🔧 QX80 - Power Steering Pump Replacement

The power steering pump is belt-driven and creates hydraulic pressure so the steering feels light and smooth. Replacing it involves removing the drive belt, disconnecting the power steering lines, swapping the pump, then refilling and bleeding the system to remove air.

Difficulty Level: Advanced | Estimated Time: 3-5 hours

Assumption: your QX80 uses a belt-driven hydraulic pump (not electric steering).

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; keep hands away from the radiator fan and belts.
• ⚠️ Support the vehicle with jack stands; never rely on a floor jack alone.
• ⚠️ Power steering fluid is slippery and flammable; wipe spills immediately.
• ⚠️ Do not hold the steering at full lock for more than 5 seconds while bleeding.
• 🔋 Battery disconnect is recommended to prevent accidental cranking.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 2-gallon)
• Shop towels
• Funnel
• Ratchet
• Socket set (8mm-19mm)
• 10mm socket
• 12mm socket
• 14mm socket
• Extension set (3" and 6")
• Torque wrench (10-100 ft-lbs)
• Serpentine belt tool (specialty)
• Box-end wrench set (10mm-19mm)
• Flare-nut wrench set (specialty)
• Hose clamp pliers
• Hose pinch-off pliers
• Power steering pulley puller/installer kit (specialty)
• Trim clip removal tool
• Flathead screwdriver

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Power steering pump - Qty: 1
• Power steering pump pulley - Qty: 1 (only if damaged or worn)
• Power steering pressure line sealing washers or O-ring set - Qty: 1
• Power steering return hose clamp - Qty: 1 (recommended)
• Serpentine drive belt - Qty: 1 (recommended if cracked or glazed)
• Power steering fluid (Nissan/Infiniti approved, Dexron III/Matic D equivalent) - Qty: 2 quarts

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and chock the rear wheels.
• 🔋 Disconnect the negative battery terminal using a 10mm socket.
• 🛞 Raise the front of the vehicle with a floor jack and support with jack stands so the front wheels can turn freely during bleeding.
• 🧼 Clean around the pump and hose connections with shop towels so dirt does not enter the system.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Use a trim clip removal tool and 10mm socket to remove the clips/bolts.
• Set the shield and hardware aside in a small pile so nothing gets lost.

Step 2: Relieve belt tension and remove the serpentine belt

• Use a serpentine belt tool (specialty) or 14mm socket to rotate the belt tensioner and relieve tension.
• Slip the belt off the power steering pump pulley first, then remove it from the other pulleys.
• Tip: take a quick photo of belt routing.

Step 3: Drain as much power steering fluid as possible

• Place a drain pan under the pump and hoses.
• Use hose pinch-off pliers on the return hose to reduce mess (these gently clamp a rubber hose without damaging it).
• Use hose clamp pliers or a flathead screwdriver (depending on clamp type) to loosen the return hose clamp, then pull the hose off and drain into the pan.

Step 4: Disconnect the high-pressure line from the pump

• Use a flare-nut wrench (specialty) on the pressure fitting (this wrench grips more sides of the nut to prevent rounding).
• Keep the fitting straight as you loosen it; do not twist the metal line.
• Cap/cover open lines with a clean shop towel to keep dirt out.

Step 5: Remove the power steering pump

• Unplug any nearby harness clips from the bracket using a trim clip removal tool if they block access.
• Use a ratchet, extensions, and a 12mm socket or 14mm socket to remove the pump mounting bolts.
• Remove the pump from the engine bay carefully without bending the power steering lines.

Step 6: Transfer the pulley (if your new pump does not include one)

• Use a power steering pulley puller/installer kit (specialty) to remove the pulley from the old pump.
• Install the pulley onto the new pump using the installer from the same kit.
• Press the pulley on straight until it aligns with the other pulleys (misalignment can shred the belt).
• Tip: never hammer a power steering pulley.

Step 7: Install the new pump

• Position the pump and hand-start all mounting bolts to avoid cross-threading.
• Tighten mounting bolts using a torque wrench: Torque to 44 Nm (32 ft-lbs).

Step 8: Reconnect the power steering lines

• Install new sealing washers/O-rings on the pressure fitting as supplied with your parts kit.
• Thread the pressure fitting by hand first, then tighten using a flare-nut wrench.
• Tighten the pressure fitting with a torque wrench if your crowfoot adapter is available: Torque to 34 Nm (25 ft-lbs).
• Reconnect the return hose and secure the clamp using hose clamp pliers or a flathead screwdriver (snug, not crushing the hose).

Step 9: Reinstall the serpentine belt

• Route the belt according to the under-hood diagram.
• Use a serpentine belt tool (specialty) to rotate the tensioner and slip the belt onto the power steering pulley last.
• Visually confirm the belt is centered on every pulley groove.

Step 10: Refill and bleed the power steering system

• Fill the reservoir using a funnel with power steering fluid (Nissan/Infiniti approved, Dexron III/Matic D equivalent) to the COLD mark.
• With the front wheels still off the ground and engine OFF, slowly turn the steering wheel lock-to-lock 10-15 times.
• Top off fluid as the level drops; do not let the reservoir run empty.
• Reconnect the battery using a 10mm socket.
• Start the engine and let it idle; continue turning lock-to-lock slowly 5-10 more times.
• Shut the engine off, wait 2 minutes for bubbles to rise, then recheck and adjust fluid level.
• Tip: foamy fluid means air is still inside.

Step 11: Reinstall splash shield and lower the vehicle

• Reinstall the splash shield using a 10mm socket and trim clip removal tool.
• Lower the vehicle from jack stands using a floor jack.

---

✅ After Repair

• 🔎 With the engine idling, inspect the pump and hose connections for leaks using a flashlight and shop towels.
• 🛞 Road test in a safe area: verify steering is smooth and quiet in both directions.
• 📏 Recheck fluid level after the road test; set to the HOT mark once fully warmed up.
• 🧼 If you spilled fluid on the belt or pulleys, clean it off to prevent belt squeal.

---

💰 DIY vs Shop Cost

Shop Cost: ₹25,000-₹55,000 (parts + labor)

DIY Cost: ₹12,000-₹30,000 (parts only)

You Save: ₹13,000-₹25,000 by doing it yourself!

Shop labor rates vary but typically run ₹1,500-₹3,000/hour. This repair takes a shop approximately 3-5 hours.

---
