🔧 Legacy - Fuel Pump Replacement

The fuel pump on your Legacy is inside the fuel tank, and Subaru provides an access panel under the rear seat so you can replace it without dropping the tank. The job is mostly careful handling of fuel lines and seals to prevent leaks and fuel odors.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: in-tank pump module is serviced through rear-seat access panel.

---

⚠️ Safety & Precautions

• ⚠️ Work outside or in a well-ventilated area; fuel vapors are flammable.
• ⚠️ No smoking, sparks, heat guns, or shop lights with hot bulbs near the car.
• ⚠️ Disconnect the negative battery cable before opening the tank access.
• ⚠️ Keep a class B fire extinguisher nearby.
• ⚠️ Wipe spills immediately and dispose of fuel-soaked rags safely.
• ⚠️ Replace the fuel pump seal/gasket; reusing it often causes leaks/odor.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Fire extinguisher (Class B)
• 10mm socket
• 3/8" ratchet
• 3/8" torque wrench (5–80 Nm range)
• Phillips #2 screwdriver
• Small flat-blade screwdriver
• Plastic trim removal tool
• Needle-nose pliers
• Fuel line quick-disconnect pick set
• Fuel pump lock ring wrench (specialty)
• Shop towels
• Drain pan
• Non-marring marker or paint pen

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Fuel pump module assembly - Qty: 1
• Fuel pump tank seal/gasket - Qty: 1
• Fuel line O-rings (if supplied/required) - Qty: 1 set

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and keep doors/windows open for ventilation.
• ⛽ Drive until the tank is below 1/2 if possible; a full tank makes the module harder to handle and increases spill risk.
• 🔋 Disconnect the negative battery terminal using a 10mm socket and move the cable aside so it can’t spring back.
• 🧻 Have shop towels ready; even “dry” fuel lines usually release a small amount of fuel.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve fuel pressure

• Open the fuel door and loosen the gas cap to release tank vapor pressure.
• Re-connect the negative battery cable temporarily using a 10mm socket.
• Remove the fuel pump power (fuel pump fuse/relay in the interior fuse/relay box) using a small flat-blade screwdriver as needed to help lift the cover.
• Start the engine and let it run until it stalls; crank for 2–3 seconds more to bleed off remaining pressure.
• Disconnect the negative battery cable again using a 10mm socket.
• If it won’t start, pressure may already be low.

Step 2: Remove the rear seat bottom cushion

• At the front edge of the rear seat bottom, use a plastic trim removal tool to locate the release points.
• Pull up sharply on the seat bottom at the release points to pop the clips free.
• Lift the seat bottom out and set it aside.
• Pull straight up to avoid breaking clips.

Step 3: Open the fuel pump access cover

• Locate the access panel on the floor under the rear seat.
• Remove the access cover screws using a Phillips #2 screwdriver.
• Lift the cover; peel back any butyl sealer carefully (sticky black sealant).
• Clean loose dirt around the pump top using shop towels so debris can’t fall into the tank.

Step 4: Disconnect the electrical connector

• Press the lock tab and unplug the fuel pump electrical connector by hand.
• If the tab is stubborn, use a small flat-blade screwdriver gently on the lock tab (do not pry on wires).

Step 5: Disconnect fuel lines (quick-connect fittings)

• Place a drain pan and shop towels under the lines.
• Use a fuel line quick-disconnect pick set to release the quick-connect locks, then pull the line straight off.
• Cap/cover the open lines with clean shop towels to keep dirt out.
• Expect a small fuel dribble—this is normal.

Step 6: Mark the pump module orientation

• Use a non-marring marker or paint pen to mark the position of the lock ring and module relative to the tank opening.
• This helps you reinstall it in the same orientation so hoses and wiring lay correctly.

Step 7: Remove the fuel pump lock ring

• Use a fuel pump lock ring wrench (specialty) to loosen and remove the lock ring.
• Lift the lock ring off and set it aside in a clean area.
• Torque spec (lock ring): Torque to 53 Nm (39 ft-lbs)

Step 8: Remove the fuel pump module

• Lift the module straight up slowly; angle it as needed to clear the float arm (the fuel level “float” is the little arm that reads fuel level).
• Let fuel drain from the module into the tank opening, then move it to the drain pan.
• Remove and discard the old tank seal/gasket from the tank opening using needle-nose pliers if needed.

Step 9: Install the new seal and pump module

• Place the new fuel pump tank seal/gasket onto the tank opening, fully seated and not twisted.
• Carefully lower the new module into the tank, guiding the float arm in without bending it.
• Align your orientation marks.

Step 10: Reinstall and tighten the lock ring

• Install the lock ring by hand first to prevent cross-threading.
• Tighten the ring using the fuel pump lock ring wrench (specialty).
• Torque spec (lock ring): Torque to 53 Nm (39 ft-lbs)

Step 11: Reconnect fuel lines and electrical

• Push fuel lines on until you feel/hear a solid click; tug lightly to confirm they’re locked.
• Reconnect the electrical connector by hand until it clicks.
• Wipe the area clean with shop towels so any new leak is easy to spot.

Step 12: Reinstall access cover and rear seat

• Reinstall the access cover using a Phillips #2 screwdriver.
• Reinstall the rear seat bottom: hook the rear edge, then push down firmly at the front to snap the clips in.

Step 13: Restore power and prime the fuel system

• Reinstall the fuel pump fuse/relay.
• Reconnect the negative battery cable using a 10mm socket.
• Turn the key to ON (engine off) for 5 seconds, then OFF; repeat 3 times to prime the system.
• Start the engine.

---

✅ After Repair

• 🔍 With the engine idling, check the pump top and fuel line connections for any wetness or fuel smell.
• 🧯 If you see a leak, shut the engine off immediately and re-seat the line or lock ring.
• 🚗 Test drive for 10–15 minutes, then re-check for leaks and odors once parked.
• 🛠️ If a check engine light appears, scan and clear codes after confirming no leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,200 (parts + labor)

DIY Cost: $180-$550 (parts only)

You Save: $470-$650 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
