🔧 CX-9 - Cabin Air Filter Replacement

Your CX-9’s cabin air filter cleans the air going into the HVAC system (heat/AC). Replacing it helps reduce odors, improves airflow, and keeps dust/pollen out of the cabin.

Difficulty Level: Beginner | Estimated Time: 0.2-0.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF and remove the key/fob from the vehicle.
• ⚠️ Don’t force plastic tabs; they can snap in cold weather.
• ⚠️ Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground and set the parking brake.
• Turn the HVAC system OFF.
• Move the front passenger seat back for more room.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open the glove box

• Open the glove box fully and remove any items inside.
• Use flashlight to look at the right-side glove box damper (a small arm that slows the glove box).

Step 2: Disconnect the glove box damper

• Use your hand (or nitrile gloves for grip) to gently pop the damper arm off its pin on the right side.
• Damper = the little arm that prevents slamming.

Step 3: Release the glove box stops

• With the glove box open, gently push in on both sides of the glove box (near the upper edges) to clear the built-in “stops.”
• Once the stops clear, let the glove box swing down toward the floor.
• Use safety glasses to protect your eyes from dust.

Step 4: Remove the cabin filter access cover

• Behind the lowered glove box, find the cabin filter housing cover (a small rectangular door).
• Use your hand to press the side tab(s) and pull the cover off.
• Use flashlight to confirm the cover clips are fully released before pulling.

Step 5: Remove the old cabin air filter

• Slide the old filter straight out of the housing.
• Keep the filter level as you pull it out to avoid dumping leaves/dust.
• Old filter can be very dusty—go slow.

Step 6: Install the new cabin air filter

• Check the airflow direction marking on the filter frame (usually “AIR FLOW” with an arrow).
• Install the new filter in the same orientation as the old one (match the arrow direction shown on the housing/old filter).
• Slide it in straight—don’t bend or crush the pleats.

Step 7: Reinstall the cover and glove box

• Reinstall the filter access cover by lining it up and pressing until it clicks.
• Lift the glove box back up and push the sides in again so the stops pass back into place.
• Reconnect the glove box damper arm on the right side (press it back onto the pin until it snaps on).

---

✅ After Repair

• Start the vehicle and turn the fan to medium-high to confirm strong airflow.
• Switch between fresh air and recirculation to make sure there are no unusual noises.
• If you smell musty odor, consider running the fan for a few minutes with AC on.

---

💰 DIY vs Shop Cost

Shop Cost: ₹1,200-₹2,500 (parts + labor)

DIY Cost: ₹600-₹1,500 (parts only)

You Save: ₹600-₹1,000 by doing it yourself!

Shop labor rates vary but typically run ₹800-₹1,500/hour. This repair takes a shop approximately 0.2-0.5 hours.

---
