🔧 Highlander - Serpentine Belt Replacement

The serpentine belt drives key engine accessories on your Highlander, including the alternator and A/C compressor. Replacing it involves releasing the automatic belt tensioner, removing the old belt, routing the new belt correctly, and checking that it sits fully in each pulley groove.

Difficulty Level: Beginner to Intermediate | Estimated Time: 0.7-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the vehicle OFF and remove the smart key from the work area.
• ⚠️ Let the engine cool before working near the belt, pulleys, radiator fan, or exhaust parts.
• ⚠️ Keep hands, sleeves, hair, and tools away from the belt area if the engine is running.
• ⚠️ Do not touch orange high-voltage hybrid cables or hybrid system components.
• ⚠️ Disconnecting the 12V battery negative cable is recommended to prevent accidental READY mode.
• ⚠️ Never pry against plastic pulleys or force the belt over pulley edges.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• Ratchet wrench
• 14mm socket
• Long-handle 3/8-inch drive ratchet
• Serpentine belt tool (specialty)
• Flat-blade screwdriver
• Plastic trim clip remover
• Flashlight
• Torque wrench inch-pound
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine drive belt - Qty: 1
• Drive belt tensioner assembly - Qty: 1 if noisy, weak, leaking, or rough
• Idler pulley - Qty: 1 if noisy, wobbly, or rough

---

📋 Before You Begin

• Park your Highlander on level ground and set the parking brake.
• Make sure the vehicle is OFF, not in READY mode.
• Keep the smart key at least 15 feet away from the vehicle.
• Open the hood and let the engine cool.
• A serpentine belt tool is a long, thin wrench used to move the belt tensioner in tight spaces.
• The belt tensioner is a spring-loaded arm that keeps the belt tight automatically.
• Take a clear photo of the belt routing before removal using your phone and a flashlight.
• If disconnecting the 12V battery, use a 10mm socket and ratchet wrench to remove the negative cable first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Upper Engine Cover if Equipped

• Put on safety glasses and nitrile gloves.
• Lift the engine cover straight upward by hand if it is held by rubber grommets.
• If small fasteners are fitted, use a 10mm socket and ratchet wrench to remove them.
• Set the cover aside in a safe place.

Step 2: Remove Any Belt-Area Access Shield

• Use a plastic trim clip remover to remove plastic push clips from the upper radiator or side access shield if they block your view.
• Use a 10mm socket and ratchet wrench to remove any small shield bolts.
• Use a flashlight to inspect the belt path from the top of the engine bay.

Step 3: Record the Belt Routing

• Use a flashlight and take a photo of how the belt wraps around each pulley.
• Look for the belt routing decal under the hood or near the radiator support.
• If the decal is missing, use your photo as your guide for installation.
• Photos prevent routing mistakes.

Step 4: Locate the Automatic Belt Tensioner

• Use a flashlight to find the spring-loaded tensioner pulley on the belt path.
• The tensioner has a pulley and a hex-shaped bolt head at the center or arm area.
• Fit a 14mm socket onto the tensioner bolt head.
• Attach a long-handle 3/8-inch drive ratchet or serpentine belt tool to the socket.

Step 5: Release Belt Tension

• Pull the long-handle 3/8-inch drive ratchet or serpentine belt tool slowly to rotate the tensioner and loosen the belt.
• Do not remove the tensioner bolt. You are only rotating the tensioner arm.
• While holding the tensioner released, slide the belt off the easiest smooth pulley by hand.
• Slowly let the tensioner return to its resting position.
• Move slowly and steadily.

Step 6: Remove the Old Belt

• Pull the old belt out by hand from around the pulleys.
• Use a flashlight to check each pulley groove for rubber pieces, oil, or debris.
• Use shop towels to wipe dirty pulley faces.
• Do not use oil, grease, or belt dressing on the pulleys.

Step 7: Inspect Pulleys and Tensioner

• Spin each accessible pulley by hand.
• A good pulley should spin smoothly without grinding, wobbling, or rough spots.
• Use a flashlight to inspect the tensioner for wobble, misalignment, or fluid leakage.
• If a pulley is noisy or loose, replace it before installing the new belt.

Step 8: Route the New Serpentine Belt

• Compare the serpentine drive belt to the old belt by length and rib count.
• Route the new belt by hand around the lower and rear pulleys first, following your photo or routing decal.
• Make sure the ribbed side of the belt sits in ribbed pulleys.
• Make sure the smooth back side of the belt rides on smooth pulleys.
• Leave one easy-to-reach smooth pulley for last.

Step 9: Seat the Belt and Release the Tensioner

• Use the 14mm socket with the long-handle 3/8-inch drive ratchet or serpentine belt tool to rotate the tensioner again.
• Slide the belt over the last pulley by hand.
• Slowly release the tensioner until it tightens the belt.
• Remove the 14mm socket and tool from the tensioner.

Step 10: Verify Belt Alignment

• Use a flashlight to inspect every pulley.
• Make sure every belt rib is fully seated in the pulley grooves.
• If the belt is one groove off, use the 14mm socket and serpentine belt tool to release tension and reposition it by hand.
• Never start the engine if the belt is crooked or hanging off a pulley.

Step 11: Reinstall Covers and Shields

• Reinstall any removed access shields by hand.
• Use the plastic trim clip remover to line up plastic clips, then press clips in by hand.
• Use a 10mm socket and ratchet wrench to reinstall small shield bolts.
• Tighten small cover bolts with a torque wrench inch-pound to Torque to 5 Nm (44 in-lbs).
• Reinstall the engine cover by pressing it down evenly by hand.

Step 12: Reconnect the 12V Battery if Disconnected

• Use a 10mm socket and ratchet wrench to reconnect the negative 12V battery cable.
• Tighten the terminal nut with a torque wrench inch-pound to Torque to 5.4 Nm (48 in-lbs).
• Make sure the cable terminal does not twist by hand.

---

✅ After Repair

• Start your Highlander and let it idle for 30-60 seconds.
• Watch the belt from a safe distance using a flashlight.
• The belt should run straight, smoothly, and quietly.
• Turn the A/C on and listen for squealing, chirping, or slapping sounds.
• Turn the vehicle OFF and recheck belt alignment after the first short drive.
• If the belt walks off-center, squeals, or shreds, stop driving and inspect pulley alignment and the tensioner.

---

💰 DIY vs Shop Cost

Shop Cost: $140-$280 (parts + labor)

DIY Cost: $25-$75 (parts only)

You Save: $115-$205 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
