🔧 Escape - Rear Window Regulator Replacement

The rear window regulator is the track-and-cable (or scissor) mechanism that lifts and lowers the rear door glass. When it fails, the window may drop, bind, move crooked, or the motor may run but the glass won’t move.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours (per door)

---

⚠️ Safety & Precautions

• 🛑 Disconnect the negative battery cable before unplugging the window motor to prevent accidental window movement.
• 🛑 Support the glass with painter’s tape (or wedges) before loosening the glass clamp bolts—glass can drop suddenly.
• 🛑 Wear gloves—door metal edges and regulator cables can be sharp.
• 🛑 Keep fingers clear of the regulator tracks and scissor points during testing.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Plastic trim removal tool set
• 1/4" drive ratchet
• 3" extension (1/4" drive)
• 7mm socket
• 8mm socket
• 10mm socket
• Torx T20 screwdriver
• Phillips screwdriver
• Small flat screwdriver
• Needle-nose pliers
• Painters tape (1.5" wide)
• Razor blade
• Torque wrench (in-lb or Nm)
• Work light

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear window regulator (left or right, as needed) - Qty: 1
• Rear window motor (only if not included with regulator) - Qty: 1
• Door trim panel retainer clips - Qty: 6-10
• Butyl ribbon sealer (vapor barrier adhesive) - Qty: 1

---

📋 Before You Begin

• 🧰 Park on level ground, key OFF, and lower the rear window to about halfway if it still moves.
• 🧰 Disconnect the negative battery cable using a 10mm socket and isolate it so it can’t spring back.
• 🧰 Have painter’s tape ready to secure the glass to the door frame once it’s unclamped.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a plastic trim removal tool to pop up the window switch bezel (if equipped) and unplug the connector.
• Use a Phillips screwdriver or 7mm socket (varies by door) to remove screws hidden in the pull handle and behind small trim covers (pry covers with a small flat screwdriver).
• Use a plastic trim removal tool to pop the panel clips around the perimeter.
• Lift the door panel straight up and off the window ledge, then unplug any remaining connectors.

Step 2: Remove the vapor barrier (water shield)

• Use a razor blade to carefully cut through the butyl adhesive where needed.
• Peel the barrier back slowly and keep it clean so it can be reused.
• Don’t tear it—water leaks start here.

Step 3: Position and secure the window glass

• If the regulator still works, reconnect the switch temporarily, reconnect the battery briefly, and move the glass until the glass-to-regulator clamp bolts are visible in the access holes.
• Disconnect the battery again using the 10mm socket.
• Apply painters tape from the outside of the glass over the top of the door frame (use 2-3 long strips) to hold the glass up once it’s unclamped.

Step 4: Detach the glass from the regulator

• Use an 8mm socket to loosen (do not fully remove) the glass clamp bolts/nuts.
• Slide the glass upward by hand until fully up, then add more painters tape to secure it.
• Torque to 8 Nm (71 in-lbs) when tightening these clamp fasteners during reassembly.

Step 5: Unplug the window motor (power windows)

• Use needle-nose pliers or your fingers to release the connector lock tab, then unplug the motor.
• If your regulator comes with a motor, you’ll swap the whole assembly; if not, you’ll transfer the motor in a later step.

Step 6: Remove the regulator assembly

• Use a 10mm socket with a 3" extension to remove the regulator mounting bolts.
• Support the regulator as you remove the last bolt, then maneuver it out through the large door opening.
• Torque to 10 Nm (89 in-lbs) for regulator mounting bolts during reassembly.

Step 7: Transfer the motor (only if your new regulator doesn’t include one)

• Use a Torx T20 screwdriver to remove the motor screws from the old regulator.
• Install the motor onto the new regulator and snug the screws evenly.
• Torque to 4 Nm (35 in-lbs) for motor screws.
• Keep the motor seated flat—no gaps.

Step 8: Install the new regulator

• Feed the new regulator into the door cavity the same way the old one came out.
• Start all mounting bolts by hand first, then tighten using a 10mm socket.
• Torque to 10 Nm (89 in-lbs) for regulator mounting bolts.
• Plug in the window motor connector until it clicks.

Step 9: Reattach the glass to the regulator

• Remove some tape so the glass can lower slightly while still supported.
• Carefully lower the glass into the regulator clamps (you may need to nudge the regulator position by loosening its bolts slightly, then retighten).
• Tighten the clamp fasteners with an 8mm socket.
• Torque to 8 Nm (71 in-lbs) for glass clamp fasteners.

Step 10: Test the window before reassembly

• Reconnect the negative battery cable using a 10mm socket.
• Plug in the switch and cycle the window fully down and fully up 3 times.
• Watch for smooth movement and listen for clicking (cable misroute) or grinding (track bind).
• Disconnect the battery again using the 10mm socket before reinstalling trim.

Step 11: Reinstall the vapor barrier and door panel

• Press the vapor barrier back into place; add butyl ribbon sealer anywhere the adhesive is missing.
• Reconnect all electrical connectors.
• Hang the panel on the top window ledge, then press clips in around the perimeter by hand.
• Reinstall screws using a 7mm socket or Phillips screwdriver.
• Torque to 2 Nm (18 in-lbs) for door trim screws.

---

✅ After Repair

• 🧪 Reconnect the battery (use a 10mm socket) and verify the window works from both the rear switch and driver master switch.
• 🧪 Confirm the door locks, speaker, and any door-ajar function work (if equipped).
• 🧪 Check that the vapor barrier is fully sealed to help prevent wet carpets.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $85-$220 (parts only)

You Save: $265-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
