🔧 Cruze - Engine Air Filter Replacement

You’ll open the air filter box (airbox) in the engine bay, remove the old filter, and install a new one. A clean air filter helps your Cruze breathe properly and can improve drivability and fuel economy.

Difficulty Level: Beginner | Estimated Time: 0.2-0.5 hours

Assumes the stock factory airbox is installed.

---

⚠️ Safety & Precautions

• ⚠️ Work with the engine OFF and cool to avoid burns.
• ⚠️ Keep dirt/leaves from falling into the open airbox or intake tube.
• ⚠️ Do not run the engine with the air filter removed.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7mm socket
• 1/4" drive ratchet
• Flat-blade screwdriver
• Work gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine air filter - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, set the parking brake, and pop the hood.
• Let the engine cool for 10-15 minutes if it was just running.
• Have a clean rag ready in case you need to wipe out loose debris.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the airbox

• Find the black plastic air filter box in the engine bay with a large intake tube connected to it.
• Put on safety glasses and work gloves.

Step 2: Loosen the intake tube clamp (if it limits lid movement)

• Use a 7mm socket with a 1/4" drive ratchet to loosen the worm-gear clamp at the airbox outlet.
• A worm-gear clamp is the common band clamp tightened by a small screw.
• Torque to 3 Nm (27 in-lbs) when tightening during reassembly.

Step 3: Release the airbox lid clips

• Unclip the metal retaining clips around the airbox lid by hand.
• If a clip is stubborn, gently pry it with a flat-blade screwdriver (don’t snap the clip).

Step 4: Open the airbox and remove the old filter

• Lift the airbox lid up enough to access the filter (you may not need to fully remove the lid).
• Pull the old air filter straight out.
• Note how the filter sits before removing.

Step 5: Clean the airbox sealing surface

• Use a flat-blade screwdriver (very gently) or your gloved hand to remove any leaves/debris from the airbox.
• Do not push dirt into the intake opening.

Step 6: Install the new air filter

• Place the new filter into the lower airbox the same way the old one came out.
• Make sure it sits flat and the rubber edge (seal) is fully seated all the way around.
• A pinched seal can cause unfiltered air leaks.

Step 7: Close the airbox and secure everything

• Lower the airbox lid into position.
• Snap all the metal clips back on by hand.
• Re-tighten the intake tube clamp using the 7mm socket and 1/4" drive ratchet to Torque to 3 Nm (27 in-lbs).

---

✅ After Repair

• ✅ Start the engine and let it idle for 20-30 seconds.
• Listen for a hissing/whistling sound near the airbox (can indicate a loose clamp or lid not seated).
• Quickly re-check that all clips are latched and the intake tube clamp is snug.

---

💰 DIY vs Shop Cost

Shop Cost: $60-$120 (parts + labor)

DIY Cost: $15-$35 (parts only)

You Save: $45-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.5 hours.

---
