🔧 Highlander - Fuel Pump Replacement

On your Highlander, the fuel pump sits inside the fuel tank as part of a “fuel pump module” (pump + level sender + filter/strainer). Most repairs are done through an access panel under the rear seat—no tank removal—then you reseal everything and verify there are no leaks.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🧯 Work outside or in a very well-ventilated area; fuel vapors ignite easily.
• 🔥 No smoking, no sparks, no shop lights with hot bulbs; keep a fire extinguisher nearby.
• 🔋 Disconnect the negative battery cable before opening the tank.
• ⛔ Relieve fuel pressure before disconnecting any fuel line.
• 🧼 Clean dirt from the pump area so debris can’t fall into the tank.
• 🧤 Wear gloves and safety glasses; gasoline irritates skin and eyes.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Fire extinguisher (Class B)
• 10mm socket
• 12mm socket
• 3/8" drive ratchet
• 3/8" drive extension (6")
• Torque wrench (inch-pound, 20–200 in-lb range)
• Phillips screwdriver
• Plastic trim removal tool set
• Needle-nose pliers
• Brass drift/punch
• Small hammer
• Pick tool set
• Shop towels
• Catch pan (fuel-safe)
• Handheld vacuum
• Permanent marker

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Fuel pump module assembly - Qty: 1
• Fuel pump module seal / O-ring - Qty: 1
• Fuel pump strainer (sock filter) - Qty: 1
• Fuel line O-rings (quick-connect set) - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• ⛽ Try to work with less than 1/4 tank to reduce spills.
• 🧹 Vacuum and wipe the rear seat area so dirt doesn’t fall into the tank.
• 🔋 Plan to disconnect the negative battery cable using a 10mm socket.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve fuel pressure

• Open the fuel door and loosen the gas cap to vent tank pressure.
• Turn the ignition OFF and remove the key fob from the vehicle area.
• If you have access to the under-hood fuse/relay box, remove the fuel pump circuit (EFI/fuel pump) and crank/start until it stalls; then crank 2-3 more seconds. Less pressure = less spray.
• Turn ignition OFF.

Step 2: Disconnect the battery

• Use a 10mm socket to disconnect the negative battery cable and isolate it so it can’t spring back.

Step 3: Access the fuel pump service cover

• Fold/position the 2nd-row seat as needed to access the rear seat cushion area.
• Use a plastic trim removal tool set to release clips and lift the rear seat cushion (or panels) to expose the service cover area.
• If your Highlander does not have an access cover, the tank must be lowered. Stop here and tell me, and I’ll give you the tank-drop procedure.

Step 4: Remove the service cover

• Use a 10mm socket (or Phillips screwdriver, depending on fasteners) to remove the service cover screws/bolts.
• Lift the cover and set it aside on shop towels.

Step 5: Clean the area and mark alignment

• Use a handheld vacuum and shop towels to remove all dust/dirt around the pump module flange.
• Use a permanent marker to mark the module orientation to the tank (helps prevent misalignment on install).

Step 6: Disconnect the electrical connector(s)

• Press the lock tab and unplug the connector(s) by hand; use a pick tool set gently if the tab is stuck.

Step 7: Disconnect the fuel line(s)

• Place a catch pan (fuel-safe) and shop towels under the connection.
• Release the quick-connect fitting (usually squeeze tabs or lift a lock), then pull the line straight off.
• Use needle-nose pliers only if a clip must be removed; don’t crush plastic fittings.

Step 8: Remove the pump retaining ring / fasteners

• If equipped with a lock ring: use a brass drift/punch and small hammer to tap the ring counterclockwise until it releases.
• If equipped with small flange nuts/bolts: use a 10mm socket to remove them evenly in a crisscross pattern.

Step 9: Remove the fuel pump module

• Lift the module slowly; tilt it as needed to clear the float arm (fuel level sensor).
• Let fuel drain from the module into the catch pan (fuel-safe).
• Remove and discard the old tank seal/O-ring using a pick tool set.

Step 10: Install the new seal and module

• Wipe the tank sealing surface clean with shop towels; do not let debris fall into the tank.
• Install the new fuel pump module seal / O-ring in the correct groove (no twists).
• Lower the new module in, guiding the float arm carefully, and align it to your marker line.

Step 11: Secure the module

• If equipped with flange nuts/bolts: tighten evenly in a crisscross pattern using a 10mm socket, then use a torque wrench (inch-pound): Torque to 5.5 Nm (49 in-lb).
• If equipped with a lock ring: tap it clockwise using the brass drift/punch and small hammer until fully seated and aligned.

Step 12: Reconnect fuel line(s) and electrical

• Reconnect the fuel line quick-connect until it clicks; pull back gently to confirm it’s locked.
• Install any new fuel line O-rings if your connection style uses them.
• Plug the electrical connector(s) back in until the tab clicks.

Step 13: Reinstall service cover and seat trim

• Reinstall the service cover using a 10mm socket or Phillips screwdriver.
• Reinstall the rear seat cushion/panels using the plastic trim removal tool set to line up clips without breaking them.

Step 14: Restore power and prime the system

• Reconnect the negative battery cable using a 10mm socket.
• Turn ignition ON (engine OFF) for 5 seconds, then OFF for 5 seconds; repeat 3 times to prime pressure.
• Start the engine and let it idle.

---

✅ After Repair

• 👃 Check carefully for fuel smell around the rear seat area and under the vehicle.
• 🧻 With the engine idling, inspect the fuel line connection for seepage; shut off immediately if wet.
• 🛠️ If the check engine light comes on, scan for codes and address any EVAP/fuel pressure related faults.
• 🚗 Road test 10-15 minutes, then recheck for leaks once parked.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,600 (parts + labor)

DIY Cost: $300-$900 (parts only)

You Save: $600-$700 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
