🔧 Rear Window Regulator - Replacement

The rear door window regulator lifts and lowers the glass. If the window is stuck, slow, noisy, or falls inside the door, the regulator assembly may be broken and needs replacement.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Disconnect the 12V battery negative terminal before working inside the door. The hybrid system is not involved, but the power window circuit is.
• Support the glass with tape before removing the regulator so the window does not drop.
• Use care around the side airbag area in the door. Do not probe yellow connectors.
• Keep fingers clear of the window tracks and regulator arms. The mechanism can pinch hard.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm wrench
• Ratchet
• Extension bar
• Trim panel clip tool
• Phillips screwdriver
• Flat trim tool
• Torx T20 screwdriver
• Torque wrench
• Painter's tape
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear door window regulator assembly - Qty: 1 per side
• Rear door vapor barrier adhesive - Qty: 1
• Door panel clip set - Qty: 1 set

---

📋 Before You Begin

• Park on level ground and open the rear door fully.
• Lower the rear window if it still moves. If it is stuck, continue carefully and tape the glass in place.
• Disconnect the 12V battery negative terminal.
• Use Menu > Settings > Vehicle > Power Window Init only if the window auto-up/down function needs relearning after repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a flat trim tool and trim panel clip tool to pop off the switch bezel and visible trim covers.
• Use a Phillips screwdriver and 10mm socket to remove the screws hiding behind the trim pieces and in the pull handle.
• Lift the door panel upward to release it from the door shell.
• Disconnect the window switch connector and any courtesy light connector.

Step 2: Remove the moisture barrier

• Peel back the inner vapor barrier carefully by hand.
• Use a trim tool if needed to avoid tearing the adhesive.
• Keep the barrier clean and sticky.

Step 3: Tape the glass in place

• Raise the window glass to the fully up position if possible.
• Use painter's tape across the top of the door frame and glass to hold it securely.
• If the glass is already down, guide it by hand into the up position before taping.

Step 4: Remove the regulator fasteners

• Use a 10mm socket, ratchet, and extension bar to remove the regulator bolts inside the door.
• Use a Torx T20 screwdriver if any regulator or motor screws are Torx style.
• Remove the fasteners holding the glass clamps and regulator track.
• Torque on installation: 7.5 Nm (66 in-lbs) for the regulator mounting bolts unless your replacement part specifies otherwise.

Step 5: Remove the old regulator assembly

• Lower or maneuver the assembly out through the largest access opening in the door shell.
• If the motor is attached to the regulator, remove the assembly as one unit.
• Watch the glass edges and door latch mechanism as you remove it.

Step 6: Install the new regulator

• Feed the new regulator into the door and line up the mounting points.
• Use the 10mm socket to install the mounting bolts finger-tight first.
• Attach the glass clamps to the window glass carefully.
• Torque to 7.5 Nm (66 in-lbs) for the regulator and glass clamp fasteners unless the part instructions say different.

Step 7: Test window movement before reassembly

• Reconnect the 12V battery negative terminal temporarily.
• Reconnect the window switch and cycle the window up and down.
• Make sure the glass moves straight and does not bind or tilt.
• Disconnect the battery again before final reassembly if you need to adjust the regulator.

Step 8: Reinstall the vapor barrier and door panel

• Press the vapor barrier back into place so water stays out of the door.
• Reconnect all electrical connectors.
• Hang the door panel on the upper lip first, then press the clips back in.
• Reinstall the screws using a Phillips screwdriver and 10mm socket.

---

✅ After Repair

• Reconnect the 12V battery negative terminal fully.
• Cycle the window fully down and fully up several times.
• If auto-up/down does not work, perform window initialization using switch hold-up and hold-down relearn until the function returns.
• Check for wind noise and water leaks around the door panel.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $80-$220 (parts only)

You Save: $270-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
