🔧 86 - Fuel Pump Replacement

On your 86, the fuel pump sits inside the fuel tank as a complete module. Replacing it means safely relieving fuel pressure, opening the in-car access panel, swapping the pump/module, and sealing everything back up so there are no fuel smells or leaks.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🔥 Work outside or in a very well-ventilated area; gasoline fumes are highly flammable.
• 🧯 No smoking, no hot lights, no power tools that spark near the open tank.
• 🧤 Wear gloves and safety glasses; fuel can irritate skin and eyes.
• 🔋 Disconnect the negative battery terminal before opening the fuel system.
• ⚠️ Relieve fuel pressure before disconnecting any fuel line to avoid a high-pressure spray.
• 🧼 Clean dirt around the pump opening so debris doesn’t fall into the tank.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 10mm ratchet
• 6-inch extension for 3/8" drive ratchet
• Phillips #2 screwdriver
• Trim panel removal tool
• Small flat-blade screwdriver
• Fuel line quick-disconnect pick tool
• Fuel pump lock ring wrench (specialty)
• Torque wrench (10–100 Nm range)
• Shop rags
• Catch pan
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• In-tank fuel pump module assembly - Qty: 1
• Fuel pump module tank seal O-ring/gasket - Qty: 1
• Fuel pump strainer (sock filter) - Qty: 1
• Butyl body sealant strip - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Lower the fuel level if possible (under 1/2 tank is easier and reduces spill risk).
• Have rags ready and a catch pan nearby for small fuel drips.
• Know your goal: replacing the whole module is the cleanest DIY. Replacing only the pump motor means more small clips and seals inside the module.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve fuel pressure

• Open the hood.
• Use a 10mm socket and 10mm ratchet to loosen and remove the negative battery cable from the battery terminal.
• Locate the under-hood fuse/relay box and remove the fuel pump fuse/relay (use your fuse-box cover diagram).
• Reconnect the negative battery cable temporarily using the 10mm socket, start the engine, and let it run until it stalls.
• Crank the engine for 3–5 seconds to remove remaining pressure, then turn ignition OFF.
• Disconnect the negative battery cable again using the 10mm socket.

Step 2: Access the fuel pump service cover

• Move the front seats forward for room.
• Remove the rear seat bottom cushion (release the front clips). Use a trim panel removal tool to avoid tearing the upholstery.
• Find the metal service cover over the fuel pump area.
• Use a Phillips #2 screwdriver (or 10mm socket, depending on fasteners) to remove the service cover screws/bolts.
• Peel back any factory sealing material carefully; you’ll reseal it later with butyl body sealant strip.

Step 3: Clean the area and disconnect the electrical connector

• Use shop rags to wipe and remove loose dirt around the pump module top.
• Unplug the pump electrical connector by releasing the lock tab with a small flat-blade screwdriver (gentle pressure only).

Step 4: Disconnect the fuel lines

• Place a catch pan and shop rags under the line connections.
• Use the fuel line quick-disconnect pick tool to release the quick-connect fitting(s), then pull the line straight off.
• Tip: Pull straight—twisting can damage the connector.

Step 5: Remove the lock ring and lift out the pump module

• Mark the orientation of the pump module to the tank with a small alignment mark (so it goes back in the same direction).
• Use the fuel pump lock ring wrench (specialty) to loosen and remove the retaining lock ring.
• Lift the pump module up slowly. Angle it as needed to clear the float arm (fuel level sender).
• Let fuel drain from the module into the tank, then set the module into the catch pan.
• Remove and discard the old tank seal O-ring/gasket.

Step 6: Install the new pump/module and new seal

• Install the new fuel pump module tank seal O-ring/gasket in the tank groove (make sure it’s flat and not twisted).
• Lower the new pump module into the tank, keeping the float arm from bending.
• Align it to your orientation mark.
• Install the lock ring and tighten using the fuel pump lock ring wrench (specialty).
• Use a torque wrench to tighten the lock ring to Torque to 67 Nm (49 ft-lbs).

Step 7: Reconnect fuel lines and electrical connector

• Push the quick-connect fuel line(s) on until you feel/hear a solid click.
• Gently tug-test each line to confirm it’s locked.
• Reconnect the electrical connector until it clicks into place.

Step 8: Reseal the service cover and reinstall the seat

• Reinstall the service cover using the Phillips #2 screwdriver (or 10mm socket if equipped).
• Reseal the cover perimeter using the butyl body sealant strip to prevent fuel vapor smells in the cabin.
• Reinstall the rear seat bottom cushion by aligning the rear hooks and pressing down to engage the front clips.

Step 9: Prime the system and check for leaks

• Reconnect the negative battery cable using the 10mm socket.
• Turn ignition ON (do not start) for 5 seconds, then OFF for 5 seconds. Repeat 3 times to prime the system.
• Start the engine and inspect the pump top area (under the seat access) for any seepage.
• If you smell fuel strongly, shut it off and recheck the seal, lock ring, and quick-connects.

---

✅ After Repair

• Verify the engine starts quickly and idles smoothly.
• Check for fuel leaks again after a short 5–10 minute drive.
• Confirm the fuel gauge reads normally (a bent float arm can cause bad readings).
• If a check engine light appears, scan codes and recheck connectors and line seating.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,200 (parts + labor)

DIY Cost: $200-$650 (parts only)

You Save: $450-$550 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
