🔧 Serpentine Belt - Replacement

The serpentine belt drives key accessories on your CX-5, and a worn belt can squeal, crack, or break without much warning. This job is straightforward because the belt uses an automatic tensioner, so the main challenge is safely relieving belt tension and routing the new belt correctly.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• Let the engine cool fully before starting. The belt area can be hot.
• Keep fingers, clothing, and tools clear of the tensioner path. The spring-loaded tensioner can move suddenly.
• Disconnect the negative battery terminal only if you want extra safety while working near the accessory drive. It is not strictly required for this repair.
• Do not start the engine with the belt removed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3/8-inch drive ratchet
• 3/8-inch drive breaker bar
• 14mm socket
• Flashlight
• Safety glasses
• Mechanic gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool completely.
• If you need more room, raise the front of the vehicle and support it with jack stands.
• Use a flashlight to study the belt routing before removal. Take a photo first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the belt routing

• Open the hood and find the belt path at the front of the engine.
• Use a flashlight to trace the belt around each pulley before touching anything.
• Look for a routing decal under the hood if present.

Step 2: Release belt tension

• Find the automatic belt tensioner.
• Use a 3/8-inch drive breaker bar with a 14mm socket on the tensioner hex.
• Rotate the tensioner to relieve belt tension. Move it slowly and keep control of the bar.
• Use steady pressure, not a quick jerk.

Step 3: Remove the old belt

• While holding the tensioner released, slide the belt off one smooth pulley first.
• Then remove the belt from the remaining pulleys by hand.
• Inspect the old belt for cracks, missing ribs, glazing, or fraying.

Step 4: Inspect the pulleys and tensioner

• Spin each smooth pulley by hand and check for roughness or noise.
• Check the tensioner arm for smooth movement and strong spring tension.
• If any pulley feels loose, gritty, or noisy, it should be repaired before installing the new belt.

Step 5: Install the new belt

• Route the new serpentine belt around the pulleys exactly the same as the old one.
• Leave the easiest-to-reach pulley for last.
• Use the 3/8-inch drive breaker bar and 14mm socket to release the tensioner again.
• Slip the belt onto the last pulley while keeping the belt seated in every groove.
• Make sure every rib sits in every groove.

Step 6: Verify belt seating

• Rotate the engine by hand only if needed for final inspection, using the proper service procedure for your vehicle.
• Check that the belt is centered on every pulley and not twisted.
• Release the tensioner slowly and confirm the belt stays aligned.

Step 7: Start and recheck

• Start the engine and watch the belt for 30-60 seconds.
• Listen for squealing, slapping, or rattling.
• If the belt walks off a pulley or makes noise, shut the engine off immediately and recheck the routing.

---

✅ After Repair

• Recheck belt alignment after a short test drive.
• Look for any signs of rubbing or abnormal belt movement.
• If you disconnected the battery, reset any lost settings as needed.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $35-$70 (parts only)

You Save: $145-$250 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-2 hours.

---
