🔧 Front Lower Ball Joint - Replacement

This replaces the worn front lower ball joint on your CX-5. On this model, the ball joint is serviced at the front lower suspension arm area, and wear usually shows up as clunking, steering looseness, or uneven tire wear.

Difficulty Level: Advanced | Estimated Time: 2-4 hours per side

---

⚠️ Safety & Precautions

• Support the vehicle with jack stands; never work under a vehicle held only by a jack.
• Use wheel chocks on the opposite wheels.
• The front suspension is loaded with spring force; keep hands clear when separating the knuckle and control arm.
• If equipped with a wheel speed sensor wire near the knuckle, do not twist or pull it.
• After replacement, an alignment is required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated for vehicle weight)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Breaker bar
• Torque wrench
• 21mm socket
• 19mm socket
• 17mm socket
• 14mm socket
• Ratchet
• Penetrating oil
• Ball joint separator (specialty)
• Hammer
• Pry bar
• Needle-nose pliers
• Trim clip removal tool
• Paint marker

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front lower ball joint - Qty: 1 per side
• Ball joint pinch bolt and nut - Qty: 1 per side
• Cotter pin - Qty: 1 per side
• Front suspension nut kit - Qty: 1 set
• Wheel alignment service - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Loosen the front wheel lug nuts slightly before lifting.
• Raise the front of the vehicle and support it securely on jack stands.
• If the nut hardware is rusty, spray penetrating oil and let it soak before removal.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wheel

• Use a 21mm socket to remove the front wheel lug nuts.
• Remove the wheel and set it aside flat.

Step 2: Access the ball joint area

• Use a 14mm socket and trim clip removal tool to remove any splash shield fasteners blocking access.
• Inspect the lower control arm, steering knuckle, and ball joint for damage.

Step 3: Separate the ball joint from the knuckle

• Use a 17mm socket and breaker bar to remove the ball joint pinch bolt and nut.
• Use a ball joint separator (specialty) to free the ball joint stud from the knuckle.
• Do not strike the stud threads.

Step 4: Remove the ball joint from the lower arm

• Use a 14mm socket or 19mm socket depending on the fastener style to remove the ball joint mounting hardware.
• Lower the arm slightly with a pry bar if needed to release tension.
• Remove the old ball joint.

Step 5: Install the new ball joint

• Position the new ball joint in the control arm.
• Install the mounting hardware finger-tight first.
• Insert the stud into the knuckle and install the new pinch bolt and nut.
• Torque to 49 Nm (36 ft-lbs) for the pinch bolt, if your replacement hardware matches the factory fastener style.

Step 6: Tighten the mounting fasteners

• Use the appropriate 14mm socket or 19mm socket to tighten the ball joint mounting fasteners.
• Torque to 49-68 Nm (36-50 ft-lbs) for the ball joint mounting fasteners, depending on the replacement hardware design.
• Install a new cotter pin if your setup uses one.

Step 7: Reinstall the wheel

• Reinstall the wheel and hand-tighten the lug nuts.
• Lower the vehicle to the ground.
• Use a torque wrench and 21mm socket to tighten the lug nuts in a star pattern.
• Torque to 108 Nm (80 ft-lbs).

Step 8: Final inspection

• Turn the steering wheel lock-to-lock and confirm there is no binding.
• Check that all fasteners are fully seated.
• Road test slowly and listen for clunks or popping.

---

✅ After Repair

• Get a four-wheel alignment as soon as possible.
• Recheck lug nut torque after about 50-100 km of driving.
• If the steering wheel is off-center, return for alignment correction.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$700 per side (parts + labor)

DIY Cost: $80-$180 per side (parts only)

You Save: $270-$520 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
