🔧 Altima - Serpentine Belt Replacement

The serpentine belt drives accessories like the alternator and A/C. If it’s cracked, squealing, or slipping, replacing it prevents charging problems and overheating.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; hot parts can burn you.
• ⚠️ Support the car on jack stands; never rely on a jack alone.
• ⚠️ Keep fingers clear of the belt and pulleys while releasing the tensioner.
• ⚠️ No battery disconnect is required, but keep the key off and don’t start the engine during the work.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 14mm combination wrench
• Flat trim clip remover
• 10mm socket
• 3/8" drive ratchet
• Torque wrench (20-150 ft-lbs)
• Safety glasses
• Mechanic gloves
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and locate the belt routing decal. If you don’t see one, take a clear photo of the current belt routing before removal. This prevents misrouting.
• Plan access: on your Altima, it’s typically easiest through the passenger-side wheel well after removing the splash shield/liner fasteners.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front passenger side

• Use wheel chocks at the rear wheels.
• Break the lug nuts loose with a 21mm socket and 1/2" breaker bar (just loosen, don’t remove yet).
• Lift the passenger-front jack point using a floor jack, then support the car with jack stands.
• Remove the wheel using the 21mm socket.
• Reinstall lug nuts later and Torque to 113 Nm (83 ft-lbs).

Step 2: Remove the passenger-side splash shield/liner access

• Use a flat trim clip remover to pop out the plastic clips holding the front portion of the fender liner/undercover.
• Remove any small bolts with a 10mm socket and 3/8" ratchet.
• Pull the liner/cover back enough to clearly see the belt and the belt tensioner.

Step 3: Confirm belt routing before removal

• Use a flashlight and take a final photo of the belt routing.
• If a routing decal is present under the hood, match what you see to the decal.

Step 4: Release belt tension (tensioner)

• Find the belt tensioner (it’s a spring-loaded arm that keeps the belt tight).
• Place a 14mm combination wrench on the tensioner’s hex and rotate the tensioner to relieve tension.
• While holding the tensioner back, slide the belt off a smooth pulley (usually an idler) using your free hand.
• Slowly return the tensioner to its resting position. Don’t let it snap back.

Step 5: Remove the old belt

• Pull the belt out through the wheel well opening.
• Spin each pulley by hand and feel for roughness or wobble (alternator, idlers, and tensioner pulley). If any pulley feels gritty or loose, stop and tell me what you found.

Step 6: Install the new belt

• Route the new belt following the under-hood decal or your photo.
• Make sure the belt ribs sit fully in the ribbed pulleys (no ribs hanging off the edge).
• Leave one easy-to-reach pulley for last (typically a smooth pulley).

Step 7: Apply tension and verify belt seating

• Rotate the tensioner again using the 14mm combination wrench.
• Slip the belt onto the last pulley, then slowly release the tensioner.
• Use a flashlight to verify the belt is centered on every pulley and fully seated in the grooves.

Step 8: Reinstall splash shield/liner and wheel

• Reposition the liner/undercover and reinstall bolts with the 10mm socket and 3/8" ratchet.
• Reinstall all plastic clips using the flat trim clip remover to align holes, then push clips in by hand.
• Reinstall the wheel and snug lug nuts with the 21mm socket.
• Lower the car, then Torque to 113 Nm (83 ft-lbs) using a torque wrench in a star pattern.

---

✅ After Repair

• Start the engine and let it idle for 30-60 seconds while you watch the belt track (it should run smoothly without wandering).
• Listen for squealing, chirping, or slapping noises. If you hear any, shut it off and re-check pulley alignment and belt routing.
• After a short test drive, do a quick visual re-check through the wheel well opening to confirm the belt is still centered.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $25-$60 (parts only)

You Save: $155-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
