🔧 Explorer - Serpentine Belt Replacement

The serpentine belt (drive belt) runs your alternator, A/C, and other accessories. Replacing it restores proper grip and prevents squealing, slipping, or a sudden no-charge/overheat situation if the belt fails.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool fully; the radiator fans can turn on unexpectedly.
• ⚠️ Keep fingers, hair, and clothing away from pulleys at all times.
• ⚠️ Support the Explorer with jack stands; never rely on a floor jack alone.
• 🔋 Battery disconnect is not required, but keep the key away from the vehicle so nobody can start it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 19mm socket
• 1/2" drive breaker bar
• 8mm socket
• 10mm socket
• Ratchet (3/8" drive)
• Extension set (3/8" drive)
• 15mm serpentine belt tool (specialty)
• Trim clip removal tool
• Flashlight
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt (accessory drive belt) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels using wheel chocks.
• Open the hood and locate the belt routing diagram (usually on the radiator support/under-hood label). If it’s missing, take a clear photo of the current belt routing before removal.
• A serpentine belt tool is a long handled wrench. It gives leverage in tight spaces.
• The tensioner is a spring-loaded pulley. It keeps the belt tight automatically.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the right-front corner safely

• Use wheel chocks at the rear wheels.
• Use the floor jack at the right-front jacking point and raise the vehicle.
• Place jack stands under a solid support point and lower onto the stands.
• Remove the right-front wheel using a 19mm socket and breaker bar.

Step 2: Remove the right-front splash shield / fender liner access

• Use the trim clip removal tool to pop out plastic push-clips.
• Use an 8mm socket and 10mm socket with a ratchet to remove any small screws/bolts holding the liner/splash shield.
• Pull the liner back enough to clearly see the belt and the belt tensioner.

Step 3: Relieve belt tension

• Position a flashlight so you can see the tensioner clearly.
• Place the 15mm serpentine belt tool (specialty) on the tensioner arm bolt head.
• Rotate the tensioner smoothly to relieve tension (it is spring-loaded and will fight you).
• Move slowly; don’t let it snap back.

Step 4: Remove the old belt

• While holding the tensioner rotated with the 15mm serpentine belt tool (specialty), slip the belt off the easiest-to-reach smooth pulley.
• Slowly release the tensioner back to its rest position.
• Remove the belt from all pulleys and pull it out through the wheel-well opening.

Step 5: Inspect pulleys and tensioner before installing the new belt

• Spin each pulley by hand and feel for roughness or wobble (bad bearings feel gritty or loose).
• Check the tensioner pulley surface for cracks or wobble.
• If you see coolant/oil on the belt path, clean and fix the leak before installing the new belt.

Step 6: Install the new belt using the routing diagram

• Route the new belt around the pulleys exactly as shown on the under-hood routing diagram.
• Make sure the belt ribs sit fully inside the ribbed pulley grooves (misalignment can shred the belt).
• Leave the easiest smooth pulley for last.

Step 7: Apply tension and seat the belt

• Rotate the tensioner again using the 15mm serpentine belt tool (specialty).
• Slip the belt over the last pulley.
• Slowly release the tensioner so it tightens the belt.
• Double-check belt seating on every pulley with a flashlight.

Step 8: Reinstall the splash shield and wheel

• Reposition the liner/splash shield and reinstall hardware using the 8mm socket, 10mm socket, and ratchet.
• Install the wheel using a 19mm socket.
• Lower the vehicle safely using the floor jack and remove the jack stands.
• Tighten wheel lug nuts in a star pattern: Torque to 183 Nm (135 ft-lbs).

---

✅ After Repair

• Start the engine and watch the belt for 30–60 seconds; it should run centered with no wandering.
• Listen for chirping/squealing. If present, shut off and re-check belt routing and seating.
• Turn A/C on and headlights on to load the belt, then re-check for noise.
• After a short test drive, do a final visual check with a flashlight.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $35-$80 (parts only)

You Save: $145-$270 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
