🔧 Patriot - Serpentine Belt Replacement

The serpentine belt drives key accessories like the alternator and A/C. Replacing it restores proper grip and helps prevent squealing, charging issues, or an unexpected breakdown if the belt snaps.

Difficulty Level: Intermediate | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from hot parts.
• ⚠️ Keep fingers/clothing clear of pulleys at all times.
• ⚠️ Support the SUV with jack stands; never rely on a floor jack alone.
• ⚠️ Do not start the engine until tools are fully removed.
• Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug wrench (19mm)
• Torque wrench (20-200 ft-lbs range)
• 3/8" drive ratchet
• 3/8" drive breaker bar (18-24")
• 15mm socket
• 3/8" drive extension (6")
• Trim clip removal tool
• Flathead screwdriver
• Flashlight
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1
• Plastic splash shield clips - Qty: 1 set

---

📋 Before You Begin

• Park on level ground, shift to 1st gear, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Take a quick photo of the belt routing under the hood (many Patriots have a routing diagram sticker near the radiator support).
• Tip: Draw the belt path on paper first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and access the belt area

• Use a 19mm lug wrench to loosen the front passenger wheel lug nuts 1/2 turn (don’t remove yet).
• Lift the front passenger side with a floor jack (rated 3-ton minimum).
• Set the SUV securely on jack stands (rated 3-ton minimum).
• Remove the wheel using the 19mm lug wrench.
• Torque to 135 Nm (100 ft-lbs) when reinstalling the lug nuts later using a torque wrench (20-200 ft-lbs range).

Step 2: Remove the lower splash shield/inner fender access

• Use a trim clip removal tool and flathead screwdriver to remove the plastic push-clips/screws holding the splash shield/liner near the belt area.
• Pull the shield/liner back enough to see the belt and the tensioner pulley.
• Tip: Keep clips in a cup.

Step 3: Locate the belt tensioner

• Use a flashlight to identify the belt tensioner (a spring-loaded arm with a smooth pulley).
• The tensioner has a bolt head you can turn to release belt tension.
• Tip: Smooth pulley usually rides on belt’s back.

Step 4: Release tension and remove the old belt

• Place a 15mm socket on a 3/8" drive breaker bar (18-24") (a long handle gives you leverage).
• Fit the socket onto the tensioner bolt head.
• Rotate the tensioner to relieve tension (it will feel springy). Hold it firmly.
• While holding tension off, slide the belt off the easiest-to-reach top pulley (often the alternator) by hand.
• Slowly let the tensioner return to its resting position. Do not let it snap back.
• Remove the belt fully from all pulleys.

Step 5: Inspect pulleys before installing the new belt

• Spin each pulley by hand (alternator, idler/tensioner, A/C, crank). They should spin smoothly and quietly.
• Check the tensioner pulley for wobble. Wobble usually means the pulley/bearing is worn.
• If any pulley is noisy/rough, fix that first or the new belt may fail early.

Step 6: Route the new belt

• Match the new belt length to the old belt (same number of ribs) before installation.
• Route the new belt around the pulleys following the under-hood routing diagram (or your photo).
• Leave one easy-access pulley for last (commonly a smooth idler or alternator).
• Make sure the ribs sit perfectly in the grooved pulleys (no ribs hanging off the edge).
• Tip: Misalignment will shred the belt fast.

Step 7: Re-apply tension and seat the belt

• Use the 15mm socket with the 3/8" drive breaker bar (18-24") to rotate the tensioner again.
• Slip the belt onto the last pulley with your free hand.
• Slowly release the tensioner so it applies tension to the belt.
• Do a final visual check: belt centered on every pulley, ribs aligned, not twisted.

Step 8: Reinstall splash shield and wheel

• Reinstall the splash shield/liner using the trim clip removal tool and flathead screwdriver as needed.
• Reinstall the wheel using the 19mm lug wrench.
• Lower the SUV with the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a torque wrench (20-200 ft-lbs range) to 135 Nm (100 ft-lbs).

---

✅ After Repair

• Start the engine and watch the belt for 30-60 seconds. It should run smoothly with no wandering.
• Listen for chirping/squealing. If you hear it, shut off and re-check belt routing and alignment.
• Turn A/C on and headlights on; confirm no new noises and charging seems normal.
• Recheck visually once more after a short test drive.

---

💰 DIY vs Shop Cost

Shop Cost: $160-$320 (parts + labor)

DIY Cost: $25-$70 (parts only)

You Save: $135-$250 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
