🔧 Ioniq - Serpentine Belt Replacement

Your A/C compressor, alternator/charging system, and water pump (engine cooling) are driven by the serpentine belt. On your Ioniq, belt tension is controlled by an automatic spring-loaded tensioner, so replacement is mostly about safely relieving tension and routing the new belt correctly.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully before working near belts and pulleys.
• ⚠️ Keep fingers/clothing clear of pulleys at all times; never work with the car in READY mode.
• ⚠️ Hybrid safety: do not touch orange high-voltage cables/connectors.
• ⚠️ Support the car with jack stands; never rely on a jack alone.
• Battery disconnect is not strictly required for belt replacement, but removing the negative terminal of the 12V battery is a good safety step to prevent accidental READY/start.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm lug nut socket
• Breaker bar (1/2")
• Ratchet (3/8")
• Serpentine belt tool (specialty)
• 14mm socket
• 17mm socket
• Torque wrench (10-150 ft-lbs)
• Trim clip remover
• Flathead screwdriver
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Accessory belt tensioner assembly - Qty: 1 (only if noisy/weak)
• Accessory idler pulley - Qty: 1 (only if noisy/rough)
• Plastic splash shield clips - Qty: 4-8 (as needed)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Shut the vehicle OFF and make sure it is not in READY mode (dash should be off).
• Chock the rear wheels with wheel chocks.
• Optional but recommended: disconnect the 12V battery negative terminal (use a 10mm socket if equipped with a 10mm clamp).
• Find the belt routing diagram (usually a sticker in the engine bay). If it’s missing, take a clear photo of the current routing before removal.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the front-right corner and remove the wheel

• Use a 21mm lug nut socket and breaker bar to loosen the front-right lug nuts 1/2 turn while the tire is on the ground.
• Lift at the proper jack point using a floor jack, then place the car on jack stands.
• Remove the lug nuts with the 21mm lug nut socket and remove the wheel.

Step 2: Remove the lower splash shield / side access panel

• Use a trim clip remover and flathead screwdriver to remove the plastic clips/screws holding the splash shield near the belt area.
• Pull the panel down and out to expose the belt and pulleys.
• Keep clips grouped so none go missing.

Step 3: Inspect the belt routing and pulleys

• Use a work light to clearly see the belt path.
• Check for cracks, missing ribs, glazing (shiny surface), or fraying.
• Spin any easy-to-reach pulleys by hand (engine OFF). If a pulley feels rough or noisy, plan to replace the pulley/tensioner.

Step 4: Relieve belt tension (automatic tensioner)

• Place a 17mm socket on the belt tensioner hex (some setups use 14mm socket—use the one that fits).
• Use a serpentine belt tool (specialty) or ratchet (3/8") to rotate the tensioner against the spring to loosen the belt.
• While holding the tensioner released, slide the belt off the easiest-to-reach smooth pulley.
• Slowly let the tensioner return to rest (do not let it snap back).
• Spring tension is strong—hold tight.

Step 5: Remove the old belt

• Pull the belt out from around the remaining pulleys by hand.
• Compare the old belt to the new belt (same rib count and similar length).

Step 6: Install the new belt (route first, tension last)

• Route the new belt around the crank pulley and the grooved pulleys first, making sure the ribs sit fully in the grooves.
• Leave the easiest-access pulley for last (usually a smooth idler or smooth section of the tensioner path).
• Rotate the tensioner again using the 17mm socket and serpentine belt tool (specialty), then slip the belt onto the last pulley.
• Release the tensioner slowly and confirm the belt is centered on every pulley.

Step 7: Reinstall the splash shield and wheel

• Reinstall the splash shield using the trim clip remover and flathead screwdriver to seat the clips.
• Reinstall the wheel and hand-start the lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern with a torque wrench: Torque to 88-108 Nm (65-80 ft-lbs).

---

✅ After Repair

• Before starting, do a final visual check that the belt is seated correctly on every pulley.
• If you disconnected the 12V battery, reconnect it securely.
• Start the car and let the engine run; watch the belt for 30-60 seconds. It should run smoothly with no wobble or chirping.
• Turn A/C on and off and listen for squeal (a misrouted belt or weak tensioner can cause noise).
• Recheck the splash shield area to ensure nothing is rubbing the belt.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $30-$90 (parts only)

You Save: $150-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
