🔧 Canyon - Serpentine Belt Replacement

The serpentine belt drives accessories like the alternator, A/C compressor, and power steering (if equipped). Replacement is mainly about safely relieving the spring tension, swapping the belt, then confirming the belt is routed correctly on every pulley.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from the fan and pulleys.
• ⚠️ Remove keys from the vehicle so nobody can start it.
• ⚠️ Do not put fingers between the belt and pulleys while releasing tension.
• ⚠️ If the belt is shredded, check for debris around pulleys before restarting.
• 🔋 Battery disconnect is not required for this job, but keep tools away from the positive terminal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Flashlight
• 3/8" drive ratchet
• 3/8" drive breaker bar
• 15mm socket
• Torque wrench (10-100 ft-lbs range)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and let the engine fully cool.
• Find the belt routing diagram (usually a sticker in the engine bay). If it’s missing, take a clear photo of the current routing before removal.
• Know what you’re moving: the belt tensioner is a spring-loaded pulley assembly that keeps the belt tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the belt and tensioner

• Use a flashlight to locate the serpentine belt on the front of the engine.
• Identify the belt tensioner pulley (it’s the pulley attached to a spring-loaded arm).

Step 2: Relieve belt tension

• Install a 15mm socket on the tensioner’s hex (or use the tensioner’s square drive if yours has one) with a 3/8" drive breaker bar.
• Slowly rotate the tensioner to release tension. Move it smoothly—don’t let it snap back.
• While holding tension off, slide the belt off the easiest-to-reach smooth pulley using your gloved hand.

Step 3: Remove the old belt

• Let the tensioner return to rest slowly using the 3/8" drive breaker bar.
• Remove the belt from the remaining pulleys by hand.
• Compare old vs new belt length and rib count before installing.

Step 4: Route the new belt

• Route the new belt exactly like the underhood diagram (or your photo).
• Make sure the ribbed side sits fully in the grooves of every ribbed pulley.
• Leave the easiest-to-reach pulley for last (this makes the final install easier).

Step 5: Re-apply tension and seat the belt

• Use the 15mm socket and 3/8" drive breaker bar to rotate the tensioner again.
• Slip the belt onto the last pulley.
• Slowly release the tensioner so it tightens the belt.

Step 6: Final alignment check

• Use a flashlight to check every pulley: the belt must be centered and fully seated in the grooves.
• If you removed any components for access (varies by setup), reinstall and Torque to the factory spec using a torque wrench.

---

✅ After Repair

• Start the engine and watch the belt for 20-30 seconds (keep hands and tools clear).
• Listen for chirping/squealing. If you hear it, shut off the engine and re-check that the belt is fully seated on every pulley.
• Recheck belt tracking again after a short 5-minute drive.

---

💰 DIY vs Shop Cost

Shop Cost: $150-$250 (parts + labor)

DIY Cost: $30-$70 (parts only)

You Save: $80-$220 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
