🔧 Atlas - Fuel Pump Replacement

Your Atlas can have two different “fuel pumps”: the in-tank low-pressure fuel pump module (inside the fuel tank) and the engine-mounted high-pressure fuel pump (used on direct-injection systems). The replacement steps, tools, and safety precautions are very different, so we need to identify which one you’re replacing before I give you the exact dealership-style procedure.

Difficulty Level: Intermediate | Estimated Time: 1.0-4.5 hours (varies by pump type and access)

---

⚠️ Safety & Precautions

• 🧯 Work outdoors or in strong ventilation; fuel vapors ignite easily.
• No smoking, no sparks, no hot work lights; use an LED work light.
• Let the engine cool fully before touching fuel lines.
• Wear nitrile gloves and safety glasses; fuel can irritate skin/eyes.
• Disconnect the negative battery terminal before opening the tank/pump area.
• Relieve fuel pressure before disconnecting any fuel line to avoid spray.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Fire extinguisher Class B
• LED work light
• 10mm socket
• 3/8" drive ratchet
• Trim removal tool set
• Needle-nose pliers
• Fuel line disconnect tool set (specialty)
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Fuel pump (correct type for your repair) - Qty: 1
• Fuel pump seal / O-ring - Qty: 1
• Optional: Fuel pump module lock ring - Qty: 1
• Optional: New fuel line sealing washers / seals - Qty: 1 set

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Open the fuel door to relieve tank vapor pressure.
• Remove loose items from the second-row/cargo area so you can inspect for an access panel.
• Have a container ready for small fuel drips and keep shop towels nearby.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Identify which “fuel pump” you mean

• Look on top/side of the engine for a small pump with a metal fuel line attached (this is the high-pressure fuel pump).
• Or, if your issue is “no in-tank pump sound,” hard starts after sitting, or low feed pressure, you may mean the in-tank fuel pump module inside the fuel tank.
• If you tell me where it is, I’ll give exact steps.

Step 2: Check whether your Atlas has an in-cabin access cover

• Use a trim removal tool set to carefully lift/remove the second-row seat bottom area trim (or check under the rear carpet/cargo area if applicable).
• Look for a round or oval metal/plastic access cover held by screws or butyl sealant.
• If there is no access cover, the in-tank module replacement typically requires lowering the fuel tank (more time and more tools).

Step 3: Reply to these 2 quick questions so I can generate the exact OEM procedure (with torque specs)

• Are you replacing the in-tank low-pressure fuel pump module or the engine high-pressure fuel pump?
• Do you see a round access panel under the second-row seat/cargo floor area (yes/no)?

---

✅ After Repair

• Cycle the ignition ON for 5 seconds, then OFF; repeat 3 times to prime the system before starting.
• Start the engine and inspect for leaks at every connection you touched.
• If the check engine light turns on, scan for codes and address any fuel-pressure or EVAP leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $600-$1,800 (parts + labor)

DIY Cost: $150-$900 (parts only)

You Save: $450-$900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-4.5 hours.

---
