🔧 Accent - Rear Window Regulator Replacement

You’ll remove the rear door interior trim, secure the glass, then swap the window regulator (the cable-and-rail mechanism that moves the glass). This fixes slow, stuck, crooked, or clicking windows caused by a worn cable, broken guides, or a failing motor.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours (per rear door)

Assumption: your rear door uses a cable-type regulator with a bolted-on motor.

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before unplugging the window motor switch or motor connector.
• ⚠️ Support the window glass before removing regulator bolts; the glass can drop suddenly.
• ⚠️ Wear gloves—inner door metal edges are sharp.
• ⚠️ Do not tear the vapor barrier (the plastic water shield); reseal it to prevent water leaks and speaker damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 6" extension for 1/4" ratchet
• Phillips screwdriver #2
• Flat trim tool
• Hook pick tool
• Needle-nose pliers
• Painter’s tape 1.5"
• Razor blade or plastic scraper
• Torque wrench (inch-pound)
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear window regulator assembly - Qty: 1
• Rear window motor - Qty: 1 (only if not included with regulator)
• Door panel trim clips - Qty: 6-10 (as needed)
• Butyl tape (vapor barrier sealant) - Qty: 1

---

📋 Before You Begin

• Park on level ground and remove the key.
• Lower the rear window until you can access the glass-to-regulator fasteners (if the window still moves).
• Use a 10mm socket to disconnect the negative battery cable and isolate it so it can’t spring back.
• Have painter’s tape ready to secure the glass to the door frame.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a flat trim tool to gently pry up the switch panel, then unplug the connector.
• Use a Phillips screwdriver #2 to remove screws hiding behind the inner handle trim and armrest areas (locations vary by panel).
• Use a flat trim tool to pop the trim clips around the edge. A “trim clip” is a plastic push fastener that snaps into the door.
• Lift the panel straight up to unhook it from the window ledge, then disconnect any remaining cables/connectors using a hook pick tool.

Step 2: Remove and save the vapor barrier

• Use a razor blade or plastic scraper to carefully separate the black butyl (sticky sealant) and peel the plastic water shield back.
• Do not rip it—this barrier keeps rainwater from soaking the door panel.
• Stick it to itself to keep it clean.

Step 3: Secure the glass in the up position

• If the glass is down, manually lift it up (if possible) and secure it to the door frame with painter’s tape 1.5" (run multiple strips over the top of the door).
• If the glass won’t move because the regulator is jammed, you may need to loosen regulator bolts first (next step) and guide the glass by hand.

Step 4: Detach the glass from the regulator

• Through the access holes, use a 10mm socket with a 6" extension to remove the glass clamp/retainer bolts/nuts.
• Once loose, confirm the glass is fully supported by tape before continuing.
• Torque to 8-10 Nm (71-89 in-lbs) on reassembly.

Step 5: Unplug and remove the window motor (if separate)

• Unplug the motor connector by releasing the tab with a hook pick tool.
• Use a 10mm socket to remove the motor bolts.
• Torque to 6-8 Nm (53-71 in-lbs) on reassembly.

Step 6: Remove the regulator assembly

• Use a 10mm socket to remove the regulator mounting bolts from the door inner panel.
• Carefully maneuver the regulator out through the largest opening.
• Torque to 8-10 Nm (71-89 in-lbs) on reassembly.

Step 7: Install the new regulator (and motor if needed)

• Place the new regulator into the door cavity and align it to the bolt holes.
• Start all bolts by hand to avoid cross-threading, then tighten using a 10mm socket.
• If the motor is separate, install it and tighten with a 10mm socket.

Step 8: Reattach the glass to the regulator

• Lower/raise the regulator carrier to align with the glass clamps. If needed, temporarily reconnect the switch and battery to “jog” the motor, then disconnect again before tightening.
• Install the glass clamp bolts/nuts with a 10mm socket.
• Torque to 8-10 Nm (71-89 in-lbs).
• Remove the painter’s tape 1.5" after confirming the glass is secured.

Step 9: Function test before closing the door up

• Reconnect the window switch connector and reconnect the negative battery cable using a 10mm socket.
• Cycle the window fully down and fully up several times and watch for tilting, binding, or cable noise.
• If it’s crooked, loosen the regulator bolts slightly with a 10mm socket, shift the assembly as needed, then re-tighten.

Step 10: Reseal the vapor barrier and reinstall the door panel

• Press the vapor barrier back into the original butyl. Add butyl tape where the seal is missing.
• Reconnect all connectors/cables, then hang the trim panel on the top lip and press clips in by hand.
• Reinstall screws using a Phillips screwdriver #2.
• Reinstall the switch panel using a flat trim tool to snap it in.

---

✅ After Repair

• Verify the window seals evenly at the top and does not leave gaps.
• Confirm the door lock, handle, and speaker work (you may have unplugged them).
• If auto-up/down acts odd: cycle the window fully down, then fully up and hold the switch 2 seconds at the top.
• Check after the next rain or car wash for water leaks inside the door panel area.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$650 (parts + labor, per rear door)

DIY Cost: $80-$220 (parts only, per rear door)

You Save: $220-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
