🔧 Headlight Bulbs - Replacement

Your CR-V Touring uses LED headlamps, so there are no replaceable halogen headlight bulbs for the low or high beams. If one side is out, the usual fix is replacing the complete headlight assembly, not a bulb.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Turn the ignition off and remove the key/fob from the vehicle.
• Disconnect the negative battery cable before working near the front lighting harness.
• Do not look directly into LED light sources when powered.
• Allow nearby engine and radiator parts to cool before starting.
• If the headlight is replaced, aim adjustment may be needed afterward.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• Ratchet
• Extension bar
• Trim clip removal tool
• Phillips screwdriver
• Flat-blade trim tool
• Torque wrench
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Left headlight assembly - Qty: 1
• Right headlight assembly - Qty: 1
• Retaining clips - Qty: as needed

---

📋 Before You Begin

• Park on level ground with the steering wheel centered.
• Set the parking brake.
• Open the hood and disconnect the negative battery terminal.
• Label connectors before unplugging them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the front upper trim and fasteners

• Use a trim clip removal tool and Phillips screwdriver to remove the upper radiator cover clips and screws.
• Lift the cover out carefully and set it aside.

Step 2: Remove the front bumper cover fasteners

• Use a 10mm socket, ratchet, and extension bar to remove the upper and side fasteners holding the bumper cover.
• Use the trim clip removal tool for the plastic clips in the wheel well and lower edge.
• Pull the bumper cover forward enough to access the headlight assembly.
• Work slowly to avoid breaking tabs.

Step 3: Disconnect the headlight assembly

• Unplug the electrical connectors from the headlight assembly.
• Release any locking tabs before pulling on the connectors.

Step 4: Remove the headlight assembly

• Use a 10mm socket and ratchet to remove the headlight mounting bolts.
• Slide the assembly straight forward and out of the vehicle.

Step 5: Install the new headlight assembly

• Position the new assembly in place.
• Install the mounting bolts by hand first, then tighten with a torque wrench.
• Torque to 12 Nm (9 ft-lbs).
• Reconnect all electrical connectors.

Step 6: Reinstall the bumper cover and trim

• Reinstall the bumper cover, clips, screws, and trim pieces in the reverse order.
• Use the 10mm socket and trim clip removal tool as needed.

---

✅ After Repair

• Reconnect the negative battery cable.
• Turn on the headlights and check both sides for proper operation.
• Check beam aim against a wall or garage door.
• If the light pattern looks off, have the headlights aimed properly.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,800 (parts + labor)

DIY Cost: $450-$1,200 (parts only)

You Save: $250-$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
