🔧 Terrain - Engine Air Filter Replacement

Your Terrain’s engine air filter sits in the air filter box (air cleaner housing) and keeps dust out of the turbocharged engine. Replacing it restores airflow and helps fuel economy and throttle response.

Difficulty Level: Beginner | Estimated Time: 0.2-0.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine to avoid burns from hot components.
• ⚠️ Keep dirt/leaves from falling into the intake tube or air box.
• ⚠️ No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Flat trim tool
• 8mm socket
• 1/4" ratchet
• 1/4" extension (3")
• Torx T20 screwdriver
• Shop towel
• Handheld vacuum
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Open the hood and locate the air filter box (black plastic box connected to the intake tube).
• Quick check: look at the air box lid—some Terrains use metal retaining clips, others use screws. If you tell me which you have, I can tailor the steps perfectly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the air filter box

• Use a flashlight to find the air filter box and the intake tube that runs to it.
• If a plastic engine cover is in the way, lift it off using a flat trim tool (it pulls up from rubber grommets). Pull straight up, don’t twist.

Step 2: Open the air box (choose the setup that matches yours)

• If your lid has metal clips: release each clip by hand; if tight, gently pry with a flat trim tool.
• If your lid uses screws: loosen/remove them using an 8mm socket with a 1/4" ratchet and 1/4" extension (3"), or a Torx T20 screwdriver if your screws are Torx.
• Lift the lid just enough to remove the filter—don’t yank on hoses or wiring.

Step 3: Remove the old filter

• Pull the filter straight up/out by hand.
• Use a shop towel to cover the lower opening briefly so debris can’t fall in.

Step 4: Clean the air box sealing surface

• Use a handheld vacuum to remove leaves/dust from the air box (avoid pushing dirt into the intake opening).
• Wipe the sealing edge where the filter sits using a shop towel. A clean seal prevents unfiltered air leaks.

Step 5: Install the new filter

• Install the new filter in the same direction as the old one.
• Make sure the rubber edge sits flat all the way around (no waves or gaps).

Step 6: Close and secure the air box

• Lower the lid fully so it sits evenly.
• Re-latch the clips by hand, or tighten screws using an 8mm socket with a 1/4" ratchet (snug only—do not overtighten plastic).

Step 7: Recheck your work

• Use a flashlight to confirm: lid is seated evenly, all clips/screws are secured, and no tools are left in the engine bay.

---

✅ After Repair

• Start the engine and let it idle for 15–30 seconds; listen for hissing/whistling that could indicate the air box isn’t sealed.
• If you removed the engine cover, reinstall it by pressing down firmly by hand.

---

💰 DIY vs Shop Cost

Shop Cost: $60-$130 (parts + labor)

DIY Cost: $15-$40 (parts only)

You Save: $45-$90 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.5 hours.

---
