🔧 Lancer - Serpentine Belt Replacement

Your A/C compressor and alternator are driven by the serpentine belt. Replacing it restores proper charging and A/C operation and prevents a sudden breakdown if the old belt is cracked or slipping.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from fans and pulleys.
• ⚠️ Support the car with jack stands; never rely on a floor jack alone.
• ⚠️ Keep fingers clear when releasing the tensioner—spring force can snap back.
• ⚠️ Battery disconnect is not required, but keep tools away from the alternator’s electrical terminal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm lug nut socket
• Breaker bar 1/2" drive
• Ratchet 3/8" drive
• 10mm socket
• 12mm socket
• 14mm socket
• 14mm combination wrench
• Trim clip remover tool
• Flashlight
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Serpentine belt tensioner - Qty: 1 (optional, if noisy/weak)
• Idler pulley - Qty: 1 (optional, if noisy/rough)
• Plastic splash shield clips - Qty: 2-6 (optional, if any break)

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Open the hood and find the belt routing diagram (usually on a sticker near the radiator support). If it’s missing, take a clear photo of the current belt routing before removal.
• Gather your tools and a flashlight—this job is easier with good visibility.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front-right corner

• Use a 21mm lug nut socket and breaker bar to crack loose the front-right wheel lug nuts about 1/2 turn.
• Lift the front-right corner with a floor jack (rated 2-ton minimum).
• Set the car onto a jack stands (rated 2-ton minimum) at a safe lift point.
• Remove the wheel with the 21mm lug nut socket.
• When reinstalling later: Torque to 120 Nm (88 ft-lbs).

Step 2: Remove the right-side lower splash shield

• Use a trim clip remover tool to pop out plastic clips.
• Use a 10mm socket (and 12mm socket if equipped) with a ratchet 3/8" drive to remove shield bolts.
• Pull the shield back enough to see the belt, crank pulley, and tensioner.
• Tip: Put clips/bolts in a cup.

Step 3: Relieve belt tension (spring-loaded tensioner)

• Locate the belt tensioner (a spring-loaded arm with a pulley). A tensioner is a self-adjusting pulley assembly that keeps the belt tight.
• Place a 14mm socket on the tensioner’s hex/bolt head and attach the breaker bar 1/2" drive.
• Rotate the tensioner smoothly to relieve belt tension (you’ll feel the spring load).
• While holding tension off, slide the belt off the easiest-to-reach pulley (often the alternator or A/C pulley).
• Slowly return the tensioner to its resting position—do not let it snap back.

Step 4: Remove the old belt and inspect pulleys

• Pull the belt out through the wheel well.
• Spin each pulley by hand (alternator, idler, tensioner, A/C). They should spin smoothly and quietly.
• If a pulley feels rough, wobbles, or squeals, plan to replace that pulley or the tensioner assembly.

Step 5: Route the new belt correctly

• Compare the new belt to the old one for length and rib count.
• Route the new belt following the under-hood routing diagram.
• Make sure the ribs sit fully in the grooved pulleys and the belt sits centered on any smooth pulleys.
• Tip: Leave the easiest pulley for last.

Step 6: Apply tension and seat the belt

• Use the 14mm socket and breaker bar 1/2" drive to rotate the tensioner again.
• Slip the belt onto the final pulley.
• Slowly release the tensioner to tighten the belt.
• Double-check alignment: the belt must be fully seated in every groove (no “one rib off”).

Step 7: Reinstall splash shield and wheel

• Reposition the splash shield and install bolts with a 10mm socket (and 12mm socket if equipped) using a ratchet 3/8" drive.
• Install clips with the trim clip remover tool (use it to press pins in straight).
• Reinstall the wheel and snug lug nuts with the 21mm lug nut socket.
• Lower the car with the floor jack (rated 2-ton minimum) and remove the jack stands (rated 2-ton minimum).
• Final-tighten lug nuts in a star pattern: Torque to 120 Nm (88 ft-lbs).

---

✅ After Repair

• Start the engine and watch the belt for 15–30 seconds—it should track smoothly with no wobble.
• Listen for chirping/squealing. If present, shut off and re-check belt seating on every pulley.
• Turn on A/C and headlights to load the system; confirm no belt slip noise.
• Recheck the splash shield is secure and not rubbing the belt area.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $25-$70 (parts only)

You Save: $110-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
