🔧 TLX - Serpentine Belt Replacement

The serpentine belt (also called the drive belt) spins your alternator, A/C compressor, and other accessories. Replacing it is mostly about safely relieving the automatic belt tensioner, swapping the belt, and making sure it’s routed correctly on every pulley.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cold engine; hot parts can burn you.
• ⚠️ Keep fingers and tools away from pulleys; never do this with the engine running.
• ⚠️ Support the car with jack stands; never rely on a floor jack alone.
• ⚠️ Make sure the belt is fully seated before starting the engine.
• 🧯 Battery disconnect is not required for this job, but keep keys away from the car so nobody can start it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Breaker bar 3/8" drive
• 3/8" drive ratchet
• 3/8" drive extension set (3" and 6")
• 19mm socket
• 10mm socket
• Phillips screwdriver #2
• Trim clip removal tool
• Tire iron or 19mm lug socket
• Torque wrench (20-150 ft-lb range)
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt (accessory drive belt) - Qty: 1
• Fender liner / splash shield clips (assorted) - Qty: 1 set

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Open the hood and locate the belt routing diagram (usually on the radiator support/under-hood label). If it’s missing, take a clear photo of the current routing before removal.
• A “tensioner” is a spring-loaded arm that keeps the belt tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the right-front corner safely

• Use a floor jack to lift at the right-front jack point.
• Place jack stands at the proper support point and lower the car onto them.
• Remove the right-front wheel using a tire iron or 19mm lug socket.
• When reinstalling later, Torque to 127 Nm (94 ft-lbs) using a torque wrench.

Step 2: Remove the splash shield / fender liner access

• Use a trim clip removal tool to pop out the plastic clips (pry the center up, then pull the clip out).
• Use a 10mm socket and 3/8" drive ratchet to remove any 10mm bolts holding the access panel/liner.
• Use a Phillips screwdriver #2 if any Phillips screws are present.
• Move the liner/shield aside to clearly see the belt and the tensioner.

Step 3: Double-check belt routing before removal

• Use a flashlight to identify each pulley and the belt path.
• Compare what you see to the under-hood routing diagram.
• Taking one photo now saves big headaches.

Step 4: Relieve tension with the automatic tensioner

• Install a 19mm socket on a breaker bar 3/8" drive.
• Place the socket on the tensioner’s hex boss/bolt head.
• Rotate the tensioner smoothly to relieve belt tension (it will feel spring-loaded).
• Move slowly; the spring is strong.

Step 5: Slip the belt off one upper pulley first

• While holding the tensioner released with the breaker bar 3/8" drive, use your free hand to slide the belt off an easy-to-reach smooth pulley (often an idler).
• Carefully let the tensioner return to its resting position.
• Remove the belt fully from the remaining pulleys by hand.

Step 6: Inspect pulleys and tensioner before installing the new belt

• Spin each accessible pulley by hand. They should feel smooth and quiet (no grinding).
• Check the tensioner for wobble and the pulley for roughness.
• If a pulley feels gritty or wobbly, the belt may not be the only problem.

Step 7: Route the new belt correctly

• Route the new belt around the pulleys following the under-hood diagram (grooves must sit in the grooves of ribbed pulleys).
• Leave the easiest-to-reach pulley for last.
• Use a flashlight to confirm the belt ribs are centered and not hanging off any pulley edge.

Step 8: Re-apply tension and seat the belt

• Use the 19mm socket and breaker bar 3/8" drive to rotate the tensioner again.
• Slip the belt fully onto the last pulley, then slowly release the tensioner.
• Re-check every pulley: the belt must be fully seated in every groove.

Step 9: Reinstall splash shield and wheel

• Reinstall the liner/access panel using the 10mm socket, 3/8" drive ratchet, trim clip removal tool, and Phillips screwdriver #2.
• Reinstall the wheel using a tire iron or 19mm lug socket.
• Lower the car off the jack stands using the floor jack.
• Torque to 127 Nm (94 ft-lbs) in a star pattern using a torque wrench.

---

✅ After Repair

• Start the engine and let it idle for 20-30 seconds while you watch the belt path (from a safe distance).
• Listen for squealing, slapping, or chirping. If you hear it, shut the engine off and re-check belt seating.
• Turn A/C on and off and confirm the belt continues to track straight.
• After a short drive, do a quick re-check to ensure the belt is still centered on each pulley.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $25-$70 (parts only)

You Save: $110-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
