🔧 Pilot - Cabin Air Filter Replacement

Your Pilot’s cabin air filter cleans the air coming through the HVAC system (heat/AC). Replacing it helps reduce dust, odors, and keeps airflow strong through the vents.

Difficulty Level: Beginner | Estimated Time: 10-20 minutes

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition OFF and remove the key/fob from the vehicle.
• ⚠️ Work gently around the glove box damper (the small “slow-down” arm) to avoid breaking it.
• ⚠️ No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim removal tool (plastic) (specialty)
• Flashlight
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Cabin air filter - Qty: 1

---

📋 Before You Begin

• Park on level ground and shift to Park.
• Turn the HVAC system OFF.
• Move any items out of the glove box.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Empty and open the glove box

• Open the glove box and remove everything inside.
• Use a flashlight so you can clearly see the sides of the glove box.

Step 2: Release the glove box stops

• On each side of the glove box there’s a “stop” that prevents it from dropping all the way down.
• Use your hands to gently push the glove box sides inward to clear the stops, then let the glove box swing downward.
• Go slow so the plastic doesn’t crack.

Step 3: Disconnect the glove box damper arm

• The damper is the small arm/cylinder on the right side that makes the glove box open slowly.
• Use a trim removal tool (plastic) (specialty) to gently pry the damper end off its pin/clip, then let the glove box hang down.

Step 4: Remove the cabin filter access door

• Behind the glove box, find the rectangular cabin filter housing.
• Press the locking tabs on the housing door.
• Pull the door straight off by hand. Use a flashlight to see the tabs clearly.

Step 5: Slide out the old cabin air filter

• Pull the filter tray/filter straight out toward you.
• Wear nitrile gloves—the old filter can be dusty.
• If there are leaves/debris inside the housing, remove them by hand (do not push debris deeper).

Step 6: Install the new cabin air filter (correct direction)

• Look for the airflow arrow on the side of the new filter.
• Install it in the same orientation as the old one. (Typically the arrow points down for this style of housing.)
• Slide the filter fully in until it seats evenly.
• Don’t crush the filter—slide it gently.

Step 7: Reinstall the cover and glove box

• Reinstall the cabin filter housing door by hand until the tabs click.
• Reconnect the damper arm: use the trim removal tool (plastic) (specialty) if needed to guide it back onto its pin.
• Lift the glove box back up and gently push the sides inward to pass the stops, then close it.

---

✅ After Repair

• Start the engine and turn the fan to medium-high to confirm strong airflow.
• Switch between fresh air/recirculation and make sure there are no unusual noises behind the glove box.
• If airflow is weak, recheck that the filter isn’t installed backward or bent.

---

💰 DIY vs Shop Cost

Shop Cost: $60-$140 (parts + labor)

DIY Cost: $15-$40 (parts only)

You Save: $45-$100 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.3-0.5 hours.

---
