🔧 Malibu - Outer Tie Rod End Replacement

The outer tie rod end connects your steering rack to the steering knuckle. Replacing it restores safe steering and correct tire wear, but it must be installed at the correct length and then professionally aligned.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours (one side)

---

⚠️ Safety & Precautions

• 🛑 Support the car with jack stands; never rely on a floor jack.
• 🧤 Wear safety glasses; rust and metal chips fall when removing the cotter pin.
• 🧭 Keep the steering wheel centered and don’t let it free-spin (helps protect the steering angle sensor/clock spring).
• 📏 Get an alignment after replacement; “counting turns” only gets you close.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 19mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20–200 ft-lbs range)
• 18mm socket
• 21mm socket
• Open-end wrench set (18mm–24mm)
• Needle-nose pliers
• Side cutters
• Tie rod end puller (specialty)
• Penetrating oil
• Wire brush
• Paint marker
• Tape measure
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Outer tie rod end - Qty: 1
• Cotter pin (tie rod end nut) - Qty: 1
• Jam nut (optional, if damaged) - Qty: 1
• Anti-seize compound (optional) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Loosen the front lug nuts slightly using a 19mm socket and breaker bar before lifting.
• Spray penetrating oil on the tie rod end jam nut threads and the stud nut, then wait 5–10 minutes.
• Have a plan for alignment: schedule a shop alignment right after the repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Two quick details so I give you the correct torque specs

• Which side are you replacing: driver or passenger?
• Are you replacing the outer tie rod end (the one at the wheel/knuckle) or the inner tie rod end (the one at the steering rack boot)?

Step 2: Lift and remove the front wheel

• Lift the front corner using a floor jack at the correct jacking point.
• Set the car onto jack stands and gently shake the car to confirm it’s stable.
• Remove the lug nuts with a 19mm socket and remove the wheel.

Step 3: Mark the current position (helps keep alignment close)

• Use a wire brush to clean the exposed threads near the jam nut.
• Use a paint marker to mark the jam nut position on the threads.
• Measure from a fixed point on the tie rod end to the jam nut using a tape measure and write it down. This helps match the new length.

Step 4: Remove the cotter pin and loosen the stud nut

• Straighten and remove the cotter pin using needle-nose pliers (or cut it with side cutters if it’s rusted).
• Remove the tie rod end stud nut using an 18mm socket or 21mm socket (size can vary by brand/previous repairs).

Step 5: Separate the tie rod end from the steering knuckle

• Install a tie rod end puller (specialty) and tighten it until the stud pops free from the knuckle.
• A loud pop is normal. Keep fingers clear of the joint as it releases.

Step 6: Loosen the jam nut

• Hold the inner tie rod (or the flats behind the outer end, if present) with an open-end wrench set (18mm–24mm).
• Break the jam nut loose using an open-end wrench set (18mm–24mm).
• Do not spin the inner tie rod itself if you can avoid it; just crack the jam nut free.

Step 7: Remove the outer tie rod end (count turns)

• Unthread the outer tie rod end by hand and count the exact number of turns until it comes off.
• Write the turn count down.

Step 8: Install the new outer tie rod end

• Apply a light coating of anti-seize compound (optional) to the threads (avoid getting any on the stud taper).
• Thread the new outer tie rod end on the same number of turns you counted.
• Align the stud into the steering knuckle hole by hand.

Step 9: Tighten the stud nut and install a new cotter pin

• Tighten the stud nut using a torque wrench and the correct socket.
• Line up the castle nut slot with the hole and install a new cotter pin, then bend it over using needle-nose pliers.
• Torque: I’ll provide the exact Malibu spec once you answer Step 1 (it varies by hardware).

Step 10: Tighten the jam nut

• Hold the outer tie rod end so it doesn’t rotate using an open-end wrench set (18mm–24mm).
• Tighten the jam nut using an open-end wrench set (18mm–24mm).
• Torque: I’ll provide the exact Malibu spec once you answer Step 1.

Step 11: Reinstall the wheel and lower the car

• Install the wheel and hand-thread lug nuts.
• Lower the car off the jack stands using the floor jack.
• Torque lug nuts in a star pattern using a torque wrench: Torque to 140 Nm (103 ft-lbs).

---

✅ After Repair

• Turn the steering wheel lock-to-lock while parked and listen for any clunks.
• Road test at low speed first; confirm the steering wheel is close to centered.
• Get a professional front-end alignment as soon as possible.
• Recheck for looseness after a short drive (5–10 miles).

---

💰 DIY vs Shop Cost

Shop Cost: $220-$450 (parts + labor + alignment)

DIY Cost: $35-$110 (parts only, per side)

You Save: $110-$340 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours, plus alignment.

---
