🔧 Grand Caravan - Serpentine Belt Replacement

The serpentine belt drives accessories like the alternator, A/C compressor, and power steering pump. If it’s cracked, glazed (shiny), squealing, or you see missing ribs, it’s time to replace it to avoid a breakdown.

Difficulty Level: Intermediate | Estimated Time: 0.5-1.5 hours

---

⚠️ Safety & Precautions

• 🧯 Work on a cool engine; hot pulleys and coolant hoses can burn.
• 🧤 Keep fingers and tools away from pulleys; never work with the engine running.
• 🛑 Support the van with jack stands; never rely on a floor jack alone.
• 🔌 Battery disconnect is not required, but keep the key away from the vehicle so no one starts it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• 19mm socket
• 1/2" drive breaker bar
• 15mm socket
• 3" socket extension
• 10mm socket
• Trim clip remover
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Serpentine belt tensioner - Qty: 1 Optional if noisy/weak
• Idler pulley - Qty: 1 Optional if noisy
• Splash shield push clips - Qty: 3-8 Optional if any break

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Look for the belt routing diagram sticker (often on the radiator support/upper core support). If it’s missing, take a clear photo of the current belt routing before removal.
• “Tensioner” is a spring-loaded arm that keeps belt tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the right-front corner and remove the wheel

• Use a 19mm socket to slightly loosen the right-front lug nuts (about 1 turn) while the van is on the ground.
• Lift the right-front with a floor jack (rated 3-ton minimum) at the proper jacking point.
• Set the van securely on jack stands (rated 3-ton minimum).
• Remove the lug nuts with the 19mm socket and take the wheel off.

Step 2: Remove the right-front splash shield (inner fender access)

• Use a trim clip remover to pop out the plastic push clips.
• Use a 10mm socket to remove any small bolts holding the splash shield.
• Pull the splash shield back enough to clearly see the belt and tensioner.
• Set clips in a cup so they don’t vanish.

Step 3: Locate the belt tensioner and unload belt tension

• Locate the belt tensioner pulley (a smooth pulley on a spring-loaded arm).
• Install a 15mm socket on the tensioner bolt.
• Attach a 1/2" drive breaker bar (use a 3" socket extension if needed for reach).
• Rotate the tensioner to relieve belt tension, then slide the belt off one easy-to-reach pulley (usually an upper smooth pulley).
• Move the tensioner slowly; it’s strong.

Step 4: Remove the old belt

• With tension released and the belt off one pulley, carefully let the tensioner return to its rest position.
• Remove the belt from the remaining pulleys by hand.
• Use a flashlight to check each pulley for wobble, cracks, or rubber buildup.
• Spin pulleys by hand (engine OFF). If any pulley feels rough or sounds gritty, plan to replace that pulley/tensioner.

Step 5: Route the new belt correctly

• Compare the new belt to the old belt for length and rib count.
• Route the new belt around the pulleys using the under-hood routing diagram (or your photo).
• Make sure the ribbed side of the belt sits in the grooved pulleys, and the smooth side rides on smooth pulleys.
• Leave the easiest-to-reach pulley for last (so you can slip it on after unloading the tensioner).

Step 6: Apply tension and install the belt on the last pulley

• Use the 15mm socket and 1/2" drive breaker bar to rotate the tensioner again and create slack.
• Slip the belt fully onto the last pulley, then slowly release the tensioner.
• Visually confirm the belt ribs are centered in every grooved pulley.
• If it’s off one rib, fix it now.

Step 7: Reinstall the splash shield and wheel

• Reposition the splash shield and reinstall fasteners using the 10mm socket and trim clip remover (to seat clips).
• Reinstall the wheel and hand-thread lug nuts.
• Lower the van off the jack stands using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern using the 19mm socket.
• Torque to 135 Nm (100 ft-lbs).

---

✅ After Repair

• Start the engine and watch the belt for 20–30 seconds; it should run smoothly with no wandering.
• Listen for chirping/squealing. If noise remains, recheck routing and pulley condition.
• Turn A/C on and rotate steering wheel (at idle) to confirm normal accessory operation.
• After a short test drive, do a quick recheck that the belt is still seated correctly.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $30-$80 (parts only)

You Save: $150-$270 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.7-1.2 hours.

---
