🔧 Fusion - Engine Air Filter Replacement

Replacing the engine air filter keeps dirt out of your engine and helps maintain power and fuel economy. On your Fusion, the filter sits inside the airbox (the black plastic box connected to the intake tube) near the front of the engine bay.

Difficulty Level: Beginner | Estimated Time: 0.25-0.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool engine to avoid burns from hot parts.
• ⚠️ Keep tools, fingers, and rags away from moving parts (fans/belts).
• ⚠️ Hybrid note: You do not need to touch any high-voltage components for this job—stay within the airbox/intake area.
• ⚠️ Battery disconnect is not required for an air filter swap.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Small flathead screwdriver
• 7mm socket
• 1/4" ratchet
• Flashlight
• Shop towel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine air filter - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground and shift to Park.
• Open the hood and prop it securely.
• Assumption: Your airbox uses metal latches and/or a small clamp screw (common on the Fusion). Follow the latch steps that match what you see.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the airbox

• Use a flashlight to find the black plastic airbox connected to the large intake tube.
• The intake tube often has a sensor nearby; avoid pulling on any wiring.

Step 2: Release the airbox cover

• If your airbox has metal clips, pop them open using your fingers or a small flathead screwdriver.
• If your intake tube clamp blocks the cover, loosen the clamp using a 7mm socket and 1/4" ratchet (just loosen—do not remove the clamp completely unless needed).
• Don’t pry hard; plastic tabs can snap.

Step 3: Open the airbox and remove the old filter

• Lift the airbox lid upward enough to access the filter.
• Pull the old filter straight out with your hands while wearing nitrile gloves.
• Note the orientation (which side faces up/out). The new filter must sit the same way.

Step 4: Clean the airbox sealing surface

• Use a shop towel to wipe out loose dust/leaves inside the bottom half of the airbox.
• Wipe the rim where the filter seals so unfiltered air can’t sneak past.
• Do not let dirt fall into the intake tube opening.

Step 5: Install the new engine air filter

• Insert the new engine air filter into the airbox, matching the original orientation.
• Make sure the filter’s edges sit flat in the tray all the way around.
• If it won’t sit flat, it’s not aligned.

Step 6: Close and secure the airbox

• Lower the airbox lid back into place.
• Snap the clips closed (or re-engage the cover tabs) by hand; use the small flathead screwdriver only if needed to help guide a clip.
• If you loosened the clamp, snug it with the 7mm socket and 1/4" ratchet (do not over-tighten—just firm).

Step 7: Quick final check

• Visually confirm the airbox is fully closed and evenly seated.
• Make sure no tools or rags are left in the engine bay.

---

✅ After Repair

• Start your Fusion and let it idle for 30 seconds.
• Listen for any hissing/whistling that could indicate the airbox lid isn’t sealed.
• If you hear a leak, shut it off and re-check the filter seating and clips/clamp.

---

💰 DIY vs Shop Cost

Shop Cost: $60-$140 (parts + labor)

DIY Cost: $15-$40 (parts only)

You Save: $45-$100 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.5 hours.

---
