🔧 Land Cruiser - Cabin Air Filter Replacement

Your cabin air filter cleans the air going through your A/C and heater. Replacing it helps reduce musty smells, improves airflow, and keeps dust/pollen out of the cabin.

Difficulty Level: Beginner | Estimated Time: 0.25-0.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF before working under the dash.
• ⚠️ Be gentle with glove box and plastic tabs; they can snap if forced.
• ⚠️ No battery disconnect is required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Clean nitrile gloves
• Small flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park your Land Cruiser on level ground and set the parking brake.
• Open the passenger door and move any items out of the glove box.
• Have a trash bag ready for the old filter.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Empty and open the glove box

• Open the glove box and remove everything inside.
• Use a small flashlight to look along the sides of the glove box so you can see the stops and damper.

Step 2: Release the glove box to drop down

• On the right side of the glove box, locate the small “damper” arm (the little shock-like piece that slows the glove box).
• Carefully unhook the damper from the glove box by hand. If it’s tight, use your clean nitrile gloves for grip.
• Gently push the glove box sides inward (left and right) to clear the built-in stops, then let the glove box swing down.
• Push in slowly—don’t bend the glove box hard.

Step 3: Remove the cabin filter housing cover

• Behind the lowered glove box, find the rectangular cabin filter access cover.
• Press the locking tabs and pull the cover straight off.
• Use a small flashlight if the tabs are hard to see.

Step 4: Remove the old cabin filter

• Slide the old filter straight out of the housing.
• Keep it level to avoid dumping leaves and dust.
• Note the airflow direction marking (often says “AIR FLOW” with an arrow) on the filter or housing.

Step 5: Install the new cabin filter

• Put on clean nitrile gloves to keep the new filter clean.
• Install the new filter in the same direction as the old one, matching the “AIR FLOW” arrow to the housing’s airflow direction.
• Slide it fully into place so it sits flat and doesn’t buckle.

Step 6: Reinstall the cover and glove box

• Snap the cabin filter access cover back on until the tabs click.
• Lift the glove box back up and push the sides inward again to pass the stops back into position.
• Reconnect the glove box damper on the right side.
• Close the glove box and make sure it opens/closes smoothly.

---

✅ After Repair

• Start your Land Cruiser and run the blower fan on medium-high for 30 seconds.
• Confirm airflow is stronger and there are no rattles from the glove box area.
• If you still have a musty smell, the evaporator case may need cleaning (separate service).

---

💰 DIY vs Shop Cost

Shop Cost: $80-$160 (parts + labor)

DIY Cost: $15-$45 (parts only)

You Save: $65-$115 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.5 hours.

---
