🔧 Serpentine Belt - Replacement

The serpentine belt drives the engine accessories on your CR-V, including the alternator and A/C compressor. On the 1.5L turbo, belt access is tight, so you’ll usually work from the passenger-side wheel well after removing the splash shield.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Let the engine cool fully before starting. The belt area sits near hot components.
• Do not place fingers near the tensioner path while releasing belt tension.
• Support the vehicle securely on jack stands before removing the wheel.
• Battery disconnect is not required for this repair.
• Take a photo of the belt routing first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• 19mm socket
• Ratchet
• Breaker bar
• Torx T25 screwdriver
• Trim clip removal tool
• Flashlight
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Chock the rear wheels.
• Raise the passenger front corner and support it with a jack stand.
• Remove the passenger front wheel for better access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open up the belt area

• Use a 19mm socket and ratchet to remove the passenger front wheel lug nuts, then remove the wheel.
• Use a Torx T25 screwdriver and trim clip removal tool to remove the front splash shield fasteners in the passenger wheel well.
• Pull the splash shield aside to expose the serpentine belt and tensioner.

Step 2: Release belt tension

• Locate the automatic belt tensioner.
• Use a breaker bar on the tensioner arm and rotate it to relieve belt tension.
• Move slowly to avoid slipping.

Step 3: Remove the old belt

• Slide the belt off one accessible pulley while holding tension off with the breaker bar.
• Slowly release the tensioner back to its stop.
• Remove the belt from all pulleys and pull it out through the wheel well.

Step 4: Inspect the pulleys

• Use a flashlight to inspect the belt tensioner, idler pulley, and accessory pulleys.
• Check for cracks, wobble, rough spinning, or oil contamination.
• If a pulley feels rough or loose, replace that part before installing the new belt.

Step 5: Install the new belt

• Route the new belt around all pulleys except the easiest final pulley.
• Use the breaker bar to rotate the tensioner again and slide the belt onto the last pulley.
• Make sure every rib sits fully in every pulley groove.
• Check the routing twice.

Step 6: Reassemble and verify

• Reinstall the splash shield using the Torx T25 screwdriver and trim clip removal tool.
• Reinstall the wheel and hand-tighten the lug nuts with the 19mm socket.
• Lower the vehicle and tighten the lug nuts in a star pattern to 108 Nm (80 ft-lbs).
• Start the engine and watch the belt for smooth tracking.

---

✅ After Repair

• Listen for squealing, chirping, or ticking noises.
• Watch the belt for wobble or walking off a pulley.
• Turn the steering wheel and switch on the A/C to confirm normal accessory operation.
• Recheck the lug nut torque after a short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $40-$90 (parts only)

You Save: $140-$230 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
