🔧 3 - Serpentine Belt Replacement

The serpentine belt on your 3 drives key accessories like the alternator and A/C compressor. Replacing it restores proper charging and accessory operation and prevents a sudden roadside belt failure.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• Let the engine cool completely before working near the belt path.
• Keep fingers, hair, and clothing away from pulleys at all times.
• Support the car with jack stands before working in the wheel well.
• If you disconnect the battery, you may reset radio clock/settings.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum) - Qty: 2
• Wheel chocks
• 21mm socket
• Breaker bar (1/2")
• Torque wrench (1/2" drive)
• 10mm socket
• Ratchet (3/8")
• Extension (3/8" drive, 6")
• 14mm socket
• 14mm box-end wrench
• Trim clip remover (panel tool)
• Flathead screwdriver
• Flashlight
• Mechanic gloves
• Safety glasses
• Serpentine belt tool (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt (accessory drive belt) - Qty: 1
• Undercover/splash shield clips - Qty: As needed

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels using wheel chocks.
• Open the hood and find the belt routing diagram (usually on the underside of the hood or on the radiator support). If the sticker is missing, take a clear photo of the current belt routing before removal.
• Optional but recommended: disconnect the negative battery cable using a 10mm socket to prevent accidental shorts at the alternator.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the right-front corner and remove the wheel

• Loosen the right-front lug nuts with a 21mm socket and breaker bar (just crack them loose).
• Lift the right-front jacking point using a floor jack, then support the car on jack stands.
• Remove the lug nuts with a 21mm socket and remove the wheel.

Step 2: Remove the right-front splash shield/inner liner access

• Remove the plastic clips and small screws using a trim clip remover, flathead screwdriver, and 10mm socket (fasteners vary).
• Peel the liner back enough to clearly see the belt, crank pulley, and belt tensioner.

Step 3: Confirm belt routing

• Use a flashlight and compare what you see to the under-hood routing diagram.
• Take a photo from the wheel well so you can match the routing during install.
• Photo now saves a lot of frustration later.

Step 4: Release belt tension

• Fit a 14mm socket and ratchet (or a 14mm box-end wrench) onto the belt tensioner’s hex.
• Rotate the tensioner smoothly to relieve belt tension (it’s spring-loaded).
• A serpentine belt tool (specialty) is a thin, long handle made for tight belt tensioner access.

Step 5: Remove the old belt

• While holding the tensioner released with the 14mm socket and ratchet, slip the belt off the easiest-to-reach upper pulley.
• Slowly let the tensioner return to its stop (don’t let it snap back).
• Remove the belt from the remaining pulleys by hand.

Step 6: Inspect pulleys and tensioner

• Spin each pulley by hand and listen/feel for roughness or wobble.
• Check the tensioner movement by rotating it with the 14mm socket—it should move smoothly and return firmly.
• If you hear grinding or see wobble, stop and tell me which pulley it is (alternator, A/C, idler/tensioner).

Step 7: Install the new belt

• Route the new belt around the pulleys exactly as shown on the routing diagram (your 3’s belt drives the alternator and A/C).
• Make sure the belt ribs sit fully in the ribbed pulley grooves and the belt sits centered on smooth pulleys.
• Leave the easiest-to-reach pulley for last.

Step 8: Apply tension and verify belt seating

• Rotate the tensioner again with the 14mm socket and ratchet to relieve tension.
• Slip the belt onto the final pulley, then slowly release the tensioner.
• Re-check every pulley: the belt should be fully seated (no rib hanging off an edge).

Step 9: Reassemble and torque the wheel

• Reinstall the splash shield/liner using the trim clip remover, flathead screwdriver, and 10mm socket.
• Reinstall the wheel and hand-tighten lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 108-118 Nm (80-87 ft-lbs).

Step 10: Reconnect battery (if disconnected)

• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• Start the engine and watch the belt for 20-30 seconds—it should run smooth and centered with no wandering.
• Turn A/C on and off and listen for squeal or chirping.
• Shut the engine off and do one final visual check that the ribs are still seated correctly.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $25-$65 (parts only)

You Save: $115-$295 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
