🔧 Expedition - Power Steering Pump Replacement

The power steering pump makes the hydraulic pressure that helps you turn the steering wheel easily. Replacing it involves removing the drive belt, disconnecting the hoses, swapping the pump (and pulley), then refilling and bleeding the system to remove air.

Assumption: Your Expedition is equipped with a belt-driven hydraulic power steering pump (not an electric steering rack system).

Difficulty Level: Advanced | Estimated Time: 3-5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine; hot coolant pipes and turbo plumbing can burn you.
• ⚠️ Support the truck with jack stands; never rely on a floor jack.
• ⚠️ Power steering fluid is slippery and flammable—clean spills immediately.
• ⚠️ Keep fingers and tools away from the belt path while rotating the engine or running it.
• Disconnect the negative battery cable if you’ll be working near the fan or main wiring.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Drain pan (at least 2-gallon)
• Fluid suction gun
• Funnel
• Shop rags
• Trim clip tool
• 3/8" drive ratchet
• 3/8" drive extension set
• 1/2" drive breaker bar
• Socket set 8mm-18mm
• Wrench set 10mm-18mm
• Line wrench set 16mm-18mm
• Serpentine belt tool 1/2" drive
• Torque wrench 10-150 ft-lbs
• Power steering pulley puller/installer set (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Power steering pump - Qty: 1
• Power steering pump pulley - Qty: 1
• Power steering pressure line O-ring seal kit - Qty: 1
• Power steering return hose clamp - Qty: 1
• Power steering fluid (Motorcraft MERCON LV ATF) - Qty: 3 quarts
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Raise the front end with a floor jack and support with jack stands so the front wheels can turn freely for bleeding.
• Use a fluid suction gun to remove as much fluid as possible from the reservoir into a drain pan.
• If access is tight near the fan/wiring, disconnect the negative battery cable using a 10mm wrench.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the upper intake ducting (for access)

• Loosen the clamps with an 8mm socket or screwdriver and remove the intake tube.
• Remove any plastic covers using a trim clip tool and 10mm socket.

Step 2: Drain the power steering system

• Place a drain pan under the pump/hoses.
• Remove the return hose clamp using pliers (or a 10mm socket if it’s a screw clamp), then pull the return hose off the reservoir/pump nipple.
• Let it drain, then plug the hose with a clean rag to reduce mess.
• Tip: Bag the hose end to stop drips.

Step 3: Remove the serpentine belt from the pump pulley

• Rotate the belt tensioner using a 1/2" breaker bar or serpentine belt tool 1/2" drive.
• Slip the belt off the power steering pump pulley, then slowly release the tensioner.
• If reusing the belt, take a photo of the belt routing before removal.

Step 4: Remove the pump pulley

• Install the power steering pulley puller/installer set (specialty) and pull the pulley off the pump shaft.
• Pulley puller/installer definition: A tool that presses/pulls the pulley without damaging the pump shaft.

Step 5: Disconnect the pressure line and remaining hoses

• Clean around the pressure fitting with shop rags to keep dirt out.
• Use a line wrench 16mm-18mm to loosen the high-pressure line fitting (a line wrench grips more sides of the nut to prevent rounding).
• Remove any remaining hose clamps using pliers and detach hoses.
• Catch fluid in the drain pan.

Step 6: Remove the pump from its bracket

• Remove the pump mounting bolts using a socket set 10mm-15mm with a 3/8" ratchet and extensions.
• Lift the pump out carefully, watching for nearby wiring and hoses.
• Torque note: Reinstall fasteners to the factory specification for your pump/bracket hardware; use a torque wrench and do not overtighten aluminum threads.

Step 7: Transfer fittings (if required) and install new seals

• If your replacement pump requires transferring a fitting/valve, remove it using the correct wrench set 16mm-18mm and install onto the new pump.
• Replace the pressure line O-ring(s) from the seal kit (lightly coat with fresh fluid before installing).
• Tip: Never reuse flattened O-rings.

Step 8: Install the new pump

• Position the pump and hand-start all mounting bolts.
• Tighten with a 3/8" ratchet, then final-tighten with a torque wrench 10-150 ft-lbs to factory spec.
• Reconnect the return hose and install a new clamp using pliers.

Step 9: Reconnect the pressure line

• Thread the pressure line fitting by hand first to avoid cross-threading.
• Tighten using a line wrench 16mm-18mm to the factory spec for the fitting.
• Wipe everything clean with shop rags so leaks are easy to spot later.

Step 10: Press the pulley onto the new pump

• Use the power steering pulley puller/installer set (specialty) in installer mode to press the pulley on.
• Press it until the pulley aligns flush/straight with the other belt pulleys.
• Tip: Misalignment will shred belts.

Step 11: Reinstall the serpentine belt

• Route the belt according to your photo/diagram.
• Rotate the tensioner using the serpentine belt tool 1/2" drive and slip the belt onto the pump pulley.
• Double-check the belt is fully seated in every pulley groove using a flashlight.

Step 12: Refill and bleed the system

• Fill the reservoir using a funnel with Motorcraft MERCON LV ATF to the “COLD” mark.
• With the front wheels still off the ground and the engine OFF, turn the steering wheel slowly from lock-to-lock 15–20 times to push air out.
• Top off fluid as the level drops.
• Start the engine and let it idle; do not rev.
• Turn lock-to-lock 5–10 more times, slowly, watching for foaming or growling noises.
• Shut off, wait 5 minutes, then recheck and adjust level.

Step 13: Reassemble intake ducting and lower the vehicle

• Reinstall the intake tube and covers using a 8mm socket and 10mm socket.
• Lower the truck from the jack stands using the floor jack.
• If disconnected, reconnect the battery using a 10mm wrench.

---

✅ After Repair

• With the engine running, check for leaks at the pressure fitting and hose connections using a flashlight.
• Road test at low speed first. Steering should be smooth and quiet with no whining.
• Recheck fluid level hot (after driving) and top off to the correct mark.
• If the fluid turns milky/foamy, air is still trapped—repeat the bleed process.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,200 (parts + labor)

DIY Cost: $220-$550 (parts only)

You Save: $430-$650 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-5 hours.

---
