🔧 Rogue - Engine Air Filter Replacement

You’ll be replacing the engine air filter inside the black plastic air box in the engine bay. A clean filter helps your engine breathe better, improving performance and fuel economy.

Difficulty Level: Beginner | Estimated Time: 15-30 minutes

---

⚠️ Safety & Precautions

• 🛑 Turn the engine off and remove the key from the vehicle.
• 🧊 Let the engine cool for at least 15 minutes to avoid touching hot parts.
• 🧤 Wear gloves and safety glasses to protect your hands and eyes.
• 🔌 Battery disconnection is not required for this job.
• 🚭 Do not smoke or use open flames near the engine bay.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 10mm socket
• 🧰 1/4" drive ratchet
• 🧰 3" socket extension
• 🧰 Flathead screwdriver (medium)
• 🧰 Work light or flashlight
• 🧰 Shop rag or microfiber cloth
• 🧰 Mechanic gloves
• 🧰 Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🧩 Engine air filter element (panel style, for Rogue 2.5L) - Qty: 1
• 🧩 Air box cover clips or screws - Qty: As needed if any are damaged
• 🧩 Cleaning wipes or mild cleaner - Qty: 1 (for wiping air box)

---

📋 Before You Begin

• 🅿️ Park the Rogue on a flat surface, shift to Park, and set the parking brake.
• 🔄 Turn off all accessories (AC, lights, radio) and remove the key.
• 🔍 Open the hood using the hood release inside the cabin, then lift the hood and secure it with the hood prop rod.
• 📦 Locate the engine air box: it is a black plastic box on the driver’s side of the engine bay, with a large hose running from it to the engine.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Identify the air box and fasteners

• 🔎 Stand at the front of the Rogue and look to the left (driver side). The air box is a rectangular black plastic box with a large rubber intake hose attached.
• 🔎 Look for metal clips and/or screws holding the top cover of the air box to the bottom half.
• 💡 Take a quick photo before disassembly

Step 2: Release air box clips

• 📎 If your air box uses clips, unhook them by hand. Pull each metal clip away from the cover until it pops free.
• 👋 If a clip is stiff, gently pry the edge with the flathead screwdriver while pulling with your fingers.
• 💡 Do not bend clips; they can snap

Step 3: Remove air box screws (if equipped)

• 🔩 If there are screws/bolts on the air box cover, use the 10mm socket, 3" extension, and 1/4" ratchet to remove them.
• 🔩 Turn counterclockwise to loosen and remove each screw. Place them in a small container so they don’t get lost.
• 📏 When reinstalling later, tighten these screws to 6 Nm (53 in-lbs) using the 10mm socket and ratchet.
• 💡 Only snug the screws; do not overtighten

Step 4: Lift the air box cover

• 📦 Gently lift the air box cover. It will hinge or slide slightly because the intake hose is still attached.
• 📦 You do not need to remove the hose. Just lift the cover enough to reach the filter.
• 💡 Lift slowly to avoid cracking the plastic

Step 5: Remove the old air filter

• 🧩 Grab the edge of the old filter and lift it straight up and out of the air box.
• 🧩 Note how the filter sits: rubber sealing edge usually faces up, and the pleats go down into the box.
• 💡 Match orientation with the new filter

Step 6: Clean the air box

• 🧽 Use the shop rag or microfiber cloth to wipe out dirt, leaves, or dust from the bottom of the air box.
• 🧽 If very dirty, lightly dampen the rag with cleaner, but do not leave liquid puddles inside the box.
• 💡 Keep debris from falling down the intake tube

Step 7: Install the new air filter

• 🧩 Place the new engine air filter into the air box with the rubber seal facing up and the pleats going down, matching the way the old filter sat.
• 🧩 Make sure the filter edges sit flat and fully in the groove of the air box so there are no gaps.
• 💡 Gaps allow unfiltered air into engine

Step 8: Refit the air box cover

• 📦 Lower the air box cover back into place, making sure it aligns with the bottom half and the filter.
• 📦 Check that no part of the new filter is pinched or sticking out.
• 💡 Press down gently to seat the cover

Step 9: Reinstall screws and clips

• 🔩 If your air box uses screws/bolts, install them by hand first to avoid cross-threading, then snug them with the 10mm socket, extension, and ratchet.
• 🔩 Tighten to 6 Nm (53 in-lbs) with the 10mm socket. This is “firm but not hard” if you don’t have a torque wrench.
• 📎 Re-latch all metal clips by pushing them back onto the cover until they click firmly into place.
• 💡 Double-check every clip and screw is secure

Step 10: Final checks under the hood

• 🔍 Confirm the air box cover is sitting flat with no gaps along the sealing edge.
• 🔍 Check that the large intake hose is still fully seated and its clamps are tight (hand-check only).
• 🔍 Remove any tools or rags from the engine bay.
• 🚗 Close the hood securely.

---

✅ After Repair

• 🔑 Start the engine and let it idle for a minute. Listen for any unusual hissing near the air box that might indicate a gap or loose hose.
• 🚦Take a short test drive. Throttle response may feel a bit smoother with a clean filter.
• 📆 Note your mileage and date so you know when the filter was last changed. Many people replace it every 15,000–30,000 miles depending on dust conditions.

---

💰 DIY vs Shop Cost

Shop Cost: $60-$120 (parts + labor)

DIY Cost: $15-$35 (parts only)

You Save: $45-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.5 hours.

---
