🔧 Altima - Serpentine Belt Replacement

The serpentine belt (the single long belt that spins your alternator, A/C, and power steering pump) wears and can crack, squeal, or slip. On your Altima, replacement is mostly about safely accessing the belt and using the spring-loaded tensioner to remove/install it.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• 🧯 Work on a cold engine; keep hands away from fans and pulleys.
• 🧰 Support the car with jack stands; never rely on a floor jack alone.
• 🧤 Keep fingers clear when releasing the tensioner; it snaps back strongly.
• 🔌 Battery disconnect is not required, but remove the key and keep it away from the car.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (pair, rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 14mm combination wrench
• 14mm socket
• 3/8" drive ratchet
• 6" extension (3/8" drive)
• Trim clip removal tool
• Flathead screwdriver
• Torque wrench (10-150 ft-lbs range)
• Work light
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Right front inner fender liner clips - Qty: 4-10
• Serpentine belt tensioner assembly - Qty: 1 Optional if noisy/weak

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• 🧱 Chock the left rear wheel so the car can’t roll.
• 📸 Take a photo of the belt routing before removal (or sketch it).
• 🔦 Identify the belt tensioner: it’s the spring-loaded arm with a pulley.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the right-front wheel lug nuts

• Use a 21mm socket and a 1/2" drive breaker bar to loosen the lug nuts about 1/2 turn while the tire is still on the ground.

Step 2: Raise and support the front-right corner

• Use a floor jack at the front-right jack point and lift the car.
• Place jack stands under a solid support point and lower the car onto them.
• Leave the floor jack lightly touching as a backup (do not support with it).

Step 3: Remove the right-front wheel

• Remove the lug nuts using a 21mm socket and set the wheel aside.

Step 4: Open the right inner fender/splash shield for access

• Use a trim clip removal tool and flathead screwdriver to remove the plastic clips and small fasteners holding the front portion of the inner fender liner.
• Pull the liner back enough to see the belt and pulleys clearly. More access = easier install.

Step 5: Relieve belt tension

• Put a 14mm socket on a 3/8" drive ratchet with a 6" extension, or use a 14mm combination wrench on the tensioner’s hex/bolt point.
• Rotate the tensioner to take tension off the belt (you’ll feel the spring load).
• Breaker bar definition: a long-handled bar used for extra leverage.

Step 6: Remove the old belt

• While holding the tensioner rotated, slide the belt off the easiest pulley to reach (usually an upper smooth pulley).
• Slowly release the tensioner back to its resting position (don’t let it snap).
• Remove the belt from the remaining pulleys and pull it out through the wheel well opening.

Step 7: Inspect pulleys and tensioner

• Spin each pulley by hand; it should spin smoothly and quietly.
• Check for wobble or grinding noises; if present, plan to replace that pulley/tensioner.

Step 8: Install the new belt (route it first)

• Route the new belt around the pulleys following your photo/sketch. Make sure the ribbed side sits in ribbed pulleys and the smooth side sits on smooth pulleys.
• Leave one easy-to-reach pulley for last (so you can slip it on after releasing tension).
• Make sure every rib is seated.

Step 9: Apply tension and seat the belt fully

• Rotate the tensioner again using the 14mm socket on a 3/8" drive ratchet (or 14mm combination wrench).
• Slip the belt onto the last pulley, then slowly release the tensioner.
• Re-check every pulley: the belt must be centered and fully seated in the grooves.

Step 10: Reinstall the inner fender liner

• Reposition the liner and reinstall clips using the trim clip removal tool and flathead screwdriver.

Step 11: Reinstall the wheel and torque lug nuts

• Install the wheel and hand-thread the lug nuts.
• Lower the car, then use a torque wrench with a 21mm socket to tighten in a star pattern: Torque to 113 Nm (83 ft-lbs).

---

✅ After Repair

• 🔎 Start the engine and watch the belt for 15-30 seconds; it should run smooth with no hopping or wandering.
• 👂 Listen for squeal/chirp. If you hear noise, shut off and re-check belt seating on every pulley groove.
• 🧪 Turn on A/C and headlights; confirm no belt slip noise under load.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$380 (parts + labor)

DIY Cost: $25-$70 (parts only)

You Save: $110-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
