🔧 CR-V - Serpentine Belt Replacement

The serpentine belt drives key accessories like the alternator, A/C compressor, and power steering pump. Replacing it is mostly about safely accessing the belt, relieving tension with the automatic tensioner, and routing the new belt correctly.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from fans and pulleys.
• ⚠️ Support your CR-V with jack stands; never rely on a floor jack alone.
• ⚠️ Keep fingers clear when releasing the belt tensioner—spring force is strong.
• ⚠️ Battery disconnect is not required, but removing the negative terminal reduces accidental short risk near the alternator.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (pair, rated 2-ton minimum)
• Wheel chocks
• 19mm lug nut socket
• 1/2" drive breaker bar (18" minimum)
• 14mm shallow socket
• 1/2" drive ratchet
• 6" socket extension
• Trim clip removal tool
• 10mm socket
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt (accessory drive belt) - Qty: 1
• RH fender liner / splash shield clips - Qty: 1 set (as needed)

---

📋 Before You Begin

• Park on level ground, shift to Park, set the parking brake, and install wheel chocks behind the rear wheels.
• Turn the steering wheel slightly left to improve right wheel-well access.
• Take a quick photo of belt routing.
• If you choose to disconnect the battery: use a 10mm socket to remove the negative terminal and tuck it aside.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the right-front wheel

• Use a 19mm lug nut socket and breaker bar to loosen the lug nuts 1/2 turn while the wheel is on the ground.
• Raise the right-front with a floor jack and set the vehicle on jack stands.
• Remove the lug nuts with the 19mm lug nut socket and take the wheel off.
• During reassembly: Torque to 108 N·m (80 ft-lbs).

Step 2: Remove the right-front lower splash shield/fender liner section

• Use a trim clip removal tool to pop the plastic clips out (center pin first, then the body).
• Use a 10mm socket and ratchet to remove any small bolts holding the liner/splash shield section.
• Pull the liner back enough to clearly see the belt and the tensioner pulley.

Step 3: Relieve tension with the automatic belt tensioner

• Locate the belt tensioner pulley (the smooth pulley that pushes on the back side of the belt).
• Install a 14mm shallow socket on a breaker bar (use a 6" extension if it helps reach).
• Place the socket on the tensioner pulley bolt head, then rotate the tensioner clockwise to relieve belt tension.
• Move it slowly—spring tension is strong.

Step 4: Remove the old belt

• While holding the tensioner rotated with the breaker bar, slide the belt off the easiest-to-reach pulley (often the alternator pulley) by hand.
• Slowly let the tensioner return to its resting position (do not let it snap back).
• Pull the belt out through the wheel well.

Step 5: Inspect pulleys and tensioner

• Spin the pulleys by hand (with the belt off). They should spin smoothly and quietly.
• Look for wobble, cracks, or roughness at the tensioner pulley.
• If you see heavy cracking/glazing on the old belt, make sure every pulley groove is clean before installing the new belt.

Step 6: Route and install the new belt

• Route the new belt around the pulleys to match the under-hood belt routing diagram (or your photo).
• Make sure the ribbed side sits fully inside the ribbed pulleys, and the smooth side rides on smooth pulleys.
• Leave one easy pulley for last (again, often the alternator pulley).

Step 7: Apply tension and seat the belt

• Rotate the tensioner clockwise again using the 14mm socket and breaker bar.
• Slip the belt over the last pulley by hand.
• Slowly release the tensioner to apply belt tension.
• Visually confirm the belt is centered on every pulley and fully seated in all grooves.

Step 8: Reinstall splash shield and wheel

• Reposition the liner/splash shield and reinstall fasteners using the 10mm socket and ratchet.
• Reinstall clips using the trim clip removal tool (press clip body in, then press center pin flush).
• Reinstall the wheel and hand-tighten lug nuts with the 19mm lug nut socket.
• Lower the vehicle, then Torque to 108 N·m (80 ft-lbs) in a star pattern using the 19mm lug nut socket.

---

✅ After Repair

• Start the engine and watch the belt for 20–30 seconds; it should run straight with no wandering.
• Turn A/C on and rotate steering wheel lock-to-lock; listen for squeal.
• Shut the engine off and do a final visual check that the belt ribs are still seated correctly.
• If you disconnected the battery, reconnect the negative terminal using a 10mm socket.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $25-$65 (parts only)

You Save: $115-$325 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
