🔧 Escape - Outer Tie Rod End Replacement

The outer tie rod end connects your steering rack to the front knuckle and lets the wheel turn while keeping alignment. When it’s worn, you can get clunks, loose steering, and uneven tire wear. Replacing it is straightforward, but you must get an alignment afterward.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (one side)

---

⚠️ Safety & Precautions

• 🛑 Support your Escape with jack stands—never rely on a floor jack alone.
• 🧤 Wear safety glasses; dirt/rust can fall when separating the joint.
• 🔥 If you drive first, let brakes/rotors cool before working near them.
• 🧭 Plan on a professional alignment after replacement to prevent tire wear.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• 19mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20–200 Nm range)
• 21mm socket
• 19mm open-end wrench
• Needle-nose pliers
• Tie rod end puller (specialty)
• Small wire brush
• Paint marker
• Measuring tape
• Penetrating oil

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Outer tie rod end (Left or Right) - Qty: 1
• Outer tie rod end nut (usually included with tie rod end) - Qty: 1

---

📋 Before You Begin

• Park on level ground, steering wheel centered, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Before lifting, slightly loosen the front wheel lug nuts using a 19mm socket and breaker bar.
• Spray penetrating oil on the tie rod end stud nut and the jam nut threads. Let it soak 5–10 minutes.
• Tip: Take a quick photo of the tie rod threads.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the front wheel

• Use a floor jack to lift the front corner at the approved jacking point.
• Set the vehicle onto jack stands and confirm it’s stable.
• Remove the lug nuts with a 19mm socket and take the wheel off.

Step 2: Mark the current toe setting (so it’s close afterward)

• Use a wire brush to clean exposed threads at the jam nut area.
• Use a paint marker to mark the tie rod end and jam nut position.
• Use a measuring tape to measure from a fixed point (example: tie rod end housing) to the center of the stud; write it down.
• Tip: This helps you drive safely to alignment.

Step 3: Loosen the jam nut

• Hold the tie rod end with a 19mm open-end wrench (or on the hex if provided).
• Loosen the jam nut using a 19mm open-end wrench by turning it counterclockwise (do not move it far yet).
• Jam nut = the lock nut that holds alignment.

Step 4: Remove the tie rod end nut from the knuckle

• Remove the nut on the tie rod end stud using a 21mm socket.
• If the stud spins, apply upward pressure on the tie rod end and retry with the 21mm socket.

Step 5: Separate the tie rod end from the steering knuckle

• Install a tie rod end puller (specialty) over the joint and tighten it until the stud “pops” free.
• Tie rod puller = a tool that presses the joint apart safely.

Step 6: Remove the old outer tie rod end

• Spin the tie rod end off the inner tie rod by hand.
• Count the exact number of turns it takes to remove it (example: “17 turns”). Write it down.

Step 7: Install the new outer tie rod end

• Thread the new tie rod end onto the inner tie rod the exact same number of turns you counted.
• Align your paint marks and/or your measurement from earlier to get it as close as possible.

Step 8: Attach the tie rod end to the knuckle and torque fasteners

• Insert the stud into the steering knuckle.
• Install the new nut (if supplied) and tighten using a 21mm socket.
• Tighten the stud nut with a torque wrench: Torque to 59 Nm (44 ft-lbs).
• Hold the tie rod end and tighten the jam nut using a 19mm open-end wrench, then final torque with a torque wrench: Torque to 75 Nm (55 ft-lbs).

Step 9: Reinstall the wheel and lower the vehicle

• Reinstall the wheel and hand-thread lug nuts.
• Lower the Escape off the jack stands using the floor jack.
• Torque lug nuts in a star pattern using a torque wrench: Torque to 135 Nm (100 ft-lbs).

---

✅ After Repair

• Start the engine and turn the steering wheel lock-to-lock to confirm smooth movement and no binding.
• Road test at low speed first; listen for clunks and verify the steering wheel stays close to centered.
• Get a 4-wheel alignment as soon as possible (toe will be disturbed even if you counted turns).
• Tip: Uneven steering wheel = alignment needed.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$450 (parts + labor + alignment)

DIY Cost: $35-$120 (parts only, per side)

You Save: $100-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours (plus alignment).

---
