🔧 HR-V - Radiator Hose Replacement

Replacing a radiator hose means removing the old coolant hose and clamps, installing the new hose, then refilling and bleeding the cooling system. This is usually done because the hose is leaking, swollen/soft, cracked, or the clamp area is weeping coolant.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the radiator cap on a hot engine; hot coolant can spray and burn you.
• ⚠️ Support your HR-V with jack stands before working underneath.
• ⚠️ Coolant is toxic; keep it off skin and away from pets and kids.
• ⚠️ Clean spills immediately; coolant is slippery.
• 🔋 Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 2-gallon)
• Flat-blade screwdriver
• Phillips screwdriver
• 10mm socket
• 3/8" drive ratchet
• 6" extension (3/8" drive)
• Hose clamp pliers (specialty)
• Slip-joint pliers
• Pick tool (small)
• Funnel
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2
• Honda-approved coolant (premixed) - Qty: 1-2 gallons

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and chock the rear wheels.
• 🌡️ Let the engine cool completely (ideally 2+ hours).
• 🧰 If you’re replacing the lower hose, plan to raise the front of your HR-V for access.
• 🧪 Identify the hose you’re replacing: upper hose goes to the top of the radiator; lower hose goes to the bottom of the radiator.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve cooling system pressure (when cold)

• Put on safety glasses and nitrile gloves.
• Place shop rags around the radiator cap area.
• Slowly loosen the radiator cap by hand to the first stop, then remove it fully once you confirm there’s no pressure.

Step 2: Raise the front (recommended for lower hose)

• Use a floor jack (rated 2-ton minimum) to lift the front safely at the front center jack point.
• Set the vehicle onto jack stands (rated 2-ton minimum).
• Keep wheel chocks in place.

Step 3: Remove the lower engine cover (if equipped)

• Use a 10mm socket, 3/8" drive ratchet, and 6" extension to remove the bolts.
• Use a flat-blade screwdriver or Phillips screwdriver to remove any push clips (turn gently to avoid breaking them).

Step 4: Drain coolant to below the hose level

• Place a drain pan (at least 2-gallon) under the radiator drain area.
• Open the radiator drain cock using a flat-blade screwdriver (turn slowly) and drain enough coolant so the radiator level is below the hose you’re replacing.
• Close the drain cock with the flat-blade screwdriver once done (snug; do not overtighten).

Step 5: Remove the hose clamps

• Use hose clamp pliers (specialty) to squeeze the spring clamp and slide it back on the hose. (Hose clamp pliers are pliers that lock and hold a spring clamp open.)
• If access is tight, use slip-joint pliers instead, but go slow to avoid slipping.

Step 6: Remove the old radiator hose

• Twist the hose by hand to break it loose.
• If it’s stuck, gently work the edge with a pick tool (small) to separate the hose from the neck.
• Pull the hose off and aim it into the drain pan (at least 2-gallon) to catch remaining coolant.
• Don’t pry hard on plastic necks.

Step 7: Prep the fittings and install the new hose

• Wipe the radiator neck and engine-side fitting using shop rags.
• Slide the clamps onto the new hose (use hose clamp pliers (specialty)).
• Push the new hose on fully until it seats against the stop/bead.
• Reposition the clamps to the same spot as original, centered over the sealing area.

Step 8: Reassemble access panels

• Reinstall the lower engine cover using the 10mm socket, 3/8" drive ratchet, and 6" extension.
• Reinstall push clips using the flat-blade screwdriver or Phillips screwdriver.

Step 9: Refill coolant

• Use a funnel to refill the radiator with Honda-approved coolant (premixed).
• Fill the coolant reservoir to the MAX line.

Step 10: Bleed air from the cooling system

• Start the engine and set the heat to HOT (this opens the heater circuit).
• Let the engine idle while watching the coolant level at the radiator fill neck; add coolant as the level drops using the funnel.
• Once the radiator fan cycles on and off at least once, reinstall the radiator cap by hand.
• Shut the engine off and let it cool полностью, then recheck the reservoir and top off to MAX.

---

✅ After Repair

• 🔎 With the engine running, inspect both ends of the replaced hose for seepage.
• 🧻 Look for dried coolant trails after a short drive; recheck clamp position.
• 🌡️ Confirm the temperature gauge stays normal and the heater blows hot.
• 🧪 Recheck coolant level the next morning (cold) and top off the reservoir if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $210-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
