🔧 Rogue - Engine Air Filter Replacement

You’ll be replacing the engine air filter in your Rogue’s air box to keep the engine breathing clean air and running efficiently. This is a great first DIY job and requires only basic tools.

Difficulty Level: Beginner | Estimated Time: 15-25 minutes

---

⚠️ Safety & Precautions

• 🛑 Make sure the engine is off and the key is out of the vehicle.
• 🔥 Let the engine cool for at least 15 minutes to avoid hot parts.
• 🧤 Keep fingers away from the radiator fan area; it can start if the engine runs.
• 🔋 Battery disconnection is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 1/4" drive ratchet
• 1/4" drive extension (3"-6")
• Flathead screwdriver (medium)
• Clean shop towel
• Work gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine air filter element - Qty: 1
• Air box cover screws or clips - Qty: As needed if any are damaged

---

📋 Before You Begin

• Park the Rogue on level ground and set the parking brake.
• Shift the transmission to Park and turn the engine off.
• Open the hood using the interior hood release, then the hood safety catch at the front.
• Use the hood prop rod to securely hold the hood open.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the air filter box

• Stand in front of your Rogue and look slightly to the left side of the engine bay.
• The air filter box is a black plastic box with a large rubber hose (air intake duct) going to the engine.
• Wipe off loose dust from the top with a clean shop towel so dirt doesn’t fall inside later.

Step 2: Inspect how the air box cover is fastened

• On the 2021 Rogue, the air box cover is usually held by metal clips at the front and/or side and may have one or two 10mm bolts at the back.
• Check for:
  • Metal spring clips along the front edge.
  • Possible 10mm bolts near the rear edge.
• Take a quick photo so you remember how it sits.

Step 3: Release the air box cover

• If there are metal clips:
  • Use your fingers or a flathead screwdriver to gently pry the clips off the cover lip.
• If there are bolts:
  • Use a 10mm socket with a 1/4" drive ratchet (and extension if needed) to loosen and remove the bolts.
  • Torque on reassembly: 3–5 Nm (27–44 in-lbs) (snug, not very tight).
• Gently lift the front/side of the air box cover. You do not need to completely remove the cover; just open it enough to access the filter.
• Do not pull hard on any attached hoses or wires.

Step 4: Remove the old air filter

• Look inside the opened box. You’ll see the rectangular air filter sitting in a plastic tray.
• Grasp the filter by one of the corners and lift it straight up and out using your hands.
• Note the orientation: which side faces up and which edge faces the engine.
• Match “up” side of old and new filters.

Step 5: Clean the air box

• With the filter removed, inspect the bottom of the air box for leaves, sand, or debris.
• Use a clean shop towel to wipe out loose dirt from the bottom and sides.
• If you have a vacuum, you can carefully vacuum the bottom of the box, but do not damage any plastic surfaces.
• Do not use water or cleaners inside the box.

Step 6: Install the new air filter

• Compare the new filter to the old one to confirm size and shape match.
• Place the new filter into the air box tray with the same orientation as the old one:
  • The rubber sealing edge should sit neatly against the plastic edges of the box.
  • Make sure the filter sits flat all the way around; no edge should be folded or sitting on top of the lip.
• Press gently around the edges to ensure a good seal.
• If it won’t sit flat, it’s likely rotated wrong.

Step 7: Refit and secure the air box cover

• Lower the air box cover back into place, making sure the rear edge and any locating tabs slide into their slots first.
• Check that the cover sits evenly all the way around and is not pinching the filter.
• If there are bolts:
  • Install the bolts by hand to avoid cross-threading.
  • Tighten using a 10mm socket and 1/4" drive ratchet.
  • Torque to 3–5 Nm (27–44 in-lbs) – just snug; do not overtighten.
• If there are clips:
  • Re-latch each clip using your fingers or a flathead screwdriver if needed.
  • Verify each clip is fully engaged on the cover lip.
• Gently tug the cover to confirm it is secure and does not lift.

Step 8: Final under-hood check

• Look around the area you worked on for any tools or towels and remove them.
• Check that the large rubber air intake duct is still firmly attached to the air box and the engine side. If you see a clamp, make sure it is not loose.
• Remove the hood prop rod and close the hood securely.

---

✅ After Repair

• Start the engine and let it idle for a minute. You should not hear any unusual hissing or whistling from the air box area.
• Lightly press the accelerator; the engine should respond smoothly.
• No warning lights should appear on the dash as a result of this job.
• Make a note of the date and mileage so you know when you last changed the filter.

---

💰 DIY vs Shop Cost

Shop Cost: $60–$110 (parts + labor)

DIY Cost: $15–$35 (parts only)

You Save: $45–$75 by doing it yourself!

Shop labor rates typically run $100–$150/hour. This repair takes a shop approximately 0.3–0.5 hours.

---
