🔧 Grand Cherokee - Serpentine Belt Replacement

The serpentine belt drives key accessories (like the alternator and A/C). If it’s cracked, glazed, squealing, or you see ribs missing, it’s time to replace it to avoid a breakdown.

Difficulty Level: Intermediate | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from hot parts.
• ⚠️ Key out of the vehicle so the engine can’t start unexpectedly.
• ⚠️ Keep fingers clear of the belt and pulleys while releasing the tensioner (it snaps back hard).
• ⚠️ If you raise the front end, support it with jack stands (never rely on a jack alone).

---

🔧 Required Tools

You'll need the following tools for this repair:

• 15mm socket
• 3/8" drive ratchet
• 3/8" drive breaker bar (18"-24")
• Serpentine belt tool (specialty)
• Flashlight
• Trim clip tool
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the hood and locate the belt routing diagram (usually on a sticker in the engine bay). If it’s missing, take a clear photo of the belt routing before removal.
• If you need more access, chock the rear wheels, raise the front with a floor jack, and set it on jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm belt routing

• Use a flashlight to find the routing sticker, then compare it to what you see on the engine.
• Take a photo before touching anything.

Step 2: Relieve tension from the belt tensioner

• Install a 15mm socket on a 3/8" drive breaker bar (or use a serpentine belt tool (specialty)).
• Place the tool on the automatic belt tensioner bolt head (the spring-loaded pulley assembly).
• Rotate the tensioner smoothly to relieve belt tension. (The “tensioner” is a spring-loaded arm that keeps the belt tight.)

Step 3: Remove the old belt

• While holding the tensioner rotated with the breaker bar, slip the belt off the easiest-to-reach smooth pulley (often an idler pulley) by hand with mechanic gloves.
• Slowly release the tensioner back to its resting position (don’t let it snap).
• Pull the belt out of the engine bay.

Step 4: Inspect pulleys before installing the new belt

• Use a flashlight to inspect all pulleys for wobble, heavy rust, cracks, or rubber buildup.
• Spin the idler/tensioner pulleys by hand: they should spin smoothly and quietly (no grinding sound).

Step 5: Route the new belt

• Route the new belt following the under-hood diagram (or your photo).
• Make sure the ribbed side of the belt sits fully inside ribbed pulleys, and the smooth side rides on smooth pulleys.
• Leave the easiest pulley for last (so you can slip it on after releasing tension).

Step 6: Apply tension and seat the belt

• Rotate the tensioner again using the 15mm socket and breaker bar.
• Slip the belt fully onto the last pulley by hand.
• Slowly release the tensioner.
• Visually check every pulley: the belt must be centered and fully seated in every groove.

---

✅ After Repair

• Double-check belt alignment with a flashlight before starting the engine.
• Start the engine and watch the belt for 15–30 seconds: it should run straight with no hopping or wandering.
• Listen for chirping/squealing. If you hear it, shut off and re-check routing and pulley seating.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $40-$90 (parts only)

You Save: $140-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
