🔧 Ioniq - MAF Sensor Replacement

On your Ioniq, what many people call a “MAF” is often actually a MAP/T-MAP sensor (it measures pressure/temperature instead of airflow). The replacement process is simple, but the location and fasteners differ depending on which sensor your Ioniq has.

Quick question (1): Is the sensor mounted in the air intake tube right after the air filter box (MAF), or is it bolted into the intake manifold/near the throttle body (MAP/T-MAP)? If you’re not sure, tell me where it sits or upload a photo and I’ll lock you into the correct path.

Difficulty Level: Beginner | Estimated Time: 0.3-0.8 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool so you don’t burn your hands on hot parts.
• ⚠️ Keep hands/tools away from orange high-voltage cables (hybrid system wiring).
• ⚠️ Disconnecting the 12V negative battery terminal is recommended to prevent accidental shorting and to help avoid setting extra fault codes.
• ⚠️ Do not touch the sensing element if you’re handling a MAF; it’s delicate.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 10mm socket
• 1/4" ratchet
• 6" extension (1/4")
• Phillips screwdriver #2
• Torx T20 bit
• Trim clip removal tool
• Flashlight
• Nitrile gloves
• Safety glasses
• OBD2 scan tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Mass air flow (MAF) sensor - Qty: 1
• MAP/T-MAP sensor (pressure/temperature sensor) - Qty: 1
• Sensor O-ring (if not included with sensor) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and power the car OFF.
• Open the hood and remove the key fob from the vehicle area.
• Use a 10mm wrench to disconnect the 12V negative battery terminal and set it aside so it can’t spring back.
• Confirm which sensor you’re replacing:
  • MAF: typically installed in the intake duct near the air filter box.
  • MAP/T-MAP: typically bolted into the intake manifold area (often near the throttle body).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the sensor

• Use a flashlight to locate the sensor and its electrical connector.
• If an engine cover blocks access, remove it by pulling upward firmly with your hands; if clips resist, use a trim clip removal tool.

Step 2: Unplug the electrical connector

• Press the connector lock tab and pull straight off. If it’s stuck, wiggle gently—don’t pull on the wires.
• Tip: Push in first, then pull off.

Step 3A (If equipped): Remove and replace the MAF sensor

• Locate the MAF in the intake tube near the air box.
• Use a Torx T20 bit (or Phillips screwdriver #2 if yours uses Phillips) to remove the two sensor screws.
• Pull the sensor straight out. Do not twist hard or pry on the plastic housing.
• Install the new MAF sensor in the same orientation (matching the arrow/flow direction if marked).
• Reinstall screws and Torque to 3 Nm (27 in-lbs).

Step 3B (Common on Ioniq): Remove and replace the MAP/T-MAP sensor

• Locate the MAP/T-MAP sensor bolted into the intake manifold area.
• Use a 10mm socket, 1/4" ratchet, and 6" extension (1/4") to remove the mounting bolt(s).
• Pull the sensor straight out; there is usually an O-ring seal.
• Inspect the O-ring. If it’s flattened/torn, replace it (lightly oil it with a drop of clean engine oil on a gloved fingertip).
• Install the new sensor fully seated, then reinstall bolt(s) and Torque to 9 Nm (80 in-lbs).

Step 4: Reconnect and reassemble

• Reconnect the electrical connector until it clicks.
• Reinstall any engine cover you removed (press down evenly).
• Reconnect the 12V negative battery terminal using a 10mm wrench and tighten snugly.

Step 5: Clear codes (if needed)

• If you had a check engine light, use an OBD2 scan tool to clear codes after the repair.
• If codes return immediately, stop and tell me the exact code(s).

---

✅ After Repair

• Start your Ioniq and let it idle for 2–3 minutes. Listen for intake air leaks (hissing).
• Take a short test drive. Confirm normal acceleration and that the check engine light stays off.
• Re-scan with your OBD2 scan tool and make sure no pending codes return.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $60-$200 (parts only)

You Save: $120-$150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
