🔧 Rear Door Lock Actuator - Replacement

On your Rogue, the rear door lock actuator is built into the latch assembly inside the door. This repair means removing the door trim panel, disconnecting the latch rod and connectors, then swapping the actuator/latch assembly. If the lock is sticking, this usually fixes hard locking, no-unlock, or keyless entry problems.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before unplugging door wiring.
• Use care with the side-impact airbag area in the door. Do not probe yellow connectors.
• The door panel clips can break if pried too hard. Work slowly.
• Support the door panel when removing the last fasteners so it does not fall.
• Keep glass fully raised during the repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim panel removal tool
• Phillips screwdriver
• 10mm socket
• Ratchet
• Extension bar
• Small flat-blade screwdriver
• Needle-nose pliers
• Torque wrench
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear door lock actuator assembly - Qty: 1
• Door panel clip set - Qty: 1
• Plastic vapor barrier adhesive - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Lower the rear window slightly if needed for access, then raise it fully before removing the panel.
• Disconnect the negative battery cable and wait 3 minutes before touching door connectors.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use the trim panel removal tool to pry off the small trim covers around the inner door handle and armrest.
• Use the Phillips screwdriver and 10mm socket to remove the visible screws.
• Use the trim panel removal tool to pop the retaining clips around the edge of the door panel.
• Lift the panel upward to unhook it from the window ledge.

Step 2: Disconnect the wiring and cables

• Unplug the electrical connectors from the switch panel using your fingers.
• Release the inner handle cable from the panel and set the trim panel aside.
• Do not force the connectors.

Step 3: Remove the vapor barrier

• Carefully peel back the vapor barrier from the door shell.
• Use the small flat-blade screwdriver only if you need to lift adhesive edges.
• Keep the barrier clean so it can be resealed later.

Step 4: Disconnect the latch and actuator hardware

• Use the small flat-blade screwdriver and needle-nose pliers to release the lock rod retainers.
• Disconnect the electrical connector from the actuator.
• Remove the latch mounting bolts with the 10mm socket.
• Torque on installation: Torque to factory specification.

Step 5: Remove and replace the actuator assembly

• Slide the actuator/latch assembly out of the door opening.
• Transfer any linkage clips or rods to the new actuator assembly if needed.
• Install the new assembly in the same position as the old one.

Step 6: Reinstall and secure everything

• Reconnect the electrical connector and all lock rods.
• Install the latch bolts with the 10mm socket and torque to factory specification.
• Press the vapor barrier back into place using the original adhesive or new adhesive.
• Reconnect the door panel wiring, then hang the trim panel on the window ledge and press the clips in place.
• Reinstall the screws and trim covers with the Phillips screwdriver.

---

✅ After Repair

• Reconnect the negative battery cable.
• Test the lock and unlock function from the inside switch, key fob, and outside handle.
• Check that the door opens normally from inside and outside.
• Make sure the door panel does not rattle and the window operates normally.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $70-$180 (parts only)

You Save: $180-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3 hours.

---
