🔧 Grand Cherokee - Fuel Pump Replacement

The fuel pump on your Grand Cherokee is part of an in-tank fuel pump module. Replacing it means safely relieving fuel pressure, opening the access panel under the rear seat area, swapping the module and seal, then priming the system and checking carefully for leaks.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Work outside or in a very well-ventilated area; gasoline fumes are highly flammable.
• ⚠️ No smoking, sparks, hot bulbs, or grinding tools anywhere near the vehicle.
• ⚠️ Relieve fuel pressure before disconnecting any fuel line to prevent spray.
• ⚠️ Disconnect the negative battery cable before opening the tank access.
• ⚠️ Keep a Class B fire extinguisher nearby.
• ⚠️ Clean dirt off the top of the tank/module before opening it; dirt in the tank can ruin the new pump.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Class B fire extinguisher
• Trim clip removal tool
• Flat-blade screwdriver
• Phillips screwdriver
• Ratchet
• 10mm socket
• 13mm socket
• Extension bar 6"
• Torque wrench 10-100 Nm
• Fuel line quick-disconnect tool set (specialty)
• Fuel pump lock ring tool (specialty)
• Brass punch
• Dead-blow hammer
• Shop rags
• Hand vacuum or small shop vacuum
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Fuel pump module assembly - Qty: 1
• Fuel pump module tank seal O-ring - Qty: 1
• Fuel pump lock ring - Qty: 1
• Fuel line retaining clips - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and keep the area ventilated.
• Try to work with the fuel level low (around 1/4 tank or less) to reduce spills and fumes.
• Open the fuel door and loosen the gas cap to help release tank vapor pressure.
• Know these terms: a quick-connect is a push-on fuel fitting that releases with a clip; a lock ring is the large ring that twists to hold the pump module into the tank.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Relieve fuel pressure

• Open the hood.
• Remove the fuel pump relay/fuse from the under-hood fuse box (use the fuse box diagram on the cover).
• Start the engine and let it run until it stalls.
• Crank for 3-5 seconds one more time to bleed off remaining pressure.
• Turn ignition OFF and remove the key.

Step 2: Disconnect the battery

• Use a 10mm socket to disconnect the negative battery cable.
• Move the cable aside so it can’t spring back onto the terminal.

Step 3: Remove the rear seat cushion and access cover

• Remove the rear seat bottom cushion (release the front edge latches; some setups use fasteners).
• If bolts are present, remove them using a 13mm socket and ratchet.
• Lift the carpet/sound insulation as needed to expose the fuel pump access panel.
• Remove the access cover fasteners using a Phillips screwdriver or 10mm socket (varies by cover) and lift the cover.
• Tip: Bag and label fasteners.

Step 4: Clean the area thoroughly

• Use a hand vacuum or small shop vacuum to remove dust around the module top.
• Wipe with shop rags so no dirt can fall into the tank once opened.

Step 5: Disconnect the electrical connector and fuel lines

• Unplug the pump electrical connector by releasing the tab with a flat-blade screwdriver (gentle—don’t break the tab).
• Place shop rags around the fuel line connections to catch drips.
• Disconnect the fuel supply/return/EVAP quick-connect fittings using a fuel line quick-disconnect tool set (specialty) as needed.
• Pull lines straight off—do not twist aggressively.

Step 6: Remove the fuel pump lock ring

• Mark the pump module orientation with a flat-blade screwdriver (small reference mark) so the new one goes in the same way.
• Use a fuel pump lock ring tool (specialty) to rotate the lock ring counterclockwise and remove it.
• If using a punch method: use a brass punch and dead-blow hammer to tap the lock ring around evenly (brass helps reduce spark risk).
• Remove the lock ring and set it aside (replace it if your new parts list includes one).

Step 7: Remove the fuel pump module

• Carefully lift the module straight up. Angle it slightly as needed to clear the tank opening.
• Allow fuel to drain from the module back into the tank before fully removing it.
• Remove and discard the old tank seal O-ring.

Step 8: Install the new seal and fuel pump module

• Install the new tank seal O-ring into the tank groove (make sure it sits flat, not twisted).
• Lower the new pump module into the tank in the same orientation as the old one.
• Ensure the module flange sits evenly on the new seal.

Step 9: Reinstall and tighten the lock ring

• Install the lock ring and start it by hand.
• Use the fuel pump lock ring tool (specialty) to tighten until the lock ring is fully seated and the alignment marks/tabs match the tank/module stops.
• Torque to factory specification if using a lock-ring tool that accepts a torque wrench; otherwise tighten to full seated stop per ring marks.

Step 10: Reconnect fuel lines and electrical

• Reconnect each fuel line until you hear/feel a solid “click.”
• Gently tug-test each line by hand to confirm it’s locked.
• Reconnect the electrical connector until it clicks.

Step 11: Reinstall the access cover and rear seat

• Reinstall the access cover fasteners using a Phillips screwdriver or 10mm socket.
• Reposition carpet/insulation.
• Reinstall the rear seat cushion and any bolts using a 13mm socket and torque wrench.
• Torque to factory specification for any seat/cushion bolts removed.

Step 12: Restore power and prime the fuel system

• Reinstall the fuel pump relay/fuse you removed.
• Reconnect the negative battery cable using a 10mm socket.
• Turn ignition to RUN (do not start) for 5 seconds, then OFF for 5 seconds.
• Repeat that 3-4 times to prime the system.

---

✅ After Repair

• Start the engine and let it idle for 2-3 minutes.
• Check for fuel smell and inspect the module top and line connections for leaks.
• If the engine cranks longer than normal, cycle the key RUN/OFF a few more times to prime.
• Road test for 10-15 minutes, then recheck for any seepage under the access panel.
• If a check-engine light appears, scan the vehicle—loose EVAP/fuel connections can set codes.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,600 (parts + labor)

DIY Cost: $250-$700 (parts only)

You Save: $650-$900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
