• 3/8" drive breaker bar
• 3/8" drive extension set (3" and 6")
• 12mm socket
• Torque wrench (10-150 ft-lbs range)
• Trim clip removal tool
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Mechanic gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park your 4Runner on level ground and set the parking brake.
• Chock the rear wheels using wheel chocks.
• If you need more access from below, lift the front with a floor jack (rated 3-ton minimum) and support it with jack stands (rated 3-ton minimum).
• Find the belt routing diagram (usually on the underside of the hood or near the radiator support). If it’s missing, take a clear photo of the belt routing before removal.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the front skid plate (if it blocks access)

• Put on safety glasses and mechanic gloves.
• From underneath, use a 12mm socket with a 3/8" drive ratchet to remove the front skid plate bolts.
• Lower the skid plate and set it aside.
• On reassembly, tighten skid plate bolts to Torque to 37 Nm (27 ft-lbs).

Step 2: Locate the belt tensioner

• Use a flashlight and look at the front of the engine where the belt runs.
• Find the automatic belt tensioner (it’s a spring-loaded arm with a pulley).
• Tip: The tensioner is not removed.

Step 3: Relieve belt tension

• Install a 14mm socket on a 3/8" drive breaker bar (use a 3/8" drive extension set (3" and 6") if needed for reach).
• Place the socket on the tensioner’s hex and rotate the tensioner to release tension (you’ll feel strong spring resistance).
• Tip: Move slowly—spring tension snaps back hard.

Step 4: Remove the old belt

• While holding the tensioner rotated with the breaker bar, slip the belt off one easy-to-reach pulley (often the smooth idler or alternator pulley).
• Carefully let the tensioner return to its resting position—do not let it slam.
• Remove the belt from the remaining pulleys and pull it out.

Step 5: Inspect the pulleys (quick check)

• Spin the idler pulley and tensioner pulley by hand.
• If you feel grinding, roughness, or wobble, that pulley likely needs replacement before the new belt goes on.
• Wipe any obvious dirt/oil off the pulley faces using a clean rag (no solvents needed).

Step 6: Route the new belt

• Match the new belt to the old one by length and rib count before installing.
• Route the belt following the under-hood routing diagram, leaving one pulley (an easy-to-reach one) for last.
• Make sure the ribbed side sits fully in the ribbed pulleys’ grooves (no “half-on” ribs).
• Tip: If one rib is off, it will shred.

Step 7: Apply tension and seat the belt

• Rotate the tensioner again using the 14mm socket and 3/8" drive breaker bar.
• Slip the belt onto the last pulley, then slowly release the tensioner.
• Re-check belt alignment on every pulley—especially the crank pulley at the bottom.

Step 8: Reinstall the skid plate

• Reinstall the skid plate using the 12mm socket and 3/8" drive ratchet.
• Tighten bolts using a torque wrench to Torque to 37 Nm (27 ft-lbs).

---

✅ After Repair

• Before starting, do a final visual check that the belt ribs are centered in every grooved pulley.
• Start the engine and let it idle for 30-60 seconds while you watch the belt track smoothly (no wandering side-to-side).
• Listen for squealing or chirping. If you hear it, shut off the engine and re-check belt routing and seating.
• After a short test drive, do one more quick visual inspection.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $30-$70 (parts only)

You Save: $110-$320 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
