🔧 Front Window Regulator - Replacement

The front door trim panel has to come off first, then the glass must be unbolted from the regulator and secured in place. After that, the regulator/motor assembly can be removed from the door and the new one installed, then the glass is reconnected and tested.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• Disconnect the negative battery cable before starting. The window switch, door wiring, and side airbag circuits are in the door.
• Do not turn the ignition on while the door panel is unplugged unless needed for testing.
• Support the glass carefully with tape. A loose window can drop and crack.
• Keep hands clear of the regulator tracks. The mechanism can pinch fingers.
• Use care around the side curtain airbag area in the door frame and upper trim.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4-inch ratchet
• Short extension
• Phillips screwdriver
• Plastic trim removal tool
• Panel clip pliers
• Needle-nose pliers
• Torque wrench
• Painter's tape
• Safety glasses
• Gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front window regulator assembly - Qty: 2
• Front window regulator motor - Qty: 2 if not included with regulator
• Door panel clip set - Qty: 1
• Door vapor barrier adhesive tape - Qty: 1

---

📋 Before You Begin

• Park on level ground with the parking brake set.
• Lower the front window slightly if it still moves, then disconnect the battery.
• Save any radio and clock settings before battery disconnect.
• Have painter's tape ready to hold the glass up once the door panel is off.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect power and prepare the door

• Use a 10mm socket to disconnect the negative battery cable.
• Wait at least 90 seconds before working near the door wiring.
• Lower the front glass slightly if it still operates, then leave it in place.
• Keep the glass supported before unbolting it.

Step 2: Remove the front door trim panel

• Use a plastic trim removal tool to pop off the trim covers and pry the door panel clips loose.
• Use a Phillips screwdriver to remove the exposed screws in the pull handle and around the panel.
• Lift the panel straight up and away from the door.
• Unplug the window switch and any courtesy light connectors.
• Work slowly to avoid breaking clips.

Step 3: Remove the moisture barrier

• Peel back the door vapor barrier carefully.
• If the adhesive is still good, keep it clean so it can be reused.
• Do not tear it if you can help it.

Step 4: Secure the glass

• Use painter's tape across the top of the door frame and over the glass to hold the window fully up.
• If the glass is already stuck in a low position, raise it by hand and tape it securely.
• Make sure the glass cannot fall when the regulator is removed.

Step 5: Disconnect the glass from the regulator

• Use a 10mm socket to remove the glass-to-regulator bolts through the access holes in the door inner panel.
• Slide the glass fully up and keep it taped in place.
• Check that the glass is stable before moving on.

Step 6: Remove the regulator and motor assembly

• Use a 10mm socket and 1/4-inch ratchet with a short extension to remove the regulator mounting bolts.
• Unplug the regulator motor electrical connector.
• Rotate and work the assembly out through the largest access opening in the door.
• If the motor is separate, transfer it to the new regulator now using a 10mm socket.
• Note bolt locations before removal.

Step 7: Install the new regulator

• Feed the new regulator into the door opening in the same orientation as the old one.
• Start all mounting bolts by hand first.
• Reconnect the motor connector.
• Tighten the regulator mounting bolts with a 10mm socket.
• Torque to 7 N·m (62 in-lbs).

Step 8: Reattach the glass

• Remove the painter's tape carefully while supporting the glass.
• Lower the glass into the regulator clamps.
• Install the glass-to-regulator bolts using a 10mm socket.
• Torque to 7 N·m (62 in-lbs).
• Make sure the glass sits evenly in both channels.

Step 9: Test the window movement

• Reconnect the battery negative cable with a 10mm socket.
• Turn the ignition on and use the window switch to move the glass up and down.
• Watch for binding, tilting, or unusual noise.
• If the glass moves unevenly, stop and realign it before reinstalling the panel.

Step 10: Reinstall the moisture barrier and door panel

• Press the vapor barrier back into place and seal any lifted edges.
• Reconnect all electrical plugs to the door panel.
• Align the panel clips and press the panel onto the door.
• Reinstall the screws with a Phillips screwdriver.
• Snap the trim covers back in place with a plastic trim removal tool.

---

✅ After Repair

• Cycle the front window fully up and down several times.
• Check for smooth travel and proper sealing at the top.
• Listen for rattles inside the door.
• If the auto-up or auto-down feature is not working, perform the window initialization by holding the switch in the full-up position for a few seconds, then full-down and full-up again.

---
