🔧 XT4 - Radiator Hose Replacement

Replacing a radiator hose fixes coolant leaks and prevents overheating. On your XT4, the job is mainly about safely draining some coolant, swapping the hose and clamps, then refilling and checking for leaks.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

Two quick questions (so I can tailor the steps exactly): 1) Are you replacing the upper hose (top of radiator) or lower hose (bottom of radiator)? 2) Is your hose using spring clamps (squeeze-style) or worm-gear clamps (screw-style)?

---

⚠️ Safety & Precautions

• ⚠️ Never open the cooling system hot; let the engine cool fully (at least 1–2 hours).
• ⚠️ Coolant is toxic—keep it away from kids/pets and clean spills immediately.
• ⚠️ Use jack stands if you lift the front—never rely on a floor jack alone.
• ⚠️ Avoid fingers near the radiator fan; it can start unexpectedly.
• Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 10mm socket
• Ratchet (3/8" drive)
• 6" extension (3/8" drive)
• Flat trim clip removal tool
• Hose clamp pliers
• Pick tool
• 7mm nut driver
• Funnel with long neck
• Shop rags
• Work light

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2
• DEX-COOL coolant (concentrate or pre-mix) - Qty: 1-2 gallons
• Distilled water - Qty: 1 gallon

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Let the engine cool completely before touching any hose.
• Locate the surge tank (the pressurized coolant reservoir) and the hose you’re replacing.
• Place a drain pan under the front of the vehicle before loosening anything.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve pressure safely

• Use shop rags to cover the surge tank cap, then slowly loosen it to release any leftover pressure.
• If you hear strong hissing, retighten and wait longer for it to cool.

Step 2: Raise the front (if needed for lower hose access)

• Use a floor jack (rated 3-ton minimum) to lift the front at the approved front lift point.
• Support it with jack stands (rated 3-ton minimum) before you go underneath.

Step 3: Remove the lower splash shield (if it blocks access)

• Use a 10mm socket, ratchet (3/8" drive), and 6" extension (3/8" drive) to remove the fasteners.
• Use a flat trim clip removal tool to pop any plastic push-clips without breaking them.

Step 4: Drain enough coolant to get the hose off cleanly

• Position the drain pan (at least 10-quart) under the radiator lower area.
• Slowly loosen the hose end you’re replacing and let coolant drain into the pan.
• Tip: draining less saves refill time.

Step 5: Remove the hose clamps

• If you have spring clamps: use hose clamp pliers to squeeze the clamp and slide it back on the hose.
• If you have worm-gear clamps: use a 7mm nut driver to loosen the clamp and slide it back.

Step 6: Break the hose free (don’t pry on plastic)

• Twist the hose by hand to break the seal, then pull it off.
• If it’s stuck, use a pick tool to gently lift the edge of the hose to let air in, then twist again.
• Do not pry hard against radiator necks or plastic fittings—they can crack.

Step 7: Prep the fittings and compare parts

• Use shop rags to wipe the radiator/engine nipples clean.
• Compare the new hose to the old hose (length, bends, and end shape) before installing.

Step 8: Install the new radiator hose

• Slide the clamp(s) onto the hose first.
• Push the hose fully onto each fitting until it bottoms out.
• Reposition the clamp into the original clamp “track” mark on the hose.
• For worm-gear clamps, tighten with a 7mm nut driver until snug—do not crush the fitting.

Step 9: Reinstall the splash shield

• Use the flat trim clip removal tool to align clips, then reinstall fasteners with a 10mm socket and ratchet (3/8" drive).

Step 10: Refill coolant

• Use a funnel with long neck to refill the surge tank.
• If using concentrate, mix DEX-COOL coolant with distilled water to a 50/50 blend before filling.
• Fill to the correct level line on the surge tank.

Step 11: Bleed air and check for leaks

• Start the engine and set the cabin heat to MAX HEAT (this helps coolant circulate through the heater core).
• Let it idle and watch the temperature gauge while you inspect the hose ends with a work light.
• As the engine warms up, coolant level may drop—top off using the funnel with long neck.
• Shut the engine off, let it cool, then recheck level and add as needed.

---

✅ After Repair

• Test drive 10–15 minutes, then park and check for leaks with a work light.
• After a full cool-down, recheck the surge tank level and top off if needed.
• Verify the heater blows hot and the temperature gauge stays normal.
• Dispose of old coolant properly (many parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $40-$160 (parts only)

You Save: $210-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
