🔧 Camry - Engine Air Filter Replacement

You’ll be replacing the engine air filter inside the black plastic air box in the engine bay. This helps your engine breathe clean air and can improve performance and fuel economy.

Difficulty Level: Beginner | Estimated Time: 10-20 minutes

---

⚠️ Safety & Precautions

• 🛑 Make sure the engine is off and the key is out of the ignition.
• 🛑 Let the engine cool for at least 10 minutes so you don’t touch hot parts.
• 🛑 Keep fingers and tools away from the radiator fan; it can start if the engine is on.
• 🛑 You do not need to disconnect the battery for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 10mm socket
• 🧰 1/4" ratchet
• 🧰 3" socket extension
• 🧰 Flathead screwdriver (4-6 mm tip)
• 🧰 Work gloves
• 🧰 Safety glasses
• 🧰 Shop towel or clean rag

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 📦 Engine air filter element (for 2.5L engine) - Qty: 1

---

📋 Before You Begin

• 📌 Park your Camry on level ground, shift to Park, and set the parking brake.
• 📌 Turn off the engine and remove the key or shut off the start button.
• 📌 Open the hood using the interior hood release, then unlatch the hood at the front and use the hood prop rod to hold it up.
• 📌 Make sure you have enough light to clearly see the air box area.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the engine air filter box

• Look at the engine bay from the front of your Camry with the hood open.
• The engine air box is a black plastic box on the driver’s side near the front, with a large plastic tube (air intake duct) going from it toward the engine.
• It’s on top and easy to reach.

Step 2: Identify clips and fasteners

• On the 2020 Camry, the air box lid is held by metal spring clips and may have one 10mm bolt at the front edge.
• Find:
  • Two or more metal clips along the sides of the air box lid.
  • A possible 10mm bolt at the front of the lid.

Step 3: Remove the 10mm bolt (if equipped)

• Use the 10mm socket, 3" socket extension, and 1/4" ratchet to loosen and remove the bolt at the front of the air box lid.
• Set the bolt in a safe place so it doesn’t fall into the engine bay.
• If your air box has no bolt, skip this step.

Step 4: Release the air box lid clips

• Use your fingers or the flathead screwdriver to gently pry and release each metal clip holding the lid.
• Pull the clips away from the lid until they pop off the edge.
• Be gentle so clips don’t fly off.

Step 5: Lift and move the air box lid

• Gently lift the front edge of the air box lid.
• The rear of the lid usually has tabs that slide into slots; don’t force it straight up from the back.
• Lift the front and then slide the lid slightly backward, just enough to see and access the filter inside.
• You do not need to disconnect any attached hoses; just tilt the lid up and rest it carefully.

Step 6: Remove the old air filter

• Note how the old filter is sitting: rubber sealing edge orientation and which side faces up.
• Lift the old filter straight up and out using your hands.
• If there is dust or leaves at the bottom of the air box, use the shop towel to wipe it out, or gently blow it out if you have compressed air (keep dirt from going into the intake opening).
• Do not push debris down the intake tube.

Step 7: Compare old and new filters

• Place the old and new filters side by side.
• Make sure:
  • They are the same size and shape.
  • The rubber sealing edge matches.
• If they don’t match, do not force the new filter in; you may have the wrong part.

Step 8: Install the new air filter

• Place the new filter into the air box with the same orientation as the old one (rubber edge seated all the way around the lip of the box).
• Press gently around the edges with your fingers to ensure it sits flat and fully sealed.
• No gaps should be visible around the edges.

Step 9: Refit the air box lid

• Align the rear tabs of the lid with the slots at the back of the air box.
• Slide the rear of the lid into place first, then lower the front of the lid down over the new filter.
• Make sure the lid edges sit evenly on the air box and are not pinching the filter.

Step 10: Reattach clips and bolt

• Snap each metal clip back over the edge of the lid using your fingers or the flathead screwdriver to help if needed.
• If your air box has a front bolt, reinstall it by hand first, then tighten it with the 10mm socket, extension, and ratchet.
• Snug the bolt gently: Tighten to about 5–7 Nm (4–5 ft-lbs) — just firm, do not over-tighten.

Step 11: Final check

• Look around the air box:
  • All clips engaged.
  • Front bolt (if equipped) tightened.
  • No tools or rags left in the engine bay.

---

✅ After Repair

• 🚗 Start the engine and let it idle for a minute; listen for any odd whistling or hissing near the air box (which could mean the lid is not sealed). If you hear something, shut off the engine and recheck the clips and fitment.
• 🚗 Take a short drive; throttle response should feel normal or slightly smoother.
• 🚗 No scan tool or reset is needed after a simple air filter change on your Camry.

---

💰 DIY vs Shop Cost

Shop Cost: $60–$110 (parts + labor)

DIY Cost: $15–$35 (parts only)

You Save: $45–$75 by doing it yourself!

Shop labor rates typically run $100–$150/hour. This repair takes a shop approximately 0.3 hours.

---
