Assumption: Your RAV4 Limited has the factory LED headlamp assemblies. On this setup, there are no serviceable headlight bulbs to swap. If one or both lights are out, the fix is to replace the complete headlamp assembly or the failed LED module, depending on what failed.

🔧 Headlamp Assembly - Replacement

Your RAV4 Limited does not use traditional replaceable headlight bulbs if it has the factory LED headlamps. The repair is usually a headlamp assembly replacement, which is more involved than a bulb swap because the front bumper cover is commonly removed for access.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before touching any headlamp wiring.
• Do not look directly at active LED light sources.
• Keep the ignition OFF while connectors are unplugged.
• If your vehicle has headlamp auto-aim or related calibration, a scan tool may be needed after repair.
• Handle painted panels and bumper edges carefully to avoid scratches.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• Ratchet
• Short extension
• Trim clip removal tool
• Phillips screwdriver
• Flat blade trim tool
• Torx T30 screwdriver
• Torque wrench
• Fender cover
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Left headlamp assembly - Qty: 1
• Right headlamp assembly - Qty: 1
• Front bumper cover clips - Qty: 1 set
• Headlamp mounting hardware - Qty: 1 set

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Turn the headlights OFF and remove the key or shut the vehicle fully down.
• Disconnect the negative battery cable before starting.
• Keep all fasteners organized.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect power

• Use a 10mm socket to disconnect the negative battery cable.
• Move the cable aside so it cannot touch the battery terminal.

Step 2: Remove upper bumper fasteners

• Use a Phillips screwdriver and trim clip removal tool to remove the upper grille and bumper cover retainers.
• Remove every visible fastener across the top edge.

Step 3: Remove wheel well and lower fasteners

• Use a 10mm socket and trim clip removal tool to remove the fasteners in both front wheel openings and along the lower bumper edge.
• Turn the front wheels for easier access if needed.

Step 4: Remove the front bumper cover

• Use a flat blade trim tool to gently release the bumper cover from the fender side retainers.
• Pull the cover forward slowly and unplug any fog lamp or sensor connectors if equipped.
• Work from both sides evenly.

Step 5: Remove the headlamp assembly

• Use a 10mm socket and ratchet with a short extension to remove the headlamp mounting bolts.
• Slide the headlamp assembly forward and unplug the electrical connector.

Step 6: Install the new headlamp assembly

• Connect the electrical connector to the replacement assembly.
• Set the assembly into place and hand-start the mounting bolts with a 10mm socket.
• Torque to 7 Nm (62 in-lbs).

Step 7: Reinstall the bumper cover

• Reconnect any unplugged connectors.
• Align the bumper cover with the fenders and press the side retainers back into place.
• Reinstall all top, lower, and wheel well fasteners with a Phillips screwdriver, trim clip removal tool, and 10mm socket.

Step 8: Restore power and test

• Reconnect the negative battery cable with a 10mm socket.
• Turn the headlights on and confirm both sides work correctly.
• Check that the beam pattern and aim look even.

---

✅ After Repair

• Verify low beams, high beams, and turn signals if integrated in the same housing.
• Check for warning lights on the dash.
• If the headlights appear misaligned, have the aim checked.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,600 (parts + labor)

DIY Cost: $350-$900 (parts only)

You Save: $350-$700 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
