🔧 Power Steering Pump - Replacement

On your XC60, the power steering pump is belt-driven and uses hydraulic fluid. Replacing the pump means relieving belt tension, removing the drive belt, disconnecting the hydraulic lines, and transferring or replacing the pulley if needed.

Difficulty Level: Advanced | Estimated Time: 3-5 hours

---

⚠️ Safety & Precautions

• This repair is for the hydraulic power steering pump, not an electric steering motor.
• Disconnect the negative battery cable before starting.
• Keep fingers clear of the serpentine belt and pulleys when releasing tension.
• Hydraulic fluid may be hot or under pressure; wear gloves and safety glasses.
• Prevent dirt from entering the steering lines or pump openings.
• Do not run the engine with the belt removed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• 14mm socket
• 15mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Serpentine belt tool
• Drain pan
• Shop rags
• Funnel
• Jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Power steering pump - Qty: 1
• Power steering pump pulley - Qty: 1
• Power steering pressure hose seal set - Qty: 1
• Power steering return hose seal set - Qty: 1
• Power steering fluid - Qty: 1-2 quarts
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the wheels.
• Let the engine cool completely.
• Disconnect the negative battery cable with a 10mm socket.
• Raise the front of the vehicle with a jack and support it with jack stands.
• Remove the right front wheel if needed for access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove access shields

• Use a 10mm socket and 13mm socket to remove the lower splash shields or side access panels blocking the belt and pump area.
• Set all fasteners aside in order.

Step 2: Release belt tension

• Use a serpentine belt tool or breaker bar on the belt tensioner.
• Rotate the tensioner to unload the belt, then slip the belt off the power steering pump pulley.
• Take a photo of the belt routing first.

Step 3: Remove the serpentine belt

• Slowly release the tensioner with the breaker bar.
• Remove the belt from the pulleys and inspect it for cracks or glazing.
• If worn, replace it now.

Step 4: Drain the power steering fluid

• Place a drain pan under the pump and hoses.
• Use a 13mm socket or 14mm socket for the pressure line fitting if equipped with a bolt-style connection.
• Loosen the return hose clamp and drain the fluid into the pan.

Step 5: Disconnect the steering lines

• Use a 13mm socket, 14mm socket, or the correct line wrench size if the fitting design requires it.
• Remove the pressure line and return hose from the pump.
• Cap or plug the open lines immediately to keep dirt out.

Step 6: Remove the pump mounting bolts

• Use a 14mm socket and ratchet to remove the pump mounting bolts.
• Support the pump with your hand as you remove the last bolt.
• Lift the pump out of the engine bay.

Step 7: Transfer the pulley if needed

• If your replacement pump does not include a pulley, use a pulley puller/installer (specialty) to remove the pulley from the old pump.
• Install it onto the new pump with the same specialty tool.
• Make sure the pulley is seated fully and straight.

Step 8: Install the new pump

• Position the new pump in place and install the mounting bolts by hand first.
• Use a 14mm socket and torque wrench to tighten the bolts.
• Torque to 24 Nm (18 ft-lbs) unless your replacement pump instructions specify otherwise.

Step 9: Reconnect the steering lines

• Install new seals on the pressure line and return hose.
• Reconnect the lines using the correct 13mm socket or line wrench size.
• Torque to 22 Nm (16 ft-lbs) for line fittings unless the fitting style requires a different spec from the replacement pump.

Step 10: Reinstall the serpentine belt

• Route the belt according to the factory routing.
• Use the serpentine belt tool or breaker bar to release the tensioner again.
• Slip the belt over the final pulley, then slowly release the tensioner.

Step 11: Refill the system

• Use a funnel to fill the reservoir with the correct power steering fluid.
• Fill only to the marked level.
• Do not overfill.

Step 12: Bleed the system

• With the front wheels still off the ground, turn the steering wheel slowly from lock to lock several times.
• Check the fluid level and top off as needed with the funnel.
• Start the engine and repeat the steering sweep carefully.
• Watch for foam in the reservoir.

Step 13: Reassemble and inspect

• Reinstall the shields with the 10mm socket and 13mm socket.
• Reinstall the wheel if removed and lower the vehicle.
• Use a torque wrench to tighten lug nuts to 140 Nm (103 ft-lbs).

---

✅ After Repair

• Start the engine and check for leaks at both hose connections.
• Turn the wheel left and right and listen for whining or groaning.
• Recheck the fluid level after a short test drive.
• If steering feels heavy or noisy, the system may still have air trapped and may need another bleed cycle.

---

💰 DIY vs Shop Cost

Shop Cost: $850-$1,450 (parts + labor)

DIY Cost: $220-$550 (parts only)

You Save: $600-$900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
