🔧 Escape - Fuel Pump Module Replacement

I’ll walk you through replacing the in-tank fuel pump module on your Escape. This pump sits inside the fuel tank and feeds fuel up to the engine at high pressure. We’ll access it from inside the cabin (under the rear seat), so you don’t have to drop the fuel tank.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• 🔥 Work in a very well-ventilated area; fuel vapors can ignite easily.
• 🚭 No smoking, open flames, or sparks anywhere near the vehicle.
• 🔌 Disconnect the negative battery cable before opening the fuel system to avoid accidental sparks.
• 🧯 Keep a class B or ABC fire extinguisher within reach.
• 💧 Fuel will spill when lines are opened; keep rags and a drain pan ready and clean up immediately.
• 😷 Avoid breathing fuel vapors; take breaks if you feel lightheaded.
• 🧤 Wear fuel-resistant gloves; gasoline can irritate your skin.
• ⚙️ The fuel system is under pressure; you must depressurize it before disconnecting any fuel line.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• Ratchet handle 3/8"
• Socket extension 6"
• Flathead screwdriver small
• Trim removal tool plastic
• Fuel pump lock ring tool (Ford-style, adjustable) (specialty)
• Brass punch 6-8"
• Small hammer
• Torque wrench 3/8" drive
• Pick tool hook type
• Fuel line disconnect tool 3/8" and 5/16" (specialty)
• Shop rags
• Drain pan low-profile
• Flashlight or work light LED
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Fuel pump module assembly (in-tank, with sender) - Qty: 1
• Fuel pump module lock ring - Qty: 1
• Fuel pump module tank seal / gasket - Qty: 1
• Fuel line retaining clips - Qty: 2-4
• Electrical connector repair pigtail (if existing plug is damaged) - Qty: 1
• Shop towels - Qty: 1 pack
• Plastic garbage bags (for old parts and rags) - Qty: 2-3

---

📋 Before You Begin

• Park the Escape on level ground, shift to Park, and set the parking brake.
• Try to have less than 1/4 tank of fuel; a lighter tank makes the job easier and less messy.
• Open all doors or at least both rear doors for good ventilation.
• Turn ignition OFF and remove the key/fob from the vehicle.
• Disconnect the negative battery cable using a 10mm socket and move it aside so it cannot spring back.
• Relieve fuel system pressure:
  • Remove the fuel pump fuse or relay from the fuse box (location can vary; check your owner’s manual diagram).
  • Start the engine and let it run until it stalls, then crank for 3–5 more seconds.
  • Turn key OFF. This removes most pressure from the fuel rail.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the fuel pump under the rear seat

• Open both rear doors and locate the rear seat bottom cushion; on the Escape it is usually clipped at the front edge.
• Use your hands or a trim removal tool plastic to pop up the front edge of the rear seat cushion near each outer corner; pull sharply upward to release the clips.
• Lift the seat cushion up and tilt it toward the front seats, or remove it fully from the vehicle if it’s easy.
• Under the seat you’ll see a metal floor panel with a round access cover (usually stuck on with butyl sealer) over the fuel pump area.

Step 2: Remove the access cover

• Use a flathead screwdriver small to gently pry up the edge of the round access cover; work slowly to avoid bending it too much.
• Peel the cover back and set it aside; some sticky sealant will be on the edges, which is normal.
• Shine your flashlight into the opening; you should now see the top of the fuel pump module, with fuel lines and an electrical connector attached.

Step 3: Disconnect the electrical connector

• Locate the main electrical connector on top of the pump module.
• Use your fingers or a pick tool hook type very gently to lift the locking tab on the connector. A pick tool is a small metal hook for releasing clips.
• Pull the connector straight up to disconnect it; do not pull on the wires.

Step 4: Disconnect fuel lines safely

• Place several shop rags around the fuel line connections to catch any drips.
• Identify the quick-connect fuel line fittings; they typically have plastic clips or an internal spring that locks onto the pump nipple.
• Use the fuel line disconnect tool 3/8" and 5/16" as needed:
  • Slide the tool into the fitting between the line and the pump nipple.
  • Push the tool into the fitting while gently pulling the fuel line off.
  • A small amount of fuel may leak; catch it with rags and your drain pan.
• If there are separate clip pieces, use the pick tool to remove them carefully; plan to install new clips.

Step 5: Remove the lock ring

• The pump is held into the tank by a large plastic or metal lock ring.
• First, wipe dirt and dust away from the top of the tank and around the ring using shop rags. Keep dirt out of tank.
• If you have a fuel pump lock ring tool (specialty):
  • Position the tool over the tabs of the lock ring.
  • Use a ratchet handle 3/8" and the tool to turn the ring counterclockwise until it unlocks.
• If you don’t have the specialty tool, use a brass punch 6-8" and small hammer:
  • Place the punch on one of the lock ring tabs.
  • Tap the punch counterclockwise with the hammer to rotate the ring.
  • Work your way around the ring until it comes free.
• Carefully lift the lock ring off and set it aside; note its orientation.

Step 6: Remove the old fuel pump module

• Gently rock the pump module while lifting it straight up; be careful of the float arm for the fuel gauge, which sticks out from the side.
• As you lift, angle the unit so the float arm clears the tank opening without bending it.
• Fuel will be inside the module’s cup; tilt it slightly to keep most fuel inside as you remove it.
• Immediately place the old pump into your drain pan or a plastic bag to avoid spilling fuel on the interior.
• Remove and discard the old tank seal/gasket from the opening.

Step 7: Prepare the tank opening and new pump

• Use shop rags to carefully clean the tank opening sealing surface; do not let dirt fall into the tank.
• Compare the new pump module to the old one:
  • Check connector type and location.
  • Check fuel line nipple positions.
  • Check float arm shape and length.
• Install the new tank seal/gasket into the groove on the tank opening.
• If the new module came with alignment marks, note which direction the connector and lines should face relative to the body.

Step 8: Install the new fuel pump module

• Lower the new pump module into the tank carefully:
  • Insert the float arm first, angling it into the tank.
  • Keep the bottom of the pump level to avoid spilling fuel from its cup (if pre-primed).
• Seat the pump base squarely on the new tank seal; the pump top should sit flat and even.
• Align any marks on the pump flange with marks on the tank (if present), usually so the lines and connector face the same way as original.

Step 9: Reinstall and tighten the lock ring

• Place the lock ring back over the pump flange and onto its threads/grooves.
• Start the ring by hand, making sure it is not cross-threaded.
• Using the fuel pump lock ring tool (specialty) and ratchet handle 3/8", turn the ring clockwise until it is fully seated and the alignment marks line up as per the original position.
• If using the brass punch and small hammer, gently tap the ring clockwise around its circumference until it bottoms out and is snug; do not over-strike.
• Torque: For the lock ring, follow the exact manufacturer spec in a service manual; do not overtighten, as this can damage the plastic tank or ring.

Step 10: Reconnect fuel lines and electrical connector

• Push the fuel lines straight onto the pump nipples until you hear or feel a click.
• If using new clips, install them as designed and then push the line on again until fully seated.
• Gently tug each line to confirm it is locked in place.
• Reconnect the electrical connector by pushing it down until the locking tab clicks.

Step 11: Reinstall access cover and rear seat

• Reposition the metal access cover over the opening, pressing it firmly into the existing sealer so it seals against fumes and moisture.
• If the sealer is badly damaged, you can supplement with automotive-grade butyl tape around the edge.
• Lower the rear seat cushion back into position, making sure the rear hooks locate first.
• Push down sharply on the front edge over each clip position until you feel it snap into place.

Step 12: Reconnect battery and prime the fuel system

• Reconnect the negative battery cable using a 10mm socket. Torque to manufacturer spec (snug plus a small additional turn; do not overtighten).
• Reinstall the fuel pump fuse or relay in the fuse box.
• Turn the ignition key to ON (engine not started) for about 5–10 seconds; you should hear the pump run briefly.
• Turn key OFF, then repeat this ON–OFF cycle 3–4 times to fully prime the system and remove air.

Step 13: Start the engine and check for leaks

• Start the engine and let it idle.
• Look and smell around the rear seat access area (without open flames):
  • Check for any fuel leaks at the line connections and around the lock ring.
  • Listen for any unusual noises from the pump (light humming is normal).
• If you see any wetness or smell strong fuel, shut the engine off immediately and recheck the line connections and lock ring seating.

---

✅ After Repair

• Take a short test drive around your area, monitoring for normal acceleration and no stalling.
• Watch the fuel gauge to confirm it moves and reads reasonably (it may take a few minutes to stabilize).
• After driving, recheck the pump area for any signs of seepage or fuel odor.
• Dispose of old fuel-soaked rags and the old pump according to local regulations; do not throw raw fuel in household trash.

---

💰 DIY vs Shop Cost

Shop Cost: $700-$1,000 (parts + labor)

DIY Cost: $250-$450 (parts only)

You Save: $450-$550 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
