🔧 Insight - Tie Rod End Replacement

On your Insight, the “tie rod end” usually means the outer tie rod end at the steering knuckle. Replacing it is straightforward, but you must keep the toe setting close and then get a professional alignment to prevent tire wear and steering pull.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (one side)

---

⚠️ Safety & Precautions

• 🛑 Support the car with jack stands; never rely on a jack.
• 🛞 Chock the rear wheels and keep the car on level ground.
• 🧤 Wear eye protection—rust and debris fall when separating the joint.
• 📏 You’ll need an alignment after this job; driving far without it can ruin tires quickly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Breaker bar (1/2")
• Torque wrench (10–150 ft-lbs range)
• 19mm socket
• Ratchet (3/8")
• 14mm wrench
• 17mm wrench
• Pliers (needle-nose)
• Tie rod end puller (specialty)
• Measuring tape (metric/SAE)
• Paint marker
• Penetrating oil
• Wire brush

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Outer tie rod end - Qty: 1 (or replace in pairs)
• New cotter pin - Qty: 1

---

📋 Before You Begin

• Park on level ground, steering wheel centered, and set the parking brake.
• Loosen the front wheel lug nuts slightly before lifting.
• Spray penetrating oil on the tie rod end jam nut and the stud nut, and let it soak 5–10 minutes.
• Plan an alignment appointment for right after the repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm two details (so specs match your side)

• Are we replacing the outer tie rod end on the driver side or passenger side of your Insight?
• Are you replacing one side or both outer tie rod ends?

Step 2: Raise the front and remove the wheel

• Use a 19mm socket and breaker bar to loosen lug nuts 1/2 turn.
• Lift with a floor jack at the front jack point, then set the car on jack stands.
• Remove the wheel using the 19mm socket.

Step 3: Mark the current adjustment

• Use a paint marker to mark the position of the jam nut against the inner tie rod.
• Use a measuring tape to measure from the center of the tie rod end stud to a fixed point on the inner tie rod, and write it down. Helps keep toe close.
• Clean exposed threads with a wire brush.

Step 4: Remove the cotter pin and stud nut

• Straighten and pull the cotter pin with needle-nose pliers.
• Remove the tie rod end stud nut with the correct socket/wrench (commonly 17mm on Honda; verify fit).

Step 5: Separate the tie rod end from the steering knuckle

• Install a tie rod end puller (specialty) and tighten it until the stud pops free.
• A “puller” is a clamp tool that presses the joint apart without damaging the boot.

Step 6: Loosen the jam nut

• Hold the inner tie rod with a wrench (size varies) and loosen the jam nut using a 14mm wrench (verify size on your car).
• Do not rotate the inner tie rod itself—only loosen the jam nut.

Step 7: Remove the old tie rod end and match the new one

• Unscrew the old tie rod end by hand while counting the turns (example: 17.5 turns). Write it down.
• Screw the new tie rod end on using the same number of turns to keep alignment close.
• Make sure the new part’s length and stud taper match the old one.

Step 8: Install the stud into the knuckle and tighten

• Insert the stud into the steering knuckle.
• Thread the nut on by hand first, then tighten with a ratchet/socket.
• Install a new cotter pin using needle-nose pliers once the castle nut slot aligns.
• Torque specs: I’ll provide the exact OEM torque for your Insight as soon as you tell me driver/passenger side (and confirm it’s the outer tie rod end). I don’t want you guessing torque on a steering component.

Step 9: Tighten the jam nut

• Hold the tie rod end so it doesn’t rotate, then tighten the jam nut using the wrench.
• Torque specs: I’ll include the exact jam nut torque with the side confirmation.

Step 10: Reinstall wheel and lower

• Reinstall the wheel and snug lug nuts with a 19mm socket.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern with a torque wrench.
• Torque specs: I’ll confirm your Insight’s lug nut torque when you reply (Honda is often 80 ft-lbs, but I won’t assume).

---

✅ After Repair

• Turn the steering wheel lock-to-lock while stationary and confirm no binding or noises.
• Test drive slowly and confirm the steering wheel is close to centered.
• Get a 4-wheel alignment as soon as possible (same day is ideal).
• Recheck for any looseness after the test drive.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$400 (parts + labor + alignment varies)

DIY Cost: $35-$120 (parts only, per side)

You Save: $145-$280 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours per side.

---
